Aries P35-2004 User manual
PAGE 1 • P35-2004-RA • 800.798.0813 • NEED ASSISTANCE? • ARIESAUTOMOTIVE.COM
Product Image
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
Before installing this bull bar, we recommend installing a license plate relocation
bracket, sold separately (ARIES part# 35-0000).
Level of Difficulty
Easy
Parts List
1Bull bar
1Mounting bracket,
driver side
1Mounting bracket,
passenger side
4Hex bolt, 12mm
8Flat washer, 12mm
4Nylock nut, 12mm
Tools Required
Ratchet Socket, 18mm
Level Wrench, 19mm
Scan
for helpful
install tips
INSTALLATION MANUAL P35-2004
ARIESAUTOMOTIVE.COM • NEED ASSISTANCE? • 800.798.0813 • P35-2004-RA • PAGE 2
Step 1
Starting underneath the vehicle,
remove the factory tow hooks.
Set the hardware aside for later use.
Step 2
Select the driver-side bracket. Check
the fit between the tow hook and the
bracket.
Lift the tow hook and bracket to the
underside of the frame channel and
reinstall using the factory hardware.
Step 3
Snug the hardware, but do not fully
tighten. Some factory tow hooks may
not clear the bracket and cannot be
reinstalled.
Repeat this step on the passenger side.
Step 4
With help, lift the bull bar into place and
align the mounting tabs of the bull bar on
the outside of the installed brackets.
PAGE 3 • P35-2004-RA • 800.798.0813 • NEED ASSISTANCE? • ARIESAUTOMOTIVE.COM
Step 5
Insert a 12mm hex bolt with a flat washer
from the outside and secure with another
flat washer and a nylock nut.
Snug the hardware,
but do not fully tighten.
Repeat this on the passenger side
Step 6
Level and adjust the bull bar into the
desired position and tighten all hardware.
Congratulation on the installation
of your brand new ARIES 3" bull bar.
Step 7
With the bull bar installed, periodic
inspections should be performed to ensure
all mounting hardware remains tight.
To protect your investment, we
recommend you apply a layer of
nonabrasive wax.
