Archos 50 Oxygen+ User manual
EN
Table of contents
For more information, please consult the FAQs on www.archos.com.
Make sure to read them before considering any product return. As we
are often updating and improving our products, your device’s software
may have a slightly dierent appearance or modied functionality than
presented in this Quick Start Guide.
Package contents..........................................................................................................
Description of the phone...........................................................................................
Assembling......................................................................................................................
Getting started...............................................................................................................
3G & WiFi connection...................................................................................................
Google account & Contacts........................................................................................
Hints & tips with AndroidTM........................................................................................
Troubleshooting.............................................................................................................
2
3
6
8
10
12
14
16
ARCHOS_50_Oxygen_Plus_book_AllLang.indd 1 27/03/2015 17:21:27
2
Package Contents
Check your product box for the following items:
-ARCHOS 50 Oxygen +
-Headset
-USB cable
-Charger
-Quick start guide
-Warranty Legal & Safety notices
The items supplied with your device and available accessories may vary
depending on your region or service provider.
The supplied items are designed only for your device and may not be
compatible with other devices.
Unapproved accessories may cause your device to malfunction.
ARCHOS_50_Oxygen_Plus_book_AllLang.indd 2 27/03/2015 17:21:27
3
2
1
3
8
4
5
6
7
EN
1Headset jack
Phone speaker
Camera
Volume buttons
ON/OFF button
Micro-SIM
Micro-SD card | Nano SIM
Charging led | Notication led
2
3
4
Description of the phone
5
6
7
8
ARCHOS_50_Oxygen_Plus_book_AllLang.indd 3 27/03/2015 17:21:28
4
9
10
13 1212
11
Description of the phone
9Camera
Flash light
Noise reduction
Loudspeaker
Micro-USB port
12
11
10
13
ARCHOS_50_Oxygen_Plus_book_AllLang.indd 4 27/03/2015 17:21:29
5
14 15 16
EN
16
15
14
Menu: open the list of options available on the current screen.
Home/Recent apps/Google NOW: short press to return to the Home
screen; double press to open the list of recent applications; long press to
access Google Now.
Back: return to the previous screen.
Menu
Home/Recent apps/Google NOW
Back
ARCHOS_50_Oxygen_Plus_book_AllLang.indd 5 27/03/2015 17:21:29
6
Assembling
Tip:
Before using your device for the first time, charge completely its battery.
Opening & closing a slot
1. Insert the provided tool in the cover hole and press.
The slot is opened.
2. Pull out the tray to take it o completely.
3. Place the card.
4. Replace the tray in its location and press to close.
Inserting a SIM card
For your SIM card, slide it facing downwards in the slot 1 or 2.
Inserting a Memory card
For your Memory card, slide it facing downwards in the slot 2.
ARCHOS_50_Oxygen_Plus_book_AllLang.indd 6 27/03/2015 17:21:29
7
1
2
EN
Assembling
ARCHOS_50_Oxygen_Plus_book_AllLang.indd 7 27/03/2015 17:21:30
8
Turn ON
1. Press and hold the ON/OFF button to turn on the device.
When you turn on your device, a PIN code may be requested.
2. Type the PIN code supplied with your SIM card.
Beware of typing a wrong PIN code.
3. Select‘OK’.
Through the wizard
The rst time you start up your ARCHOS, the installation wizard will help
you set up your device:
-Language
-Date & time
-WiFi connection
-Location service options
Turn OFF
To turn o your device, press and hold the ON/OFF button, and then
select Power o > OK.
Getting started
ARCHOS_50_Oxygen_Plus_book_AllLang.indd 8 27/03/2015 17:21:30
9
EN
Sound & Notication proles
1. When the device is turned on, press
and hold the ON/OFF button.
2. Select an option.
Touch screen actions:
Tap: touch once to select or launch a menu, option, or application.
Tap and hold: tap an item and hold it for more than 2 seconds.
Drag: tap an item and move it to a new location.
Double-tap: tap an item twice quickly.
Flick: briskly scroll up, down, left, or right to move through lists or screens.
Pinch: place two of your ngers far apart, and then pinch them together.
Tip:
Your device goes in standby mode when you do not use it for a specified
period of time. To wake up your device, press the ON/OFF button.
To set the duration, go to Settings > Display > Sleep.
Silent Vibrate Sound
ARCHOS_50_Oxygen_Plus_book_AllLang.indd 9 27/03/2015 17:21:30
10
3G connection
With your SIM card, you should be connected to the Internet without
any further setup. The ARCHOS will only have signal if you are in an
area covered by your provider’s 3G network. When connected to the 3G
network, the 3G icon is displayed in the status bar.
Activating the mobile data
3G & WiFi connection
To be able to access Internet, the mobile
data icon must be activated.
1. Touch and hold the time & battery icons to
reveal the status bar.
2. Pull the white line down to display the
status dashboard.
3. Touch the status dashboard icon .
4. Touch the mobile data icon to
activate it.
Tip:
If you encounter connection problem’s, see the FAQs on www.archos.
com or contact your 3G network connection provider.
ARCHOS_50_Oxygen_Plus_book_AllLang.indd 10 27/03/2015 17:21:30
