AMP Lighting Deck-DesignPro Classic Operating and safety instructions

INSTALLATION & MAINTENANCE GUIDE

Help Hotline:

1-813-978-3900 • Mon-Fri 9am-6pm (EST)

www.amplighting.com

AMP®Low Voltage Landscape Lighting

AMP® Deck-DesignPro Classic

ADL-2010-4-B-XX

AMP®Deck-DesignPro Classic

ADL-2010-4-B-XX

INSTALLATION & MAINTENANCE GUIDE

www.amplighting.com

–2–

[email protected] • 813.978.3900

Product Dimensions

–3–

Important Safety Instructions: Read Before Installation

This luminaire is intended for installation in accordance with local codes

and the National Electric Code (NEC). Failure to adhere to these codes and

instructions may result in serious injury, property damage and void the

warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situations.

1. Make sure the power is turned OFF before installing or servicing this

luminaire.

2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)

or more from pool, spa or fountain.

3. This luminaire is intended to be used only with a power supply

(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.

4. Wiring connections must be made with wire connectors that are suitable

for outdoor use.

5. Position the low voltage wire and wire connector so that it is located

within 6 inches (15.2 cm) from a building structure, a luminaire or

tting.

6. The main low voltage cable is intended for shallow burial - less than 6

inches (152 mm).

7. If additional lengths of low voltage cable are required, please contact

www.amplighting.com or call 1-813-978-3900.

Important Safety Instructions

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS

Lighted lamp is HOT!

WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before replacing lamp.

2. Lamp gets HOT quickly! Contact only switch/plug when turning on.

3. Do not touch the hot lens, guard or enclosure.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may

damage lamp.

6. Do not operate the luminaire tting with a missing or damaged shield.

SAVE THESE INSTRUCTIONS

Package Contents

A. (1) Luminaire

B. (1) Lock Screws

2”

3 3/8”

2 1/4”

Pro Technique for Hiding Lead Wire

Determine the location for the xture. Drill a hole straight through the

desired mounting location and run the lead wire out the backside of

the location so that the wires are not visible from the front side. Use a

matching trim piece and cut a groove in the back of trim. Cover the lead

wires with the matching trim piece.

Pro Technique for Hiding Splice Connections

All xtures come with 4’ of lead wire enabling you to hide the splice

connections out of sight. If you must make a splice connection in view, use

an inline heat shrink style connection that is less visible than traditional twist

caps.

INSTALLATION & MAINTENANCE GUIDE

–4–

www.amplighting.com

–4–

[email protected] • 813.978.3900

–5–

INSTALLATION & MAINTENANCE GUIDE

AMP®Deck-DesignPro Classic

ADL-2010-4-B-XX

AMP®Deck-DesignPro Classic

ADL-2010-4-B-XX

Remove Lens Assembly

Install Base

Install Bulb

Install Lens Assembly

Luminaire Lens Assembly

Base Rotate the lens assembly counter

clockwise until it is stops and then

lift the lens assembly straight off.

Note: The rst time it may be

difcult because the luminaire has

a tight o-ring seal and a grease

sealant for moisture protection.

Base

Lock

Screw

Wall Anchor Attach the base onto the desired

location and secure with the lock

screws.

Note: Wall anchors are required for

certain installation conditions (e.g.

Brick wall, Concrete Wall, etc.).

Mark on the wall for wall anchors

from the holes on the base.

Remove the base and drill proper

holes on the wall and then insert

the wall anchors.

Wire Connections

Luminaire

Wire Connector

Main Supply Cable

Pigtail

Strip both leads from the luminaire

pigtail. Using two wire connectors

(sold separately), connect the leads

from the luminaire to the main supply

cable leads.

Insert the bulb with correct wattage and

type marked on the luminaire label.

CAUTION: Do not exceed maximum

wattage marked on luminaire label.

NOTE: DO NOT touch bulb with bare

hands. Use soft cloth to handle bulb.

Socket

Bulb

Push the lens assembly back onto the

base aligned with the gaps on the

base. Push hard (moisture proof xture

requires force to get air out). Once the

lens assembly is ush with the base,

rotate the lens assembly until it stops

and locks into place.

Inner Shield

Base

Gap

Install/Replace Bulb

Rotate the lens assembly and then remove it to expose the bulb and replace

it with the correct wattage and type marked on the luminaire label. And

then reinstall the lens assembly.

IMPORTANT: Halogen bulbs must be protected from moisture and dust at all

times. Always reinstall lens assembly when moved.

IS-ADL-2010-4-B-XX.pdf

Specications and product details subject to change without notice.

[email protected] • 813.978.3900

Help Hotline:

1-813-978-3900 • Mon-Fri 9am-6pm (EST)

www.amplighting.com
