Asus Eee Pad Transformer TF101G User manual

Eee Pad User Manual

E6422

Notes for This Manual

A few notes and warnings are used throughout this guide, allowing you to

complete certain tasks safely and eectively. These notes have dierent degrees

of importance as follows:

WARNING! Important information that must be followed for safe operation.

IMPORTANT! Vital information that must be followed to prevent damage

to data, components, or persons.

TIP: Tips for completing tasks.

NOTE: Information for special situations.

ASUS is devoted to creating environment-friendly products/

packagings to safeguard comsumers’ health while minimizing

the impact on the environment. The reduction of the number

of the manual pages complies with the reduction of carbon

emission.

For the detailed user manual and related information, refer

to the user manual included in the device or visit the ASUS

Support Site at http://support.asus.com/

TF101 TF101G

ASUS Eee Pad

There are three main types of airport security devices: X-ray machines

(used on items placed on conveyor belts), magnetic detectors (used on

people walking through security checks), and magnetic wands

(hand-held devices used on people or individual items). You can send

your Eee Pad through airport X-ray machines. But do not send your Eee

Pad through airport magnetic detectors or expose it to magnetic wands.

Airplane Precautions

Ask an airline personnel if you want to use your Eee Pad onboard an aircraft.

Most airlines have restrictions for using electronic devices. Most airlines allow

electronic use only between and not during takeos and landings.

Charging Your Batteries

If you intend to use battery power, be sure to fully charge your battery pack

before going on long trips. Remember that the power adapter charges the

battery pack as long as it is plugged into the computer and an AC power

source. Be aware that it takes much longer to charge the battery pack when

the Eee Pad is in use.

Remember to fully charge the battery (8 hours or more) before rst use

and whenever it is depleted to prolong battery life. The battery reaches its

maximum capacity after a few full charging and discharging cycles.

ASUS Eee Pad

Package Contents

If any of the items is damaged or missing, contact your retailer.

Eee Pad and Digitizer Pen Case (Optional)

USB charger USB cable

User Manual

User Manual Warranty Card

ASUS Eee Pad

Your Eee Pad

Power button

The power button turns your Eee Pad on/o. Press and release

the switch to turn on or wake the Eee Pad. Press and release it

again to put the Eee Pad into sleep mode. If the system becomes

unresponsive, Press and holding the power switch will force the Eee

Pad to power o. Note that forcing the system to power o may

result in data loss. Please inspect your data to ensure there is no data

loss. It is strongly recommended that important data be backed up

regularly.

ASUS Eee Pad

Volume Key

Press this button to increase or decrease the system volume.

Rotation Lock key

To lock the screen in the current orientation, slide this switch to the

left. To unlock, slide this switch to the right.

SIM Card slot (on selected model)

The SIM card compartment allows insertion of a mobile SIM card for

3G functions.

Built-in front Camera

Use the built-in camera for picture taking, video recording, video

conferencing, and other interactive applications.

Touch Screen Panel

The touch screen panel allows you to operate your Eee Pad using up

to two ngers or with the included digitizer pen.

Power (DC) Input

Insert the power adapter into this port to supply power to your Eee

Pad and charge the internal battery pack. To prevent damage to your

Eee Pad and battery pack, always use the bundled power adapter.

Built-in rear Camera

Use the built-in camera for picture taking, video recording, video

conferencing, and other interactive applications.

Headphone Output/Microphone Input Combo Jack

The stereo combo jack (3.5mm) connects the Eee Pad’s audio

out signal to amplied speakers or headphones. Using this jack

automatically disables the built-in speaker.

The jack is also designed to connect the microphone used for Skype,

voice narrations, or simple audio recordings.

ASUS Eee Pad

mini HDMI port

Insert a mini HDMI cable into this port to connect to a high-denition

multimedia interface (HDMI) device.

Micro SD Card Slot

Insert Micro SD card into this slot

ASUS Eee Pad

Charging the Eee Pad

• Use only the power adapter that comes with your device. Using a

dierent power adapter may damage your device.

• The input voltage range between the wall outlet and this adapter is

AC 100V–240V, and the output voltage of this adapter is 15V, 1.2A.

To prolong battery life, fully charge the battery for up to 8 hours when

using the Eee Pad for the rst time and whenever the battery power is

fully depleted.

ASUS Eee Pad

Declarations and Safety Statements

Federal Communications Commission Statement

This device complies with FCC Rules Part 15. Operation is subject to the

following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to Part 15 of the Federal Communications

Commission (FCC) rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

The use of a shielded-type power cord is required in order to meet FCC

emission limits and to prevent interference to the nearby radio and

television reception. It is essential that only the supplied power cord be

used. Use only shielded cables to connect I/O devices to this equipment.

You are cautioned that changes or modications not expressly approved

by the party responsible for compliance could void your authority to

operate the equipment.

(Reprinted from the Code of Federal Regulations #47, part 15.193, 1993.

Washington DC: Oce of the Federal Register, National Archives and Records

Administration, U.S. Government Printing Oce.)

ASUS Eee Pad

FCC Radio Frequency (RF) Exposure Caution

Statement

Any changes or modications not expressly approved by the party

responsible for compliance could void the user’s authority to operate

this equipment. “The manufacture declares that this device is limited to

Channels 1 through 11 in the 2.4GHz frequency by specied rmware

controlled in the USA.”

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. To maintain compliance with FCC RF exposure

compliance requirements, please avoid direct contact to the transmitting

antenna during transmitting. End users must follow the specic operating

instructions for satisfying RF exposure compliance.

IC Radiation Exposure Statement for Canada

This equipment complies with IC radiation exposure limits set forth for an

uncontrolled environment. To maintain compliance with IC RF exposure

compliance requirements, please avoid direct contact to the transmitting

antenna during transmitting. End users must follow the specic operating

instructions for satisfying RF exposure compliance.

Operation is subject to the following two conditions:

• This device may not cause interference and

• This device must accept any interference, including interference that may

cause undesired operation of the device.

To prevent radio interference to the licensed service (i.e. co-channel Mobile

Satellite systems) this device is intended to be operated indoors and away

from windows to provide maximum shielding. Equipment (or its transmit

antenna) that is installed outdoors is subject to licensing.

This device and its antenna(s) must not be co-located or operating in

conjunction with any other antenna or transmitter.

Country Code selection feature to be disabled for products marketed to the

US/CANADA.

This Class [B] digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du

Canada

FCC Regulations:

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

This device has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiated radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for

compliance could void the user‘s authority to operate the equipment.

The antenna(s) used for this transmitter must not be co-located or operating in

conjunction with any other antenna or transmitter.
