Asante 50598 User manual
Step 1
Connection to the router
Quick Guide
...............................................................................................................................................................
Thank you for choosing
Asante Smoke Detector Kit
For first time installation, please make sure that Asante products and
your router are within close proximity to each other. Once configured, they can be
moved to desired locations. If you have more than one Smoke Detector, it is
very important to add them one at a time. Insert battery into one unit, claim on
the app and then move on to the next.
Asante Genie
ports and lights
Asante Smoke Detector
ports and buttons
Using the RJ45 Ethernet cable provided connect
the Asante Genie to a LAN port on your router.
Step 3
Download app and device discovery
Step 2
Power
1. Connect the power to Asante Genie and make sure
power light comes on.
2. Cloud Light comes on usually after 1 to 3 minutes
depending on the internet connection.
* Connect Smartphone to same WiFi router that Asante Genie
is connected to.
Wireless Pairing Light
WiFi wireless
connectivity light Signal Strength
Light for Wireless
Test Button
(LED Light)
Test Button
Inserting battery
into Smoke Detetor
Cloud Light
Power
1. Download free app from Apple Store or Google Play
Simply search for Asante Genie
2. Create an account and sign in
3. Claim your first Asante Genie when prompted
* If your Smartphone can not connect to same WiFi router, use the
procedure below to manually add the device.
1. Login to app and click the + sign as shown
2. Enter the MAC address that appears on the back of Asante Genie in
the fields provided and click on apply.
Step 4
Setup of Smoke Detector
Step 5
Location test and mounting instruction
Ethernet port
to connect to your
personal router Power
Factory default reset button
( hold down for 6 seconds
to reset to default )
Cable/Phone Jack
1. Remove the base from the smoke detector
2. Insert battery into smoke detector and close the lid. Inside the
battery compartment there is a red lever that will be pushed down
when inserting the battery.
3. Claim your first Smoke Detector when prompted in the app.
4. Before installing additional Smoke Detectors, rename the one
that you just installed. This way each Smoke Detector will have
a specific name.
Repeat steps 1-4 for any additional Smoke Detectors you might have.
1. Login to app using your Smartphone and enter the setting page
for Smoke Detector. click on Location Test button as shown
2. Press the test button on the Smoke Detector and make sure you
receive a test response on your app
3. Now move the Smoke Detector to the location that it will be installed
4. Repeat steps 1-3 to make sure Smoke Detector is still within
the communication range. If you received a response on the app,
then you are done. Proceed with mounting of the unit.
5. If you do not get a response from Smoke Detector at the location
that the unit needs to be installed, then consider relocating Asante Genie.
To do this, please see step 7.
To ensure a reliable communication between the Smoke Detector and
Asante Genie, the following steps should be taken. It is a good idea to do
the test holding the Smoke Detector in an upside down position just like
if it was attached to ceiling.
__________________________________________________
Step 6
Mounting instruction for Smoke Detector
WiFi set up for Asante Genie (Optional)
1. Remove the mounting base from the Smoke Detector (counter clockwise) and hold it against
the ceiling surface that you would like to install the unit.
2. Mark the screw holes using a pen or pencil as shown below and
Tighten the base to the surface using the screws provided.
3. Holding the smoke detector firmly into base, turn it clockwise to lock
4. You can also do the Location Test one more time to confirm the correct location for Smoke Detector.
Asante Genie wireless bridge mode can extend your wireless coverage in a large size property. For areas
larger than 5000 sq.ft, consider placing the Asante Genie in a central location to bridge Asante devices into
your home router. Otherwise we strongly recommend using the Ethernet wired mode. If you still want to use
the wireless option, please follow the procedure below.
1. Login to app and select the settings button as shown below
2. Select WiFi manager
3. Select your home router from the list
4. Enter your personal wireless password that has been setup on your router when prompted
Once connected, you can disconnect the Ethernet cable between the Asante Genie and router and move
the Asante Genie to appropriate location. The lights on the Asante Genie will indicate a wireless signal.
Testing Your Smoke Detector
Test the Smoke Detector weekly by pressing the test button and holding it for around 4 seconds until the
alarm sounds. The sound pattern is 3 beeps, pause, and then 3 beeps with red LED flashing continuously
and rapidly.
Step 7
Test Button and LED Light
In Standby Mode
The red LED, as the ALARM indicator, are featured with the Asante Smoke Detector Alarm.
It can be seen through the clear test button on the cover of the unit. When red LED flashes every 334 seconds,
it indicates that the Smoke Detector is under normal operation. When Smoke Detector senses smoke; it
sounds an alarm with 3 beeps, pause and 3 beeps. The red LED will flash continuously and rapidly.
Silence Feature
The silence feature can temporarily turn off sound for up to 10 minutes.
To use this feature, press test button on the cover when alarm goes off.
If the smoke concentration around the Smoke Detector is still at an alarming level after 10 minutes of silence,
the unit will re-alarm immediately.
Low Battery Warning Signal
If the alarm horn begins to chirp once in 43 seconds with red and yellow LED flashing, it indicates that the
Smoke Detector battery is weak. This low battery warning signal should last for up to 30 days. However, you
should replace battery immediately upon receiving this signal for continuous protection.
Tamper Switch Feature
If the Smoke Detector is not mounted into the bracket properly during the first 5 minutes after battery is
installed, the tamper function is triggered and the yellow LED stays on.
If the Smoke Detector is still not mounted into the bracket properly 5 minutes after battery is installed, you
will hear three beeps with yellow LED steadily on until smoke alarm is mounted back into bracket.
Internet Wireless Router
Asante Genie
Irrigation
Controller
Garage Door
Opener
with Camera
Smoke
Detector
40ft
5000 sq.ft
Use wireless connection to maximize
the WiFi coverage. Asante Genie can cover up to 5000 sq.ft
Radius
