Audiovox CarStream Troubleshooting guide
AUDIO,T"OX®
'------------'
r m
BLUETOOTH
NTEGRATION
KIT
for selected Volkswagen I Audi vehicles
using CD Changer emulation
Installation Guide/User manual
./
2
Copyrights and Trademarks
Copyright 2015 VOXX Electronics Corporation
All Trademarks and Logos are the property
of
their respective owners.
All rights reserved.
3
Table
of
Contents
Warning and safety .........................................................
.4
Pairing Your Phone ............................................................18
Product registration .........................................................5 Bluetooth I AUX operation in CDC mode ...........................19
Kit contents ......................................................................6 Operation .......................................................................... 20
DIP switch overview .........................................................7 Managing Multiple calls ....................................................
21
Note to Installer .....
___
..
___
...................................................8 Music Control ...................................................................22
Connection diagram -Bluetooth and AUX .....................9 Audio Streaming ...............................................................23
Vehicle bus
connecotr-
BT100AUD kit .........................10 Auxiliary audio source ......................................................24
Vehicle bus connecotr -
BT1
01
AVW kit .......................
11
Optional remote controller ...............................................25
Vehicle bus
connecotr-
BT101AVW kit ........................12 Troubleshooting ..............................................................26
Harness modification for BT101AVW ............................13 Firmware update .........................................................27-28
Vehicle bus
connector-
BT1
02AVW kit ........................14 Auxiliary audio source .......................................................28
Installation ................................................................15-16 Warranty ..........................................................................30
Controls and Indicators .................................................17 FCC Compliance ..............................................................
31
4
AUDIO~~ox~
Warning
and
safety!
Please read these instructions carefully before proceeding. Failure to follow instructions may result
in
improper operation or injury. VOXX Electronics Corporation, its regional offices, distribuotrs or resellers
won't take any responsibility for any damage or injury as a result
of
using the integration kit.
-Do not open, disassemble or alter the interface
in
any way.
-Do not insert anything into the casing.
-Do not cut or try to alter cables
in
any way and always use the correct connections.
-Only
operate unit when stationary or ask passengers to operate it for you.
-Do
not allow the Mobile Phone to distract you from driving.
-Exercise good judgement and keep your eyes on the road at all times.
-Do not expose unit to extreme temperatures, humidity or shock.
X
X
-Keep away from children! -Interface components may contain small parts, can be broken or disassembled
and components may become loose from vibration and heat. Small components and packaging materials
may
be
a choking hazard when handled by children.
'
'
AUDio~~oxGD
Congratulations
on
your
purchase!
Thank you for purchasing this integration kit. Please review this booklet before operating the unit. This
interface was designed and manufactured to seamlessly integrate with your vehicle's factory audio system.
Product
registration
5
We recommend registering yourAudiovox product so you can receive news about important firmware updates
and have unlimited access to our online support system.
To
register
your
Audiovox
product, please complete the
following
steps:
1.
Visit http://www.audiovoxoei.com
2.
Look up and save the serial number
of
the product.
3.
Complete the product registration form.
4.
Submit the form.
5.
Save the registration sheet
in
a safe place for future reference.
If you are unable to complete the registration via internet, please call VOXX Electronics at 1-800-645-4994.
Prior to installation make sure the module's firmware is up to date to ensure compatibility
with the latest features and enhancements. Please refer to page 28 to update firmware.
6
CarStream
kit
contents
CarStream module Vehicle Interface
Harness
Optional accessories (sold separately):
AUX connector
(MCC1
06AUX) IR Receiver &
Remote controller
(MCC613RCK)
BCS
1M
Bluetooth
module
~
\
(
/
\')
\
~)
Clip and 2-sided mount
For more accessories, visit
www
.audiovoxoei.com
DIP
switch
settings
At the time of printing, the DIP switch settings are currently
not
being used on the
Audi
I Volkswagen CO-Changer emulation compatible CarStream module.
l 1
ON/OFF Switch Positions
7
8
AUDIO~~ox·
Attention
installer!
Please
read
the
following!
Audiovox
strongly
recommends
that
the
unit
be installed in an easily accessible location!
DO NOT PLACE IT BEHIND THE RADIO AND DO NOT HIDE UNDER CARPET!
Whether the unit is professionally or self installed, put the module where you, the end user can get to it easily
in
the future. (Have the installer show you where the interface module is installed.)
Installing the module behind the radio will make it difficult to:
-Add possible future upgrades, changing software, adding new features, improving operation;
-Access the AUX input on the module to attach any audio device;
-Access the DIP switches located on the module;
-Remove the unit
in
case
of
failure.
MAKE
SURE THAT THE MODULE IS IN AN ACCESSIBLE LOCATION!
Connection
diagram
-
Bluetooth
and
AUX
inputs
0
IR
Receiver
(optional)
CarStream module
(front) Vehicle Inter-
face Cable
Auxiliary device
(not included)
AUX cable
(optional)
0
[>
t
CarStream module
(back)
LJo
~
~
ll~
Upgrade Port Bluetooth module
USB to
PC
or MAC computer
* Do not connect the Bluetooth module under any circumstance to the AUXILIARY input
connector! Improper connection can cause permanent damage to Bluetooth/lnterface module.
9
10
AUDIO~
..
OXGD
Vehicle
bus
connector-
BT100AUD
kit
only.
You
can access the
CD
changer connector located on the back of the radio. Unplug the factory connection
if present and plug the
BT1
OOAUD
connector into the receptacle. The connector should securely lock.
Ground wire MUST
be
connected to a stable grounding point.
To
factory harness
in vehicle
BT1
OOAUD
Connector
To
ground
To
CarStream
Interface Module
