Audiovox VM9423 User manual
VM9423 Quick
Reference Guide
Multimedia Receiver
Press Audio
OPEN
Enter
SRC
NAV
INT
DISP
WIDE
PIC
Composite Video Out
Remote Control
Navigation Ready (NAV102 Only)
Bluetooth Ready (Requires BTM10)
DVD, CD, MP3, WMA, USB & SD
Touch Screen Interface
4
MediaLink A/V Input
SD Input Behind Front Panel
Featuring:
Navigation operation requires NAV102
installation
Bluetooth operation requires BTM10
installation
Rear Camera operation requires rear camera
installation
Anti-Theft Feature
Entering the Default Password
The VM9423 is equipped with an anti-theft feature requiring the user to enter a
password upon initial power on.
The default user password is 012345 (6 digits). Enter the password using the on-
screen keypad and then press the Enter (arrow) button. You can also use the remote
control keypad to enter the password.
123
456
789
0
Enter Password:
Changing the Password
To change the anti-theft and RATINGS protection password,perform the following
steps:
1. Press the SETUP button on the remote control or touch the button on the
screen to enter the “SETUP” menu.
2. Touch RATING to view the “RATING” sub-menu. An open lock icon to the right of
the “Password” field indicates that a user password had not yet been entered.
3. Touch the keypad icon next to the blue box in the “Password” field to open the
on-screen keypad.
4. Enter a new 6-digit password and press the Enter (arrow) button.
The "lock" icon will now appear closed and the new anti-theft password will be
set, as well as the password for RATING protection.
NOTE: If you forget your password, contact Customer Service at 1-800-323-4815 for
assistance.
RADIO
SETUP
RDS
Rating
Hardware
P.VOL
TS Cal
General Language Audio Back
Password
Rating 8. Adult
Load Factory Reset
Speaker
Demo
Bluetooth
02:40 AM
123
456
789
0
Clear
Press Audio Enter
Multimedia Receiver
7
17
1
2
4
3
15
14
13
16
8
6
19
9
5
12 10 11
18
NAV
INT
Controls and Indicators
1. Press to activate the automatic mechanical system and slide the TFT monitor
down to reveal the disc and SD slots. Press again to close the TFT.
2. When viewing files in DVD/disc mode, press to view the top and bottom
information bars. Press again to select "Display Off".
3. Press to view and adjust Brightness and Contrast settings.
4. Press to change the AM, FM or SAT band.
5. Rotate to adjust the volume. Press to access audio EQ menu.
6. Press to turn the unit on. Press and hold to turn the unit off.
Press repeatedly to select playing mode.
7. Press to adjust the display aspect of the picture to one of two settings: CINEMA,
NORMAL or Standby (screen off).
NOTE: Only CINEMA and Standby are available for non-video sources.
8. Press to silence the receiver. Press again to resume previous volume level.
9. Point remote control at IR Receiver to control functions.
10. Press to play the previous chapter/track or auto-search the previous available
radio station. In menu mode, press to move the cursor to the left.
11. Press to slow forward/slow reverse disc or tune down one frequency step in tuner
mode. In menu mode, press to move the cursor down.
12. Use thin metallic object to depress RESET button and restore factory default
settings.
13. Press to pause or resume playback or to confirm current selection.
14. Press to access the next chapter or track or auto-search the next available radio
station. In menu mode, press to move the cursor to the right.
15. Press to fast forward/fast reverse disc or tune up one frequency step in tuner
mode. In menu mode, press to move the cursor up.
16. Press to control intro playback function.
17. Touch the TFT to control head unit functions.
18. When the NAV102 is connected to the head unit, press to display the navigation
user interface.
19. Press to control repeat playback function.
23
22
21
20
EJECT LABEL SIDE UP
Controls and Indicators (continued)
20. Press to eject disc. Press and hold to reset core mechanism position.
21. Insert SD card for playback of media files through the radio.
22. Insert disc for automatic playback.
23. Disc Present Indicator illuminates when disc is inserted.
Common User Settings
Audio Control Menu
Touch the EQ button on the left side of the screen to access the Audio Control Menu,
shown below.
1. Use the touchscreen or the left/right joystick buttons on the unit or remote control
to highlight the audio feature to be adjusted.
2. Touch the screen or press the joystick enter button to select the highlighted
option.
3. Touch the +/– buttons on the screen or use the joystick to adjust the selected
feature to the desired setting.
Touch the "FAD-BAL"
button to access a
second screen with the
Balance/Fader
settings.
Use the arrows on
either side of the box
where "User" is
selected, to choose a
preset equalizer level.
NOTE
The EQ mode will automatically change to “USER” when individual
audio functions are adjusted.
EQ: User
E
Q
T
A
G
+12 —
0 —
–12 —
80 250 600 1k 4k 10k 16k
FAD-BAL EQ USER BACK
