Aiper Seagull 3000 User manual
Seagull 3000
User Manual
ROBOTIC POOL CLEANER
Thank you for choosing Aiper robotic pool cleaner.
You have joined millions of people to enjoy the convenience of
robotic pool cleaning.
This user manual helps you to keep your robot performing at its
best. Please take a few moments to read through it.
If you have any questions, please contact our customer service
for assistance or visit www.aiper.com for more information.
Aiper Customer Service:
US Toll Free: 1-866-850-0666
Email: service@aiper.com
Facebook: @AiperOfficial
CONTENTS
1
2
2
3
3
3
4
5
7
8
9
10
11
13
14
-------------------------------
-------------------------------------
-----------------------------------------
-------------------------------------
------------------------------------------
-----------------------
-----------------------------
-----------------------------------
---------------------------------------
---------------------------------
----------------------------------------
-------------------------------------
---------------
--------
-------------
Important Precautions
1. Introduction
2. Structure
3. Specifications
4. Operations
Important Notes
4.1 Operation Panel Instructions
4.2 Panel Light Indicators
4.3 App
4.4 Charging
4.5 Filter Cleaning
4.6 Installation of Foam Floating Blocks
5. Frequently Asked Questions (FAQ)
6. Packing List
7. Warranty
1
Important Precautions
1. Read the manual carefully, and use the cleaner according to the
manual. We are not liable for any losses or injuries caused by
improper use.
2. Only use the accessories recommended or sold by the manufacturer.
3. Do not allow children to ride on the cleaner or play with it.
4. Use the original and authorized power adapter only.
5. The adapter cord should only be replaced by a qualified electrician.
6. Do not turn on the cleaner when it is out of water.
7. The charging adapter must be connected to a leakage protected and
earthed socket when charging.
8. Do not operate the cleaner when people or animals are in the pool.
9. Always clean and wash the filter tray after using.
10. Turn off the cleaner when maintaining, cleaning or when it is not in
use.
11. The cleaner should be stored in a cool and ventilated place, away
from direct sunshine.
12. While charging, the cleaner should be kept in a cool place, and not
covered with anything to prevent the damage of internal electrical
components caused by overheating.
13. Only certified professionals can disassemble the sealed driving kit
of the cleaner.
14. Do not operate the cleaner while pool filter is running.
15. Oil sealing for motor contains grease, which may cause water
pollution if grease leaks.
2
1. Introduction
The robotic pool cleaner Seagull 3000 is a new type of highly efficient
and energy-saving swimming pool cleaning robot. It cleans the pool
walls and floor automatically without replacing the pool water. It's totally
environment-friendly.
Read this user manual carefully before use.
2. Structure
16. Due to the limitation of battery capacity, the cleaner is only suitable
for swimming pools with size up to 3229 sq.ft (300㎡); otherwise
the clean ing effect will be affected.
17. If the cleaner needs to be stored for a long period of time, it should
be charged every three months to maintain battery life between
40%-60%. Please use the original and authorized power adapter
only. If the cleaner is not charged for a long time, the battery voltage
will be lower than the overdischarge protection voltage due to the
self-discharge of the battery, which may cause fatal damage.
18. Do not use or store the cleaner near any heat source.
19. Do not pierce the shell of the cleaner with nails or other sharp
objects. Do not hammer, impact, or throw the cleaner.
