Asus Eee Pad Slider 16GB User manual
Eee Pad User Manual
TF101
E6536
There are three main types of airport security devices: X-ray machines (used
on items placed on conveyor belts), magnetic detectors (used on people
walking through security checks), and magnetic wands
(hand-held devices used on people or individual items). You can send your
Eee Pad through airport X-ray machines. But do not send your Eee Pad
through airport magnetic detectors or expose it to magnetic wands.
Airplane Precautions
Ask an airline personnel if you want to use your Eee Pad onboard an aircraft.
Most airlines have restrictions for using electronic devices. Most airlines allow
electronic use only between and not during takeos and landings.
Charging Your Batteries
If you intend to use battery power, be sure to fully charge your battery pack
before going on long trips. Remember that the power adapter charges the
battery pack as long as it is plugged into the computer and an AC power source.
Be aware that it takes much longer to charge the battery pack when the Eee Pad
is in use.
Remember to fully charge the battery (8 hours or more) before rst use and
whenever it is depleted to prolong battery life. The battery reaches its maximum
capacity after a few full charging and discharging cycles.
Contents
Package Contents .............................................................................................. 3
Your Eee Pad......................................................................................................... 4
Charging the Eee Pad ....................................................................................... 7
Your Eee Pad mobile docking (optional) ................................................... 8
Docking the Eee Pad.......................................................................................11
Charging the Eee Pad on the docking......................................................12
Android Environment & Applications.......................................................13
Desktop .............................................................................................................13
Music .............................................................................................................14
Gallery .............................................................................................................15
Camera .............................................................................................................17
Market .............................................................................................................18
Places and Maps..............................................................................................19
Settings .............................................................................................................20
ASUS Applications..............................................................................21
ASUS Launcher................................................................................................21
File Manager.....................................................................................................22
MyLibrary...........................................................................................................25
MyNet .............................................................................................................28
Polaris® Office ..................................................................................................30
MyCloud.............................................................................................................33
Eee Pad PC Suite (on PC)................................................................................40
MyDesktop PC Server....................................................................................40
ASUS Webstorage...........................................................................................40
ASUS Sync .........................................................................................................41
Declarations and Safety Statements.........................................................42
Copyright Information ...................................................................................46
Limitation of Liability......................................................................................46
ASUS Eee Pad Manual
2
ASUS Eee Pad Manual
3
Package Contents
• If any of the items is damaged or missing, contact your retailer.
• The power plug that comes with your Eee Pad may vary depending
on your territory to t the wall outlet.
Eee Pad USB Charger
Power Plug Docking connector to USB cable
User Manual
User Manual Warranty Card
ASUS Eee Pad Manual
4
Your Eee Pad
8
1
3
2
4
7
10
5
11
6
9
ASUS Eee Pad Manual
5
1
Power button
The power button turns your Eee Pad on/o. Hold the power
button for 2 seconds to power on your Eee Pad. When the Eee Pad
is powered on, press the power button to put the Eee Pad into sleep
mode or wake it up from sleep mode. Hold the power button for 0.5
second to display the shutdown dialog box. If the system becomes
unresponsive, press and hold the power switch to force the Eee Pad
to power o.
Forcing the system to power o may result in data loss. Please
inspect your data to ensure there is no data loss. It is strongly
recommended that important data be backed up regularly.
2
Volume Key
Press this button to increase or decrease the system volume.
3
SIM Card slot (on selected model)
The SIM card compartment allows insertion of a mobile SIM card for
3G functions.
Use a straightened paper clip to press the opening beside the
SIM card slot to eject the SIM card tray.
4
Built-in front Camera
Use the built-in camera for picture taking, video recording, video
conferencing, and other interactive applications.
5
Touch Screen Panel
The touch screen panel allows you to operate your Eee Pad using
multi-touch up to ten ngers.
6Docking Connector
• Insert the power adapter into this port to supply power to
your Eee Pad and charge the internal battery pack. To prevent
damage to your Eee Pad and battery pack, always use the
bundled power adapter.
• Connect the docking connector to USB cable to the Eee Pad and
another system (notebook or desktop) for data transmission.
• Dock the Eee Pad to the mobile docking for extended functions,
including keyboard, touchpad and USB interface.
7
Built-in rear Camera (on selected models)
Use the built-in camera for picture taking, video recording, and other
interactive applications.
8
Headphone Output/Microphone Input Combo Jack
The stereo combo jack (3.5mm) connects the Eee Pad’s audio
out signal to amplied speakers or headphones. Using this jack
automatically disables the built-in speaker.
For microphone input function, the jack supports the headset
microphone ONLY.
9Microphone (Built-in)
The built-in mono microphone can be used for video conferencing,
voice narrations, or simple audio recordings.
10
mini HDMI port
Insert a mini HDMI cable into this port to connect to a high-denition
multimedia interface (HDMI) device.
11
Micro SD Card Slot
Insert Micro SD card into this slot
ASUS Eee Pad Manual
6
ASUS Eee Pad Manual
7
Charging the Eee Pad
• Use only the power adapter that comes with your device. Using a
dierent power adapter may damage your device.
• The input voltage range between the wall outlet and this adapter is
AC 100V–240V, and the output voltage of this adapter is 15V, 1.2A.
To prolong battery life, fully charge the battery for up to 8 hours when
using the Eee Pad for the rst time and whenever the battery power is
fully depleted.
41
2
3
ASUS Eee Pad Manual
8
Your Eee Pad mobile docking (optional)
The Eee Pad mobile docking is purchased separately.
1 3
4 3
2
Home PgDp
PgUp
End
Enter
Backspace
Tab
Caps Lock
Shift Shift
Ctrl Ctrl
Alt
Fn
Fn
5
76
ASUS Eee Pad Manual
9
1Docking Connector
• Insert the power adapter into this port to supply power to
your Eee Pad and charge the internal battery pack. To prevent
damage to your Eee Pad and battery pack, always use the
bundled power adapter.
• Connect the docking connector to USB cable to the Eee Pad and
another system (notebook or desktop) for data transmission.
2Battery Charge Indicator (dual-color)
With AC adapter:
Green ON: Battery power is between 95% and 100%.
Orange ON: Battery power is less than 95%.
Orange Blinking: Battery power is less than 10%.
Orange Blinking Quickly: Battery power is less than 3%.
Without AC adapter and with Eee Pad:
Orange Blinking Quickly: Battery power is less than 3%.
Ensure to connect the power charger when the this indicator
starts blinking.
3USB Port (2.0)
The USB (Universal Serial Bus) port is compatible with USB 2.0 or USB
1.1 devices such as keyboards, pointing devices, ash disk drive and
hard disk drives.
4Memory Card Slot
Normally an external memory card reader must be purchased
separately in order to use memory cards from devices such as digital
cameras, MP3 players, mobile phones, and PDAs. This Eee Pad mobile
docking has a built-in high-speed memory card reader that can
conveniently read from and write to many ash memory cards.
5
Mobile docking latch
Move the mobile docking latch to the left to release the Eee Pad from
the mobile docking.
6Keyboard
The keyboard provides comfortable travel (depth at which the keys
can be depressed) and palm rest for both hands.
The keyboard diers for each territory.
7Touchpad and Buttons
The touchpad with its buttons is a pointing device that provides the
same functions as a desktop mouse.
ASUS Eee Pad Manual
10
