Antec SLK3800B User manual

User’s Manual

Manuel de l’utilisateur

Anwenderhandbuch

Manuale per l’operatore

Manual del usuario

SLK3800B

Black Super Mid Tower Case

Boîtier Super Moyen Tour Noir

Schwarz Super Mid Tower Gehaüse

Case Super Mid Tower Nero

Caja Super Mid Tower Negra

18 17 16

123467

10 11

# Description # Description

1Side Panel 10 Front USB Port

2Upper Duct 11 Front Bezel

3Flange 12 Front Door

4Lower Duct 13 Washable Air Filter

5I/O Panel 14 Plastic Feet

6Top Panel 15 Expansion Slot Cover

7External 3.5" Drive Cage 16 120mm Fan

8Internal 3.5" Drive Cage 17 Latch

9Front 120mm Fan Bracket 18 Thmbscrew

# Description # Description

1Panneau latéral 10 Port USB avant

2Conduit supérieur 11 Encadrement avant

3Bride 12 Porte avant

4Conduit inférieur 13 Filtre à air lavable

5Panneau E/S 14 Pieds en plastique

6Panneau supérieur 15 Couvercle de logements d'extension

7Panier d'unités de 3,5 pouces externes 16 Ventil ateur 120mm

8Panier d'unités de 3,5 pouces internes 17 Loquet

9Support de ventilateur avant de 120mm 18 Vis

# Beschreibung # Beschreibung

1Seitliche Abdeckung 10 Vorderer USB-Anschluss

2Obere Luftführung 11 Frontblende

3Flansch 12 Vordertür

4Untere Luftführung 13 Abwaschbarer Luftfilter

5E/A-Konsole 14 Plastikfüße

6Obere Abdeckung 15 Abdeckungfü Erweiterungssteckplatz

7Externer 3,5 Zoll-Laufwerkkäfig 16 120mm Gehäuselüfter

8Interner 3,5 Zoll-Laufwerkkäfig 17 Verriegelung

9Vordere 120 mm Lüfterklammer 18 Schraube

# Descrizione # Descrizione

1Pannello laterale 10 Porta anteriore USB

2Condotto superiore 11 Pannello anteriore

3Flangia 12 Sportello anteriore

4Condotto inferiore 13 Filtro dell'aria lavabile

5Pannello I/O 14 Piedini in plastica

6Pannello superiore 15 Coperchio dello slot di espansione

7Gabbia per unità a disco esterne da 3,5" 16 Ventola di 120mm

8Gabbia per unità a disco interne da 3,5" 17 Serratura

9Staffa per ventola anteriore da 120mm 18 Vite

# Descripción # Descripción

1Panel lateral 10 Puerto USB frontal

2Conducto superior 11 Marco frontal

3Reborde 12 Puerta frontal

4Conducto inferior 13 Filtro de aire lavable

5Panel de E/S 14 Patas de plástico

6Panel superior 15 Tapa de ranura de expansión

7Receptáculo de unidades externas de 3,5" 16 Ventilador de 120mm

8Receptáculo de unidades internas de 3,5" 17 Pestillo

9Soporte de ventilador frontal de 120 mm 18 Tornillo

Antec, Inc.

47900 Fremont Blvd.

Fremont, CA 94538

tel: 510-770-1200

fax: 510-770-1288

Antec Europe B.V.

Sydneystraat 33

3047 BP Rotterdam

The Netherlands

tel: +31 (0) 10 462-2060

fax: +31 (0) 10 437-1752

Technical Support:

US & Canada

1-800-22ANTEC

[email protected]

Europe

+31 (0) 10 462-2060

[email protected]

www.antec.com

All trademarks are the property of their respective owners.

Reproduction in whole or in part without written permission is prohibited.

Printed in China.

Version 1.0.5 04/05/2005
