arcelik BCT603IG User manual
Built-In Hob BCT603IG
Please read this user manual first!
Dear Customer,
Thank you for purchasing this Beko product. We hope that you get the best results from your product which has been
manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and
all other accompanying documents carefully before using the product and keep it as a reference for future use. If you
handover the product to someone else, give the user manual as well. Follow all warnings and information in the user
manual.
Remember that this user manual is also applicable for several other models. Differences between models will be
identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful hints
about usage.
Warning of hazardous situations with
regard to life and property.
Warning of electric shock.
Warning of risk of fire.
Warning of hot surfaces.
3/EN
TABLE OF CONTENTS
1 Important instructions and warnings
for safety and environment 4
General safety ....................................................... 4
Electrical safety ..................................................... 4
Product safety ....................................................... 5
Intended use ......................................................... 6
Safety for children .................................................. 6
Disposing of the old product ................................... 7
Package information .............................................. 7
2 General information 8
Overview ............................................................... 8
Technical specifications ......................................... 8
3 Installation 9
Before installation .................................................. 9
Installation and connection ..................................... 9
Future Transportation ........................................... 12
4 Preparation 13
Tips for saving energy ......................................... 13
Initial use ............................................................ 13
First cleaning of the appliance .............................. 13
5 How to use the hob 14
General information about cooking ....................... 14
Using the hobs .................................................... 15
Control panel ...................................................... 16
6 Maintenance and care 21
General information ............................................. 21
Cleaning the hob ................................................. 21
7 Troubleshooting 22
4/EN
1 Important instructions and warnings for safety and
environment
This section contains safety
instructions that will help protect from
risk of personal injury or property
damage. Failure to follow these
instructions shall void any warranty.
General safety
• The appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge,
unless they have been given
supervised or instruction
concerning use of the appliance
by a responsible person for their
safely.
• Young children should be
supervised to ensure that they do
not play with the appliance.
• If the product is handed over to
someone else for personal use or
second-hand use purposes, the
user manual, product labels and
other relevant documents and
parts should be also given.
• Installation and repair procedures
must always be performed by
Authorised Service Agents. The
manufacturer shall not be held
responsible for damages arising
from procedures carried out by
unauthorised persons which may
also void the warranty. Before
installation, read the instructions
carefully.
• Do not operate the product if it is
defective or has any visible
damage.
• Ensure that the product function
knobs are switched off after every
use.
Electrical safety
• If the product has a failure, it
should not be operated unless it
is repaired by an Authorised
Service Agent. There is the risk of
electric shock!
• Only connect the product to a
grounded outlet/line with the
voltage and protection as
specified in the “Technical
specifications”. Have the
grounding installation made by a
qualified electrician while using
the product with or without a
transformer. The Manufacturer
shall not be liable for any
problems arising due to the
product not being earthed in
accordance with the local
regulations.
• Never wash the product by
spreading or pouring water onto it!
There is the risk of electric shock!
• The product must be
disconnected during installation,
5/EN
maintenance, cleaning and
repairing procedures.
• If the power connection cable for
the product is damaged, it must
be replaced by the manufacturer,
its service agent or similarly
qualified persons in order to avoid
a hazard.
• The appliance must be installed
so that it can be completely
disconnected from the mains
supply. The separation must be
provided by a switch built into the
fixed electrical installation,
according to construction
regulations.
• If the electrical supply is re-
stricted, means of all-pole dis-
connection must be accessible
and incorporated in the fixed wir-
ing in accordance with the wiring
rules.
• Any work on electrical equipment
and systems should only be
carried out by authorised and
qualified persons.
• In case of any damage, switch off
the product and disconnect it
from the mains. To do this, turn
off the fuse at home.
• Make sure that fuse rating is
compatible with the product.
Product safety
• WARNING: The appliance and its
accessible parts become hot
during use. Care should be taken
to avoid touching heating
elements. Children less than 8
years of age shall be kept away
unless continuously supervised.
• Never use the product when your
judgment or coordination is
impaired by the use of alcohol
and/or drugs.
• Be careful when using alcoholic
drinks in your dishes. Alcohol
evaporates at high temperatures
and may cause fire since it can
ignite when it comes into contact
with hot surfaces.
• Do not place any flammable
materials close to the product as
the sides may become hot during
use.
• Keep all ventilation slots clear of
obstructions.
• Do not use steam cleaners to
clean the appliance as this may
cause an electric shock.
