AG Neovo SX-15 User manual
NeoV™ Optical Glass - e most
trusted hard glass protection available.
Only on AG Neovo displays
www.agneovo.com
A sharp surveillance display for 24/7
security environments that demand
durability and long-term performance,
but where space is at a premium.
e SX-15 is a highly durable 15” display that is perfect for tight
quarters. In multi-user security environments, a strong metal casing
and NeoV™ Optical Glass protect the display from day-to-day use
and other incidental damage. e SX-15 also provides important
features such as looping video inputs for multiple connections,
Anti-Burn-in™ technology, Mask Mode and a quick signal-switching
time that are essential for security and surveillance environments.
> NeoV™ Optical Glass
> Distinctive bezel design and durable metal casing
> Anti-Burn-in™ technology to prevent image sticking
> Mask Mode to reduce image distortion
> Quick signal-switching time (≤ 0.8 sec.)
> Real-time image display with no time lag
> Automatic recovery of video settings aer power interruptions
> Video looping output supports auto termination
> Supports NTSC/PAL/SECAM video systems
> Auto-adjustment when VGA input is selected
> Kensington® security socket
> VESA standardwall mount
> Rigorous screening of the components for mission-critical 24/7 applications
SX-15
REACH
All specications are subject to change without prior notice.
Copyright © 2013 AG Neovo. All rights reserved. e name AG Neovo is a trademark of AIC.
All other trademarks are the property of their respective owners.
P/C: SX15G0_SX5G1 Version 25.3, 20130701
Specications SX-15
Panel Panel Type
Panel Size
Max. Resolution
Pixel Pitch
Brightness
Contrast Ratio
Viewing Angle (H/V)
Display Colour
Response Time
TFT LCD
15.0” (381 mm)
XGA 1024 x 768
0.297 mm
320 cd/m2 (Typical)
500:1 (Typical)
140°/125° (Typical)
16.7M
4 ms (GTG)
Horizontal
Resolution
TV Lines 430TVL (NTSC), 450TVL(PAL)
Frequency (H/V) H: 30 kHz - 60 kHz
V: 56 Hz - 75 Hz
Input Analogue
Digital
BNC Security
15-Pin D-Sub
24-Pin DVI-D
BNC Connector
Input Signal Analogue
Digital
Composite
RGB H.V Sync
TMDS
NTSC/PAL/SECAM
Output Connector BNC Security BNC Connector
Power Power Supply
Power Requirements
Consumption
External
DC 12V
< 36 W (On)
< 2 W (Off)
NeoV™
Optical Glass
Thickness
Reection Rate
Transmission Rate
Coating Hardness
3.0 mm (0.12”)
< 1%
> 96%
> 9H
Plug & Play VESA DCC 2B, DCC/CI
Operating
Conditions
Temperature
Humidity
0 °C ~ 40 °C
10% ~ 90%
Storage
Conditions
Temperature
Humidity
-20 °C ~ +60 °C
5% ~ 95%
Mounting VESA FPMPMI Yes (100 x 100mm)
Tilt Tilt 0° ~ +20°
Dimensions Product
(W x H x D)
Packaging
(W x H x D)
380 x 359 x 155 mm
(15.0” x 14.1” x 6.1”)
445 x 477 x 217 mm
(17.5” x 18.8” x 8.5”)
Weight Product Weight
Packaged Product Weight
4.8 kg ( 10.6 lbs)
7.0 kg (15.4 lbs)
Regulation
Approval
Certications &
Compliance
TUV/Bauart, CB, FCC, CE,
CCC, CEL, GOST-R, WEEE,
RoHS, Vista/Basic, REACH
Accessories Supplied CD ROM (user manual and
drivers), power cord, power
adaptor, 15-Pin D-Sub cable,
24-Pin DVI-D cable, CVBS BNC
connector cable
SX-15
Looping BNC video connector for multiple
display connections
NeoV™ Optical Glass for hard glass protection
and strong metal casing for secure mounting
Specically designed and tested for commercial
video security applications
Anti-Burn-in™ technology prevents image sticking
