Asus Asus Nexus 7 User manual
Quick Start Guide
For online help and support, visit
support.google.com/nexus
Copyright
Copyright © 2012 ASUSTek COMPUTER INC.
All rights reserved.
No part of this guide, including the products and software
described in it, may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language in
any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written
permission of ASUSTek COMPUTER INC. ("ASUS"). This clause
does not apply to such software which is licensed under the
General Public License ("GPL" ) or other Free Open Source
Licenses. Copies of the respective license terms, and where
required an offer to provide the respective source code, are
included in the product.
Google, Android, Gmail, Google Maps, Nexus 7, Google Play,
YouTube, Google+, and other trademarks are property of Google
Inc. ASUS and the ASUS logo are trademarks of ASUSTek
Computer Inc. All other marks and trademarks are properties of
their respective owners.
The content of this guide may differ in some details from the
product or its software. All information in this document is
subject to change without notice.
ASUS Pad ME370TG.
For online help and support, visit
support.google.com/nexus
Nexus 7 3
your point of purchase for assistance
country or region.
What’s in the box
Warranty
Nexus 7
4
Your Nexus 7
Touch screen
Front-facing
camera
3.5m headset jack
4-pin connector
Microphone
SIM card tray
Nexus 7 5
Microphone
Power/lock key
3.5mm headset jack
Volume key
Speaker
Microphone
Volume key
Power/lock key
NFC area
Microphone
4-pin connector
SIM card tray
Nexus 7
6
Charge the battery
a
unpack your Nexus 7. It’s a good idea to fully charge the
battery as soon as you get a chance.
charging unit, as shown in the illustration. Then connect
the charging unit to a power outlet.
DO NOT throw the battery in municipal waste.
The symbol of the crossed out wheeled bin
indicates that the battery should not be placed in
municipal waste.
Nexus 7 7
•The USB charging unit varies by country or
region.
•Use only the USB charging unit that comes with
your Nexus 7. Using a different charging unit
may damage your tablet.
•To avoid risk of injury or damaging your device,
unit and USB cable before charging the battery.
•The input voltage range between the wall outlet
and this charging unit is AC 100V–240V, and
the charging unit’s output voltage is DC 5V, 2A.
•Your Nexus 7 can be charged via the USB port
•The socket-outlet shall be installed near the
equipment(Pad) and shall be easily accessible.
on a computer only when Nexus 7 is in sleep
mode (screen off) or turned off. Charging
through the USB port will take longer than
charging with the USB charging unit.
DO NOT throw Nexus 7 in municipal waste. This
product has been designed to enable proper
reuse of parts and recycling. The symbol of
the crossed out wheeled bin indicates that the
product (electrical, electronic equipment and
mercury-containing button cell battery) should
not be placed in municipal waste. Check local
regulations for disposal of electronic products.
Nexus 7
8
Insert SIM card
insert a micro SIM card provided by your carrier. If no
card is installed, the message “No SIM card” appears
on the tablet’s lock screen.
When the tablet is face down, the SIM card tray is
located on the right side.The eject button is a small
round aperture on the left side of the tray door.
Nexus 7 9
To install a new SIM card:
1. Turn your tablet off and place it on a flat surface
with the screen facing down.
2. Locate the SIM card tray on the right side of your
tray door.
3. Insert the SIM ejection tool that comes with
the tablet (or a paperclip) into the eject button
pops out.
4. Remove the tray and place the micro SIM card
inside it, with the contacts facing up and the
angled corner to the left. There is only one
5. Carefully reposition the tray in the slot and push it
gently back into the tablet.
To activate a new SIM card, turn off Wi-Fi after setting
instructions. Once you’re done, you can turn Wi-Fi
back on.