• WARNING: Unattended cooking
on a hob with fat or oil can be
dangerous and may result in fire.
NEVER try to extinguish a fire with
water, but switch off the
appliance and then cover flame
e.g. with a lid or a fire blanket.
• CAUTION: The cooking process
has to be supervised. A short
term cooking process has to be
supervised continuously.
6/EN
• WARNING: Danger of fire: Do not
store items on the cooking
surfaces.
• WARNING: If the surface is
cracked, switch off the appliance
to avoid the possibility of electric
shock.
• In case of hotplate glass
breakage : Immediately shut off
all burners and any electrical
heating element and isolate the
appliance from the power supply.
Do not touch the appliance
surface. Do not use the appliance.
• After use, switch off the hob
element by its control and do not
rely on the pan detector.
• Metallic objects such as knives,
forks, spoons and lids should not
be placed on the hob surface
since they can get hot.
• The appliance is not intended to
be operated by means of an
external timer or separate
remote-control system.
• Vapour pressure that build up due
to the moisture on the hob
surface or at the bottom of the
pot can cause the pot to move.
Therefore, make sure that the
oven surface and bottom of the
pots are always dry.
• Hotplates are equipped with
"Induction" technology. Your
induction hob that provides both
time and money savings must be
used with pots suitable for
induction cooking; otherwise
hotplates will not operate. See.
General information about
cooking, page 14 , selecting the
pots.
• As induction hobs create a
magnetic field, they may cause
harmful impacts for people who
use devices such as insulin pump
or pacemaker.
Prevention against possible fire risk!
• Ensure all electrical connections
are secure and tight to prevent
risk of arcing.
• Do not use damaged cables or
extension cables.
• Ensure liquid or moisture is not
accessible to the electrical
connection point.
Intended use
• This product is designed for
domestic use. Commercial use
will void the guarantee.
• This appliance is for cooking
purposes only. It must not be
used for other purposes, for
example room heating.
• The manufacturer shall not be
liable for any damage caused by
improper use or handling errors.
Safety for children
• WARNING: Accessible parts will
become hot when in use. To
avoid burns and scalds children
should be kept away.
7/EN
• The packaging materials will be
dangerous for children. Keep the
packaging materials away from
children. Please dispose of all
parts of the packaging according
to environmental standards.
• Electrical products are dangerous
to children. Keep children away
from the product when it is
operating and do not allow them
to play with the product.
• Do not place any items above the
appliance that children may reach
for.
Disposing of the old product
Compliance with the WEEE Directive and
Disposing of the Waste Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic equipment
(WEEE).
This product has been manufactured with high quality
parts and materials which can be reused and are
suitable for recycling. Do not dispose of the waste
product with normal domestic and other wastes at the
end of its service life. Take it to the collection center
for the recycling of electrical and electronic equipment.
Please consult your local authorities to learn about
these collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
Package information
• Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.
8/EN
2 General information
Overview
1 Induction cooking plate
2 Assembly clamp
3 Vitroceramic surface
4 Base cover
5 Induction cooking plate
Technical specifications
Voltage / frequency
1N ~ 2
20
-
24
0 V/ 2N ~ 380
-
415 V ~ 50
Hz
Total power consumption
max. 7200 W
Fuse
32 A /
16 A x 2
Cable type / section
min.H05V2V2-F 5 x 1,5 mm
2
External dimensions (height / width / depth)
55 mm/580 mm/510 mm
Installation dimensions (width / depth)
560 (+2) mm/
490 (+2) mm
Burners
Rear left
Induction cooking plate
Dimension
180 mm
Power
1800/3000
W
Front left
Induction cooking plate
Dimension
180 mm
Power
1800/3000
W
Front right
Induction cooking plate
Dimension
145mm
Power
1500/2200
W
Rear right
Induction cooking plate
Dimension
210 mm
Power
2000/3700 W
Technical specifications may be changed
without prior notice to improve the quality of
the product.
Figures in this manual are schematic and may
not exactly match your product.
Values stated on the product labels or in the
documentation accompanying it are obtained
in laboratory conditions in accordance with
relevant standards. Depending on operational
and environmental conditions of the product,
these values may vary.
9/EN
3 Installation
Product must be installed by a qualified person in
accordance with the regulations in force. The
manufacturer shall not be held responsible for
damages arising from procedures carried out by
unauthorized persons which may also void the
warranty.
Preparation of location and electrical
installation for the product is under customer’s
responsibility.
