Aplex ARCHMI-8XX Series User manual

ARCHMI-8XX Series

7”, 8”, 10.1”, 12.1”, 15”, 15.6”, 17”, 18.5”, and 21.5”Intel Bay Trail E3845/N2930,

Fanless Industrial Compact Size Panel PC

User Manual

Release Date Revision

Jul. 2015 V1.1

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aple[email protected].tw URL: www.aplextec.com

ARCHMI-8XX Series User Manual

Revision History

Reversion

Date

Description

1.0

2015/03/25

Official Version

1.1

2015/07/15

Modify Motherboard Description, add Mounting

Description and BIOS OS Selection on P.67

ARCHMI-8XX Series User Manual

Warning!________________________

Avertissement!___________________

Risque de choc électrique - Ne pas faire fonctionner la machine avec son capot

arrière enlevé. Des tensions dangereuses sont élevées à l'intérieur.

Cet équipement génère, utilise et peut émettre une énergie de

radiofréquence et s'il n'est pas installé et utilisé conformément au manuel

d'instructions, il peut provoquer des interférences dans les communications

radio. Il a été testé et approuvé conforme aux limites pour un dispositif de classe

A et selon les règles de la FCC, qui sont conçues pour fournir une protection

raisonnable contre de telles interférences dans un environnement commercial. Le

fonctionnement de cet équipement dans une zone résidentielle est susceptible

de provoquer des interférences, dans ce cas l'utilisateur, à ses propres frais, devra

faire le nécessaire pour prendre toutes les mesures requises pour corriger le

problème.

Electric Shock Hazard –Do not operate the machine with its back cover removed.

There are dangerous high voltages inside.

This equipment generates, uses and can radiate radio frequency energy and

if not installed and used in accordance with the instructions manual, it may cause

interference to radio communications. It has been tested and found to comply

with the limits for a Class A computing device pursuant to FCC Rules, which are

designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a

residential area is likely to cause interference in which case the user at his own

expense will be required to take whatever measures may be required to correct

the interference.

ARCHMI-8XX Series User Manual

Caution

Risk of explosion if the battery is replaced with an incorrect type.

Batteries should be recycled where possible. Disposal of used batteries must be in

accordance with local environmental regulations.

Precaution

Risque d'explosion si la pile usagée est remplacée par une pile de type incorrect.

Les piles usagée doivent être recyclées dans la mesure du possible. La mise au

rebut des piles usagées doit resecter les réglementations locales en vigueur en

matière de protection de l'environnement.

Disclaimer

This information in this document is subject to change without notice. In no event

shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or

consequential, arising from either the use or misuse of information in this

document or in any related materials.

ARCHMI-8XX Series User Manual

Packing List

Accessories (as ticked) included in this package are:

□Adaptor

□Driver & manual CD disc

□Other.___________________(please specify)

ARCHMI-8XX Series User Manual

Safety Precautions

Follow the messages below to prevent your systems from damage:

◆Avoid your system from static electricity on all occasions.

◆Prevent electric shock. Don‘t touch any components of this card when

the card is power-on. Always disconnect power when the system is not

in use.

◆Disconnect power when you change any hardware devices. For instance,

when you connect a jumper or install any cards, a surge of power may

damage the electronic components or the whole system.

Consignes de sécurité

Suivez les messages ci-dessous pour éviter que vos systèmes contre

les dommages:

◆Éviter votre système contre l'électricité statique sur toutes les

occasions.

◆Évitez les chocs électriques. Ne pas toucher les composants de cette

carte lorsque la carte est sous tension. Toujours débrancher lorsque le

système n'est pas en cours d'utilisation.

◆Couper l'alimentation électrique lorsque vous changez tous les

périphériques matériels. Par exemple, lorsque vous connectez un

cavalier ou d'installer des cartes, une forte augmentation de la

puissance peut endommager les composants électroniques ou

l'ensemble du système.

ARCHMI-8XX Series User Manual

Table of Contents

Revision History…………………………………………………………………………………………………….1

Warning!/Avertissement!......................................................…………………………….…2

