Archos 50 Neon User manual

Table of contents

For more information, please consult the FAQs on www.archos.com.

Make sure to read them before considering any product return. As we

are often updating and improving our products, your device’s software

may have a slightly dierent appearance or modied functionality than

presented in this Quick Start Guide.

Package contents..........................................................................................................

Description of the phone...........................................................................................

Assembling......................................................................................................................

Getting started...............................................................................................................

3G & WiFi connection...................................................................................................

Google account & Contacts........................................................................................

Hints & tips with AndroidTM................................................................................

Troubleshooting.............................................................................................................

ARCHOS_50_Neon_book.indd 1 17/07/2014 12:46:14

Package Contents

Check your product box for the following items:

-ARCHOS 50 Neon

-Battery

-Headset

-Micro SIM adaptor

-USB cable

-Charger

-Quick start guide

-Warranty Legal & Safety notices

The items supplied with your device and available accessories may vary

depending on your region or service provider.

The supplied items are designed only for your device and may not be

compatible with other devices.

Unapproved accessories may cause your device to malfunction.

ARCHOS_50_Neon_book.indd 2 17/07/2014 12:46:14

27-01-2014

last modification:

AC50B OX

CONFIDENTIAL

DRAWING

Rev

scale 1:1 mm

1 2

11-02-2014

last modification:

AC50 NE

CONFIDENTIAL

DRAWING

Rev

scale 1:1 mm

1Micro-USB port

Headset jack

Loudspeaker

Webcam

Volume buttons

ON/OFF button

Microphone

Description of the phone

ARCHOS_50_Neon_book.indd 3 17/07/2014 12:46:15

11-02-2014

last modification:

AC50 NE

CONFIDENTIAL

DRAWING

Rev

scale 1:1 mm

Description of the phone

Camera

Flash

Loudspeaker

ARCHOS_50_Neon_book.indd 4 17/07/2014 12:46:15

11 12 13

11-02-2014

last modification:

AC50 NE

CONFIDENTIAL

DRAWING

Rev

scale 1:1 mm

Menu: open the list of options available on the current screen.

Home/Recent apps/Google NOW: short press to return to the Home

screen; double press to open the list of recent applications; long press to

access Google Now.

Back: return to the previous screen..

Home/Recent apps/ GoogleTM Search

Back

ARCHOS_50_Neon_book.indd 5 17/07/2014 12:46:15

Assembling

Opening

1. Use the notch to remove the back cover.

Do not bend or twist the back cover excessively. Doing so may damage

the cover.

2. Remove the battery.

Inserting SIM cards

For your 3G SIM card, slide it facing downwards in the 2G/3G slot (slot 1).

For your standard SIM card, slide it facing downwards in the 2G slot (slot 2).

Inserting a Memory card

For your Memory card, slide it facing downwards in the slot 3.

Closing

1. Align the battery’s 4 contact points with those of the phone and gently

press the battery down into place.

2. Replace the back cover clicking it back into position.

Tip:

Before using your device for the first time, charge completely its battery.

ARCHOS_50_Neon_book.indd 6 17/07/2014 12:46:15

Picture to show how to removed the bottom casing Picture to show how to insert the battery pack Picture to show the scards position

Picture to show how to remove the bottom casing Picture to show how to insert the battery pack Picture to show the scards position

Slot2

Slot3

Slot2

Picture to show how to remove the bottom casing Picture to show how to insert the battery pack Picture to show the scards position

Slot1

Slot3

Picture to show how to removed the bottom casing Picture to show how to insert the battery pack Picture to show the scards position

Assembling

Slot1 2G/3G SIM card

Slot2 2G SIM card

Slot3 Memory card

Lift

the back

cover

using the

notch

ARCHOS_50_Neon_book.indd 7 17/07/2014 12:46:16

Turn ON

1. Press and hold the ON/OFF button to turn on the device.

When you turn on your device, a PIN code may be requested.

2. Type the PIN code supplied with your SIM card.

Beware of typing a wrong PIN code.

3. Select‘OK’.

Turn OFF

To turn o your device, press and hold the ON/OFF button, and then

select Power o > OK.

Sound & Notication proles

Getting started

Tip:

Your device goes in standby mode when you do not use it for a specified

period of time. To wake up your device, press the ON/OFF button.

To set the duration, go to Settings > Display > Sleep.

1. When the device is turned on, press

and hold the ON/OFF button.

2. Select an option.

Silent Vibrate Sound

ARCHOS_50_Neon_book.indd 8 17/07/2014 12:46:16

Through the wizard

The rst time you start up your ARCHOS, the installation wizard will help

you set up your device:

-Language

-Date & time

-WiFi connection

-Location service options

Touch screen actions:

Tap: touch once to select or launch a menu, option, or application.

Tap and hold: tap an item and hold it for more than 2 seconds.

Drag: tap an item and move it to a new location.

Double-tap: tap an item twice quickly.

Flick: briskly scroll up, down, left, or right to move through lists or screens.

Pinch: place two of your ngers far apart, and then pinch them together.

ARCHOS_50_Neon_book.indd 9 17/07/2014 12:46:16

3G connection

With your 3G SIM card, you should be connected to the Internet without

any further setup. The ARCHOS will only have signal if you are in an area

covered by your 3G provider’s 3G or EDGE network. When connected to

the 3G network, the 3G icon is displayed in the status bar.

Activating the mobile data

3G & WiFi connection

To be able to access Internet, the mobile data icon must be activated.

1. Touch and hold the time & battery icons

to reveal the status bar.

2. Pull the blue line down to display the

status dashboard.

3. Touch the status dashboard icon .

4. Touch the mobile data icon to activate it.

Tip:

When you encounter connection problem’s, see the FAQs on www.

archos.com or contact your 3G network connection provider.

ARCHOS_50_Neon_book.indd 10 17/07/2014 12:46:17