DANGER:
The product must be installed in accordance
with all local electrical regulations.
DANGER:
Prior to installation, visually check if the
product has any defects on it. If so, do not
have it installed.
Damaged products cause risks for your safety.
Before installation
The hob is designed for installation into commercially
available work tops. A safety distance must be left
between the appliance and the kitchen walls and
furniture. See figure (values in mm).
• It can also be used in a free standing position.
Allow a minimum distance of 750 mm above the
hob surface.
• (*) If a cooker hood is to be installed above the
cooker, refer to cooker hood manufacturer'
instructions regarding installation height (min
650 mm)
• Remove packaging materials and transport locks.
• Surfaces, synthetic laminates and adhesives
used must be heat resistant (100 °C minimum).
• The worktop must be aligned and fixed
horizontally.
• Cut aperture for the hob in worktop as per
installation dimensions.
* Minimum height to extractor as recommend in
extractor instruction manual
** Minimum distance between cabinetry must be
equal to width of hob
Installation and connection
• The product must be installed in accordance with
all local electrical regulations.
Do not install the hob on places with sharp
edges or corners.
There is the risk of breaking the glass ceramic
surface!
Electrical connection
Connect the product to a grounded outlet/line
protected by a miniature circuit braker of suitable
capacity as stated in the "Technical specifications"
table. Have the grounding installation made by a
qualified electrician while using the product with or
10/EN
without a transformer. The Manufacturer shall not be
liable for any damages that will arise due to using the
product without a grounding installation in accordance
with the local regulations.
DANGER:
The product must be connected to the
mains supply only by an authorised and
qualified person. The product's warranty
period starts from date of sale or date of
delivery. Manufacturer shall not be held
responsible for damages arising from
procedures carried out by unauthorised
persons.
DANGER:
The power cable must not be clamped,
bent or
trapped or come into contact with hot parts of
the product.
A damaged power cable must be replaced by
a qualified electrician. Otherwise, there is risk
of electric shock, short circuit or fire!
• Connection must comply with national
regulations.
• The mains supply data must correspond to the
data specified on the type label of the product.
Type label is at the rear housing of the product.
• Power cable of your product must comply with
the values in "Technical specifications" table.
DANGER:
Before starting any work on the electrical
installation, disconnect the product from the
mains supply.
There is the risk of electric shock!
Connecting the power cable
While performing the wiring, you must comply
with the national/local electrical regulations
and must use the appropriate socket
outlet/line and plug for oven. In case the
product's power limits are out of current
carrying capability of plug and socket
outlet/line, the product must be connected
through fixed electrical installation directly
without using plug and socket outlet/line.
1. If it is not possible to disconnect all poles in the
supply power, a disconnection unit with at least 3
mm contact clearance (fuses, line safety switches,
contactors) must be connected and all the poles
of this disconnection unit must be adjacent to (not
above) the product in accordance with IEE
directives. Failure to obey this instruction may
cause operational problems and invalidate the
product warranty.
Additional protection by a residual current circuit
breaker is recommended.
If a cable is supplied with the product:
2. For single-phase connection, connect the wires
as identified below:
• Brown/Black cable = L (Phase)
• Blue/Grey cable = N (Neutral)
• Green/yellow cable = (E) (Ground)
» or
• Grey/Black cable = L (Phase)
• Blue/Brown cable = N (Neutral)
• Green/yellow cable = (E) (Ground)
3. For double-phase connection, connect the wires
as identified below:
• Brown cable = L1 (Phase 1)
• Black cable = L2 (Phase 2)
• Blue/Grey cable = N (Neutral)
• Green/yellow cable = (E) (Ground)
» or
• Black cable = L1 (Phase 1)
• Grey cable = L2 (Phase 2)
• Blue/Brown cable = N (Neutral)
• Green/yellow cable = (E) (Ground)
Table of contents
Other arcelik Hob manuals
arcelik
arcelik OV 644 DB User manual
arcelik
arcelik OC 608 YI User manual
arcelik
arcelik HII 64500 UFT User manual
arcelik
arcelik OCD 608 YI User manual
arcelik
arcelik OCD 623 YMI User manual
arcelik
arcelik OI 636 User manual
arcelik
arcelik OCD 672 YDWI User manual
arcelik
arcelik HII 64501 T User manual
arcelik
arcelik HIC 63401 T User manual
arcelik
arcelik HIMW 75225 S User manual