Caution/Precaution/Disclaimer……..………………………………………………………………………3

Packing List…………………………………….……………………………………………………………………..4

Safety Precautions/Consignes de sécurité………………………………….…..……………………..5

Chapter 1 Getting Started

1.1 Features………………………..………………………...…………………………..8

1.2 Specifications…………………...………………………………………………….8

1.3 Dimensions………………………....…………………………………………….11

1.4 Brief Description of ARCHMI-8XX…..….………………………….……17

1.5 Installation of HDD –7”/8”…………..…………...…………………..…..22

1.6 Installation of HDD –10.1”/15.6”/18.5”………………………………24

1.7 Installation of HDD –12.1”/15”/17”/21.5”………………….……….25

1.8 VESA Mounting…………………………………..………………………………27

1.9 Panel Mounting……………………………………..………………….……….27

Chapter 2 Hardware

2.1 Motherboard Introduction……………………...……………..………....28

2.2 Specifications…………………………..…………………………………………28

2.3 Jumpers and Connectors Location……………………………………...32

2.4 Jumpers Setting and Connectors…………………………………..……33

Chapter 3 BIOS Setup

3.1 Operations after POST Screen…...…….……...…………………………61

3.2 BIOS Setup Utility……………………………………………………………….61

3.3 Main Settings……………………………………..………………………………62

3.4 Advanced Settings……………………………………………………………...63

3.5 Chipset Settings……………………………………….………………………...71

3.6 Security Settings…………………………………………….…………………..73

3.7 Boot Settings…..………………………………………….……………………..74

3.8 Save & Exit Settings……………………………………..…………………....75

Chapter 4 Installation of Drivers

4.1 Intel (R) AtomTM SoC Chipset ………..……...………….………………78

ARCHMI-8XX Series User Manual

4.2 Intel (R) VGA Chipset……………………………………………….……......81

4.3 Intel (R) LAN Driver………..………………………………………..………...85

4.4 Realtek ALC662 HD Audio Driver Installation………………………88

4.5 USB 3.0 Driver…………………………………………………………………….90

Chapter 5 Touch Screen Installation

5.1 Windows XP/2003/Vista/WIN7 Universal Driver Installation for

PenMount 6000 Series...……………….…………………………………...93

5.2 Software Functions…………………………………………………………..103

Figures

Figure 1.1: Dimensions of ARCHMI-807(P).……………………..……………......11

Figure 1.2: Dimensions of ARCHMI-808(P).……………………..………………...11

Figure 1.3: Dimensions of ARCHMI-810(P).……………………..…………………12

Figure 1.4: Dimensions of ARCHMI-812(P).……………………..…………………12

Figure 1.5: Dimensions of ARCHMI-815(P).……………………..…………………13

Figure 1.6: Dimensions of ARCHMI-816(Resistive Touch)..……….…………13

Figure 1.7: Dimensions of ARCHMI-816(Projected Capacitive Touch)...14

Figure 1.8: Dimensions of ARCHMI-817(P)..……………………………………….14

Figure 1.9: Dimensions of ARCHMI-818(P)….……………………………………..15

Figure 1.10: Dimensions of ARCHMI-821(Resistive Touch)………………….15

Figure 1.11: Dimensions of ARCHMI-821(Projected Capacitive Touch).16

Figure 1.12: Front View of ARCHMI-8XX Series…………………………………..17

Figure 1.13: Rear View of ARCHMI-807/808……………………………………..…18

Figure 1.14: Rear View of ARCHMI-810………………………………………….….18

Figure 1.15: Rear View of ARCHMI-812………………………………………….….19

Figure 1.16: Rear View of ARCHMI-815………………………………………….….19

Figure 1.17: Rear View of ARCHMI-816……………………………………….….….20

Figure 1.18: Rear View of ARCHMI-817……………………………………….….….20

Figure 1.19: Rear View of ARCHMI-818………………………………………….….21

Figure 1.20: Rear View of ARCHMI-821………………………………………………21

Figure 1.21: ARCHMI Series VESA Mounting………………………………………27

Figure 1.22: ARCHMI Series Panel Mounting……………………………………...27

Figure 2.1: Motherboard Dimensions………………………………………….…….31

Figure 2.2: Jumpers and Connectors Location-Board Top……………….….32

Figure 2.3: Jumpers and Connectors Location-Board Bottom…………..…32

ARCHMI-8XX Series User Manual

Chapter 1 Getting Started

1.1 Features

7”/8”/10.1”/12.1”/15”/15.6”/17”/18.5”/21.5” Industrial Compact Size Panel PC

Flat front panel touch screen

Fanless design

Intel Bay Trail N2930(1.83GHz) CPU built-in/E3845(1.91GHz) for option

Onboard 2GB DDR 3L 1600 MHz/4GB(option)

9~36VDC wide-ranging power input

IP65 compliant front panel

Optional projected capacitive touchscreen support 7H anti-scratch surface

1.2 Specifications

ARCHMI-8XX Series

System

CPU

Onboard Intel Bay Trail N2930(1.83GHz )/E3845(1.91GHz) for option

Chipset

SoC

Memory

Onboard 2GB DDR 3L 1600 MHz/4GB(option)

IO Port

USB

1 x USB 2.0 type A

1 x USB 3.0 type A

Serial/Parallel

1 x RS-232 DB-9(COM2)

1 x DB-9 RS-232/422/485 (Default RS-232)(COM1)

Audio

1 x Audio Line Out

LAN

2 x GbE LAN RJ-45

Power

1 x 3-pin DC Power input terminal

1 x 2-pin connector for power on/off button

Option

(Not available for

ARCHMI-807 and

ARCHMI-808)

2 x RS-232 DB-9 + 1 x Mini-PCIe slot via TB-528C2ME1

2 x CAN bus via TB-528CAN2

2 x USB 2.0 type A Via TB-528U2

2 x USB 2.0 type A + 1 x Mini-PCIe slot + 1xRS-232 DB-9 via TB-528C1U2P1

(TB-528C1U2 for ARCHMI-810)

ARCHMI-8XX Series User Manual

Storage Space

Storage

1 x SD card slot, up to 32GB

1 x MO-297 SATA SSD bay (Easy Accessible) (for 7”/8”)

1 x 2.5" SATA HDD bay for SATA HDD (Easy Accessible)

Expansion

Expansion Slot

1 x Internal Mini-PCIe slot full size

Touch Screen –Resistive Touch Window Type

TS Control IC

PenMount 6000 on Board

Interface

USB

Light

Transmission(%)

Over 80%

Touch Screen –Projected Capacitive Type

TS Control IC

Chip on tail

Interface

USB

Light

Transmission(%)

Over 90%

Power

Power Input

9~36V/DC

Mechanical

Construction

RAL 9007

IP Rating

IP65 compliant front panel

Environmental

Operating

temperature(°C)

0~50℃

Storage

temperature(°C)

-20~60℃

Storage humidity

10 to 90% @ 40°C, non- condensing

Certification

CE / FCC Class A

Operating System Support

OS Support

Windows Embedded Compact 7, Windows 7, Windows Embedded Standard

7, Windows 8, Windows Embedded 8 Standard, Windows 8.1

Windows Embedded 8.1 Industry
