Airthereal LF500M User manual
AROMA
DIFFUSER
USER MANUAL
MODEL: LF500M
Please read the manual carefully before
use and keep it for future reference.
1
SAFETY PRECAUTIONS
• When the room temperature is below 32°F / 0°C, please empty the water
tank. If the water is allowed to turn to ice it can damage the components.
• Please use purified or distilled water so that your atomizer will not be
damaged due to impurities in the water. If you use normal tap water you
may notice a white buildup of calcium or lime in the diffuser.
• The maximum water volume is 16.9 oz/500 ml. Exceeding the max capacity
line will affect the atomization effect or cause water leakage and damage to
the machine.
• Do not let water splash into the base to avoid damaging the internal parts.
• After use you must pour out the remaining water in the water tank to prevent
damage to the atomizer. Do not leave water sitting in the tank for several
days without use.
• When cleaning or adding water to the device, always remove the AC adaptor
from the outlet. Do not insert or remove the AC adaptor with wet hands.
Doing so may cause electric shock or injury.
• Do not replace the power cord without authorization.
• In case of abnormality, do not attempt to disassemble or repair the device
by yourself. Doing so could cause fire, electric shock, injury, or malfunction.
Please stop operation and send an email to support for help.
WARNING Cancer and Reproductive Harm
www.p65warnings.ca.gov
PARTS
Top cover
Water tank
Light
Base Contorl panel
Power adaptor
Note: The accessories in the package are exclusively used for the product.
The appearance and quantity may be different for different batches. Please
contact support if you have any questions.
2
Model
Rated Voltage
Rated power
Water Tank Capacity
Mist Output
Timer Setting
Weight
Dimensions
LF500M
DC 24V 1.5A
12W
500 ml / 16.9 oz
35 - 65 ml/hr
1 - 8 hours
2.0 lbs
9.4 x 3.9 x 6.3 in
SPECIFICATIONS
OPERATION
1. Remove the top cover.
2. Add water to the max fill line.
Add 2-5 drops of scented essential
oil directly to the tank if you wish.
Note:
• The maximum water volume is
16.9 oz/500 ml. Exceeding the
max capacity line will affect the
atomization effect or cause water
leakage and damage to the
machine.
• Please use purified or distilled
water so that your atomizer will
not be damaged due to impurities
in the water. If you use normal tap
water you may notice a white
buildup of calcium or lime in the
diffuser. While not harmful, these
deposits may cause a white powder
to form when the mist dries or inside
the machine. These deposits can be
cleaned with distilled white vinegar.
Add water position
Max water level
3
3. Place the top cover back onto the diffuser.
4. Insert the power adapter cord.
5. Press the power button and you will hear a beep sound.
The default settings are as follows:
Atomization level: 2 (high)
Brightness: medium
Lighting effect: full bright
4
Function selection
Switch
Timer
Light brightness
Lighting effect
Mist level
Low water icon
CONTROL
Notes:
• After powering on, there will be a beep sound
• There will be a beep each time you press a button.
• When there is no water in the tank you will hear 2 beeps over 5 seconds
and the diffuser will automatically power down. The low water icon will
also illuminate
• When the timer is up you will hear a long beep sound before the diffuser
automatically shuts down.
Power on / Power off
1-8 hours
1: Low
2: Medium
3: High
• Full light
• Breathing light
• Flashing light
1: Low (soft flame effect)
2: High (violent flame effect)
Lights out (sleep mode)
Unit automatically powers off
5
CLEANING INSTRUCTIONS
1. Drain the water remaining in the water tank.
Ensure the air outlet side is facing up during
draining to avoid moisture getting inside the
unit.
2. Do not use any benzene, paint thinner, alcohol,
or other types of chemicals during cleaning. Doing
so may cause damage to the machinery.
3. If using detergent, always use mild kitchen detergent. Chlorine, acid,
and enzyme-type detergents remaining inside pose the danger of emitting
noxious gasses. Distilled white vinegar is recommended for cleaning.
4. If you do not intend to use the product for an extended period of time,
clean it and dry it thoroughly before storage. .
Pouring
Side
TROUBLESHOOTING
The power-on indicator
does not light up and
the diffuser cannot be
started
The indicator light is on,
but there is no mist
produced
The humidifier emits a
weird smell
No power
The water tank is short
of water or has too little
water, the low water icon
will illuminate
Too much water
There is scale in the
water tank, the added
water has impurities, or
the water has been left
in the tank for too long
Reconnect the power
adapter and try again
Add purified water to
the tank
Pour water lower than
the max capacity line.
Exceeding the max
capacity line will affect
the atomization effect
Remove the lid of the
water tank and place it
in a cool place for more
than 12 hours to ventilate.
Clean the water tank
with white vinegar and
refill with pure water
Symptom Possible Causes Approach
6
LIMITED WARRANTY
We provide a 1-year warranty.For more information please visit
www.airthereal.com/warranty.
• What's covered?
Defects due to faulty materials and/or workmanship of the product.
• What's not covered?
1. Damage caused by the owner when attempting to fix or altering the
product by himself or herself.
2. Damage caused by misuse, abuse, neglect, alterations or unauthorized
repair.
3. Natural depreciation.
• Warranty Period
Warranty becomes effective from the date of original purchase and will
last for 1 year.
• Who's covered?
This limited warranty is only effective for the original purchaser, it is
non-transferable.
• How to request warranty services?
To obtain the benefit of this warranty, please email [email protected].
Our customer service will address your issue as soon as possible!
Symptom Possible Causes Approach
Too little mist produced
The diffuser is too noisy
If the above methods cannot be improved, please consult the customer service
hotline for assistance
There is dirt on the
atomizing film or the
water in the water tank
has been left for too long
Too much water
Too little water
Clean the water tank
and add pure water
Pour water lower than
the max capacity line.
Exceeding the max
capacity line will affect
the atomization effect
Add water to the tank
Always here to help you
www.airthereal.com
Produced for: West Ryder Technology LLC
2330 Paseo Del Prado STE C304 Las Vegas, NV 89102 USA
