L-W24

A 24” Full High Deﬁnition LED display

with ultrahigh 20,000,000:1 contrast

ratio and the most efﬁcient power

consumption expertise.

AG Neovo’s rst LED backlight display comes from the design

of energy saving by LED application. Featuring Full HD 1920

x 1080 resolution, the L-W24 oers better clarity. Dual PC and

HDMI connectivity coupled with built-in speakers allows complex

multimedia combination and integration, perfectly for home and

oce users who care about convenience and quality.

> 24” widescreen LED display

> LED backlight for energy saving and environmental consciousness

> 1920 x 1080 Full HD resolution

> Slim housing design and widescreen format

> Excellent clarity with ultrahigh 20,000,000:1 dynamic contrast ratio

> Superior colour performance and colour contrast

> HDMI input for Full HD connectivity with multimedia devices

> Built-in 2W x 2 speakers

> Energy eciency

> VESA mount standard

REACH

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: LW2400 Version 1.0, 20110110

Speciﬁcations L-W24

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Surface Treatments

Viewing Angle (H/V)

Display Colour

Response Time

LED

24.0” (610 mm)

Full HD 1920 x 1080

0.277 mm

250cd/m2 (Typical)

20,000,000:1 (DCR)

Hard Coating (3H),

Anti-glare treatment

160°/160° (Typical)

16.7M

3ms (GTG)

Frequency (H/V) H: 30kHz – 83kHz

V: 55Hz – 75Hz

Max. Pixel Clock 170 MHz

Input Analogue

Digital

HDMI

15-Pin D-Sub

24-Pin DVI-D

HDMI

Audio Audio In

Speaker

3.5mm Audio Line-in

2W x 2

Power AC-DC Adaptor

Power

Consumption

Internal

AC 100 – 240 V, 50-60 Hz

< 33W (On)

< 0.5W (Stand-by)

< 0.5W (Off)

Plug & Play VESA DCC 2B

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 85%

Storage

Conditions

Temperature

Humidity

-25 °C ~ 55 °C

10% ~ 85%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt -4° ~ +18°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

566 x 395 x 190 mm

(22.3” x 15.6” x 7.5”)

622 x 423 x 130 mm

(24.5” x 16.7” x 5.1”)

Weight Product Weight

Packaged Product Weight

4.3 kg (9.5 lbs)

5.7 kg (12.5 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

FCC, CB, CE, WEEE, RoHS,

REACH

Accessories Supplied CD ROM (user manual), 15-Pin

D-Sub cable, audio cable, AC

power cord

L-W24

e slim and glossy frame represents a

stylish design and also save desktop space

Built-in HDMI input makes the L-W24 easy to

be paired with Full HD multimedia advices

VESA standard wall mount allows for secure

mounting almost anywhere
