AG Neovo C-19P User manual
www.agneovo.com
C-19P
An excellent and affordable 19” display
for home and ofce environments
where quality, reliability and price are
important considerations.
e valuable C-19P delivers the high image clarity and outstanding
display performance that is well suited for the demands of modern
oce and home applications. Featuring 1,000:1 typical contrast
ratio and built-in speakers, the slim modern design and convenient
VESA compatible wall mounts make the C-19P a perfect value
choice for home and oce environments.
> LED-backlit technology
> Slim and sleek design
> Economical and durable concern
> Fast 3ms response time
> Crisp 1,000:1 typical contrast ratio
> Built-in speakers (3W x 2)
> Tilt from -5 ° to +20 ° for optimal viewing
> Kensington® security socket
> VESA standard wall mount
> WEEE, RoHS, REACH certied
REACH
All specications are subject to change without prior notice.
Copyright © 2014 AG Neovo. All rights reserved. e name AG Neovo is a trademark of AIC.
All other trademarks are the property of their respective owners.
P/C: C19P00/C19PA0 Version 1.2 20140514
Sleek design with anti-glare display panel for
superior viewing comfort
VESA standard wall mount allows for secure
mounting
Built-in speakers provide easy access to multimedia
applications
C-19P
Tilt from -5 ° to +20 ° for optimal viewing
Specications C-19P
Panel Panel Type
Panel Size
Max. Resolution
Pixel Pitch
Brightness
Contrast Ratio
Surface Treatments
Viewing Angle (H/V)
Display Colour
Response Time
LED-Backlit TFT LCD
19.0” (482 mm)
SXGA 1280 x 1024
0.294 mm
250cd/m2 (Typical)
1,000:1 (Typical)
Hard Coating (3H),
Anti-glare treatment
170°/170° (Typical)
16.7M
3ms (GTG)
Frequency (H/V) H: 30 kHz - 82 kHz
V: 56 Hz - 75 Hz
Input Analogue
Digital
15-Pin D-Sub
24-Pin DVI-D
Audio Audio In
Speaker
1 x Stereo audio in for PC
(audio jack, 3.5ø)
3W x 2
Power Power Supply
Power Requirements
Consumption
Internal
AC 100 - 240 V, 50 - 60 Hz
< 18 W (On)
< 0.5 W (Stand-by)
< 0.5 W (Off)
Plug & Play VESA DCC 2B
Operating
Conditions
Temperature
Humidity
0 °C ~ 40 °C
10% ~ 85%
Storage
Conditions
Temperature
Humidity
-25 °C ~ 55 °C
10% ~ 85%
Mounting VESA FPMPMI Yes (100 x 100mm)
Tilt Tilt -5° ~ +20°
Dimensions Product
(W x H x D)
Packaging
(W x H x D)
422 x 388 x 195 mm
(16.6” x 15.3” x 7.7”)
478 x 403 x 140 mm
(18.8” x 15.9” x 5.5”)
Weight Product Weight
Packaged Product Weight
3.9 kg (8.6 lbs)
5.8 kg (12.8 lbs)
Regulation
Approval
Certications &
Compliance
FCC, CB, CE, GOST-R, WEEE,
RoHS, REACH
Accessories Supplied User manual, 15-Pin D-Sub
cable, audio cable, AC power
cord
