AKG IVM 4 User manual
IVM 4
Audio Routing
SST 4 / SPR 4
© AKG Acoustics 2008
2
IVM 4 – AUDIO ROUTING
SST 4:
•Comp: Stereo-Linked Com ressor
•Lim: Technical limiter – always necessary
SPR 4:
•Protection Limiter: Can be turned off
•Volume and Balance can be adjusted
STEREO MODE
3
IVM 4 – AUDIO ROUTING
SST 4:
•Comp: Com ressor work only for Channel 1
•Room: Room-Simulation is turned OFF -> MONO TRANSMISSION!
SPR 4:
•Protection Limiter: Can be turned off
•Volume can be adjusted
MONO MODE – no Room Simulation
4
IVM 4 – AUDIO ROUTING
SST 4:
•Comp: Com ressor work only for Channel 1
•Room: Room-Simulation is turned ON -> Normal Stereo Transmission! (Digital MPX)
SPR 4:
•Protection Limiter: Can be turned off
•Volume can be adjusted
MONO MODE – wit Room Simulation
5
IVM 4 – AUDIO ROUTING
SST 4:
•Comp: Com ressor work only for Channel 1
•Lim: Technical limiter – always necessary
SPR 4:
•Protection Limiter: Can be turned off
•Balance adjust the relative level between Channel 1and 2
•General Volume can be adjusted
Change to DUAL Mode from within the BALANCE menu - change from ‚l r‘ to ‚Ch‘ (See Owner Manual cha ter 4.2.4)
DUAL MODE
