Antec Studio Series Take 3 3U User manual

Studio Series

Rackmount Enclosures

www.antec.com 1-800-22ANTEC (US) / +31 (0) 10 462-2060 (EU)

Quiet computing comes to rackmounts

Antec's Studio Series rackmount enclosures offer rock-solid, lights-out performance for professional

audio recording and anyone requiring rackmount chassis ruggedness coupled with Antec’s famous

quietness. Available in 3U and 4U sizes, these cases feature special 450-Watt, whisper-quiet power

supplies, plus 92mm and 120mm fans for cool, quiet operation. Cooling is further enhanced by a

unique segregated air-flow design. Backed by Antec's legendary 3-year warranty on all parts and

labor, our Studio Series lets you power up, tune in, and create!

Model

Chassis:

Dimension:

Weight:

Color:

Drive bays:

Motherboard:

Cooling system:

Power supply:

Expansion slots:

Front ports:

Case design:

UCC 13#:

Ta ke 3

17”(W) x 20.5”(D) x 5.2”(H)

43.18(W) x 52.07(D) x 13.21(H) cm

25.7lb/11.66kg

Black

2 external 5.25” bay

1 external, 3 internal 3.5” bay

Standard ATX (9.6”x 12”)

1 x 120mm TriCool

1 x 92mm TriCool

450W ATX12V v2.0 Power Supply

(model SP2-450SXR for US version;

SP2-450SXRP for Europe Version)

2 x USB2.0,

1 x Firewire (IEEE1394)

Ta ke 4

17”(W) x 20.5”(D) x 7”(H)

43.18(W) x 52.07(D) x 17.78(H) cm

34.6lb/15.69kg

Black

2 external 5.25” bay

2 external, 4 internal 3.5” bay

Standard ATX (9.6”x 12”)

1 x 120mm TriCool

1 x 92mm TriCool

450W ATX12V v2.0 Power Supply (model

SP-450 for US version; model SP-450P for

Europe Version)

2 x USB2.0,

1 x Firewire (IEEE1394)

0-761345-94004-70-761345-94003-0

Quiet studio rackmount with rubber grommets to absorb hard drive vibration. Selectable

fan speed allows choice of performance and quietness. Power supply is isolated from the

system to keep the system cooler.