20. Make sure the charging socket is dried before charging.
PVC Roller
Brushes
Filter
Baskets
Top Cover
Handle
Floating Blocks
Floating Battery
Battery
Cable
3
1. Put the cleaner into or lift it out of the pool with the bottom towards
the wall to avoid any possible scratches to the pool. Hold the top
3. Specifications
1. Model
2. Rated Working Voltage
3. Power
4. Run Time
5. Charger Input
6. Charger Output
7. Battery Capacity
8. Charging Time
9. Pool Size
10. Filter Capacity
Seagull 3000
25.9V
120W
110~120 Mins
100~240V, 50/60Hz
30V/2A
7800mAh
4~5 Hours
Up to 3229sq.ft (300㎡)
71GPM(267LPM)
11. Filter Density
12. Moving Speed
13. Waterproof Grade
14. Pool Water Temperature
15. Pool Water PH Value
180μm
32.8ft/min (10m/min)
IPX8
50°F~95°F (10℃~35℃)
7.0~7.4
4. Operations
Important Notes:
17. Max Water Depth
41°F~95°F (5℃~35℃)
16.93(L)x15.35(W)x8.66(H) inches
430(L)x390(W)x220(H) mm
8.2ft (2.5m)
19. Storage Temperature
18. Product Size
-4°F~113°F (-20℃~45℃),
RH≦75%
16. Charging Environment
Temperature
4
handle for putting it into the pool, then power on the cleaner (Make
sure that the trapped air inside is emptied till no more air bubbles
come out before powering on).
2. The cleaner will automatically sub-stop alongside the pool wall once
the battery is low or completing a working cycle. Hold the top handle
for removing it from the pool for charging. NEVER pull the cable.
Notes:
1. The cleaner will not climb walls if the battery level is under 15%;
2. It is better to take out the filter trays first and then remove the
cleaner from the pool.
4.1 Operation Panel Instructions
Instructions for Buttons and Indicators
ALL
WALL
FLOOR
MODE START
ON
OFF
5
6
7
1
2
34
5
4.2 Panel Light Indicators
Sign Instruction DescriptionItem
Description Status Indicators
ALL WALL FLOOR Buzzer
Item
ON Power ON Press ON button, the cleaner
is powered on.
OFF
START
Power OFF
Start to Work
Press OFF button, the cleaner
is powered off.
Press this button, the cleaner
will start to work automatically
according to the selected
cleaning mode, and the
corresponding mode indicator
will start to flash with the
frequency of once per second.
MODE
ALL
ALL+FLOOR
Once floor
once wall ON
ON
ON
ON
OFF
OFF OFF “Beep”
“Beep”
“Beep”
“Beep”
OFF
OFF OFF
OFFON
Wall cleaning
only
Floor cleaning
only
There times
floor once
wall
FLOOR
WALL
Cleaning
Mode
Selection
The user can select the
corresponding cleaning mode
as required.
To clean pool floor, walls and
water line (once floor once wall)
To clean the pool walls only
To clean the pool floor only
To clean the pool floor three
times and pool wall once
1
2
3
4
1
2
3
4
Power on
6
Once floor
once wall Flash once
per second OFF OFF “Beep”5
OFF
Wall
cleaning Flash once
per second OFF “Beep”6
OFF
Floor
cleaning
Flash
once
per
second
OFF “Beep”
Flash once
per second
There times
floor once
wall
Flash
once
per
second
OFF “Beep”
7
8
→Flash
once per
second
Working
Completed
→Flash
once
per
second
OFF “Beep”9
→Flash
once per
0.2s
←Flash
once per
0.2s
Flash once
per 0.2s
Forward
Backward
Left
→Flash
once
per
0.2s
←Flash
once
per
0.2s
→Flash
once per
0.2s
←Flash
once per
0.2s
ON ON
“Beep”
“Beep”
“Beep”
10
11
12
Auto
Running
Remote
Steering
ONRight Flash
once
per 0.2s
ON “Beep”
13
Flash fast
once per
0.1s OFF Flash fast
once per 0.1s
Low
battery
17
Flash fast
once per
0.1s
Flash fast
once per
0.1s
Overload
Motor 1
overload
Flash fast
once per 0.1s
Flash fast
once per
0.1s
Flash fast
once per
0.1s OFF
OFF Flash fast
once per
0.1s
Flash fast
once per 0.1s
14
15
Motor 2
overload
16
Abnormal
Indications
