Altai Technologies U1 User manual
Altai Technologies Ltd. All rights reserved
ALTAI U1
SUPER WIFI USB CLIENT
QUICK SETUP GUIDE
Version 1.0
Date: September, 2013
Altai Technologies Ltd. All rights reserved
U1 Quick Setup Guide for 1.0.0.9
TPS13-001_rev1.0
Package Contents
1. Altai U1 Super WiFi USB Client
2. USB Cable (60cm)
3. Installation CD
Minimum System Requirements
1. Desktop or laptop PC with 1GHz or faster processor and 512 MB or more RAM.
2. Available USB 2.0 port.
3. Windows: XP SP3 32-bit/64-bit, Win 7 32-bit / 64-bit.
LED Indication
Cable Connection
4. Connect micro-USB connector of the USB cable to U1.
5. Connect the other end of the USB cable to the USB port of your computer.
Because U1 gets its power from computer, no external power supply is needed.
The power LED should light up when U1 is plugged in and the PC is on.
1
2
4
Altai Technologies Ltd. All rights reserved
U1 Quick Setup Guide for 1.0.0.9
TPS13-001_rev1.0
Download and Support
Latest software and document are available at the following link
http://www.altaitechnologies.com/support_download.php
Technical Support: u1support@altaitechnologies.com
Find out the OS of Your Computer
The installation and configuration procedures are different depending on the OS of
your computer. To find out the OS of your computer, right-click “My Computer”,
choose “Properties”.
Altai Technologies Ltd. All rights reserved
U1 Quick Setup Guide for 1.0.0.9
TPS13-001_rev1.0
Please note Windows has 32 bit version and 64 bit version. You can check the version
information below:
Altai Technologies Ltd. All rights reserved
U1 Quick Setup Guide for 1.0.0.9
TPS13-001_rev1.0
Windows XP
1. Download the U1 installer for Win XP from Altai website or copy it from U1
installation CD and put it to a specific directory. In this case, it is put on the
desktop.
2. Connect U1 to the computer and you will see the following popped up window,
please choose “No, not this time” and click “Next”.
Altai Technologies Ltd. All rights reserved
U1 Quick Setup Guide for 1.0.0.9
TPS13-001_rev1.0
3. Now the system will try to locate the U1 driver folder at your selected directory.
Please make sure the directory is correct and click “OK”.
4. You will find the installation window below:
Note: If it pops up the following “Software Installation” warning window during
installation, please click “Continue Anyway”.
Altai Technologies Ltd. All rights reserved
U1 Quick Setup Guide for 1.0.0.9
TPS13-001_rev1.0
5. Please wait until the installation is finished. The successful page will be shown as
following.
6. Now U1 driver is successfully installed and you can use it to connect to wireless
network the same as you are using your laptop integrated wireless card.
Altai Technologies Ltd. All rights reserved
U1 Quick Setup Guide for 1.0.0.9
TPS13-001_rev1.0
Altai Technologies Ltd. All rights reserved
U1 Quick Setup Guide for 1.0.0.9
TPS13-001_rev1.0
Windows 7 32 bit / 64 bit
Part A. New installation of U1 driver
1. Download the U1 installer or copy the installer from U1 installation CD according
to the system you are using and put it to a specific directory. In this document, it is
put on the desktop.
2. Connect U1 to computer and it will show “Installing device driver software” on
the bottom right corner. Please wait until it shows “Device driver software was not
successfully installed”. (We will install the driver manually in the following steps)
3. Please right click on the “Computer” icon on the desktop (If it is not there, please
go to Start>>Computer) and click “Properties”.
4. Please choose the “Device Manager” on the top left corner of the popped up
window.
5. Under the instance of “Other devices”, there is one device named “UB91C”. Right
click on it and choose “Update Driver Software”. In the popped up windown,
choose “Browse my computer for driver software”. The next step is to choose the
correct directory of the driver folder. (In this case, it is the desktop) and click OK.
Altai Technologies Ltd. All rights reserved
U1 Quick Setup Guide for 1.0.0.9
TPS13-001_rev1.0
6. Please wait for a while before you see the following successful page.
