Aquatic AISM6060SY User manual

135

SPECIFICATIONS:

The manufacturer accepts a 1/4” variance. There are variations on each tub and speciﬁcations are subject to change as we improve upon our product as required. The dimensions needed for site preparation

and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no responsibility for preparatory work. www.aquaticwhirlpools.com 800.555.5324

April 2008

Rough-In Plumbing

Measurements

GENERAL SPECIFICATIONS:

Tub Size 60” x 60” x 22”

152 cm x 152 cm x 56 cm

Bathing Well 42” long

33” wide

20” interior depth

Maximum Water Depth 15”

Shipping Weight 234 lbs. / 106 kg

Tub Weight Filled 923 lbs. / 419 kg

Tub Only Weight 173 lbs. / 78 kg

Gallons to Overow 90 gal. / 341 L

Gallons to Operate 1 bather: 65 gal. / 246 L

2 bathers: 50 gal. / 189

ELECTRICAL SPECIFICATIONS:

Pump .80 HP; 5.5 AMP; 110V

Requirement 15 AMP; 110V, separate circuit

required protected w/ Class A GFCI

SymPhONy 8

SymPhONy SErIES Model # AISM6060SY / AISM6060SYTo

8 Hydrotherapy Jets including:

- 4 Spinning Back Jets

- 4 Directional Jets

Aquatic Quality Features:

- .80 HP Run-Dry Pump

- Bath-Side On/Off Air Button

- Corner Seat

- ”Quiet Pad”Anti-Vibration Pump Mount for Quiet Pump Operation

- Heat-bent Rigid PVC Piping for Optimum Sanitary Conditions

- 4 Arm Rests

- Color Matched Trim and Jets (Select Colors)

- Durable, Easy to Clean, Lucite®Cast Acrylic Surface

- Available in 8 Standard No-Charge Colors

UL and IAPMO Listed, Factory Tested

Limited 10 Year Warranty

STANDARD EQUIPMENT: • Comfort Pillow--Oval or Rectangle

• Bolt-On Grab Bars

- White, Biscuit, Chrome, Polished Brass, Gold,

Polished Nickel, Satin Nickel or Oil Rubbed Bronze

• 1.5 kW Inline Maintenance Heater (Pump Options 1, 2)

• Lift & Turn Waste and Overow

- Chrome, Polished Brass, Gold, Satin Nickel,

Polished Nickel or Oil Rubbed Bronze

• Cable Drive Waste and Overow

- Chrome, Polished Brass, Gold, Satin Nickel,

Polished Nickel, Oil Rubbed Bronze or

Color Matched (Bone, White and Biscuit Only)

• 2-T Integral Tile Flange

• Optional Pump Location

All acrylic colors featured by Aquatic match the

industry’s leading xture manufacturers.

OPTIONAL EQUIPMENT:

Fax-On-Demand

Document # 1276

84”

18 1/2”

20”

22”

2 1/2”

18”

Two Person Bath

60”

29”

42 1/4”

42 5/16”

17 1/2”

42”

36”

14”

Deck Width 5”
