AEG LP 2270 F User manual

LP 2270 F EN User manual 2

DE Benutzerinformation 33

CONTENTS

1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3. TECHNICAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

4. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

5. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

6. PROGRAMMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

7. CONSUMPTION VALUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

8. BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

9. USING THE APPLIANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

10. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

11. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

12. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

13. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable

performance for many years, with innovative technologies that help make life simpler –

features you might not find on ordinary appliances. Please spend a few minutes reading to get

the very best from it.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com

www.aeg.com/productregistration

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts.

When contacting Service, ensure that you have the following data available.

The information can be found on the rating plate. Model, PNC, Serial Number.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

2www.aeg.com

1. SAFETY INFORMATION

Before the installation and use of the appliance, careful-

ly read the supplied instructions. The manufacturer is

not responsible if an incorrect installation and use cau-

ses injuries and damages. Always keep the instructions

with the appliance for future reference.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

• Do not let children play with the appliance.

• Keep all packaging away from children.

• Keep all detergents away from children.

• Keep children and pets away from the appliance door

when it is open.

• If the appliance has a child safety device, we recom-

mend you activate it.

• Cleaning and user maintenance shall not be made by

children without supervision.

1.2 General Safety

• Before maintenance, deactivate the appliance and

disconnect the mains plug from the mains socket.

• Do not change the specification of this appliance.

• Obey the maximum load volume of 7 kg (refer to the

“Programme chart” chapter).

ENGLISH 3

• If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly quali-

fied persons in order to avoid a hazard.

• The operating water pressure (minimum and maxi-

mum) must be between 0,5 bar (0,05 MPa) and 8 bar

(0,8 MPa)

• The ventilation openings in the base (if applicable)

must not be obstructed by a carpet.

• The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging and the

transit bolts.

• Keep the transit bolts. When you

move the appliance again you must

block the drum.

• Do not install or use a damaged appli-

ance.

• Do not install or use the appliance

where the temperature is less than 0

°C or where it is exposed to the

weather.

• Obey the installation instruction sup-

plied with the appliance.

• Make sure that the floor where you in-

stall the appliance is flat, stable, heat

resistant and clean.

• Do not install the appliance where the

appliance door can not be fully

opened.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Make sure that there is air circulation

between the appliance and the floor.

• Adjust the feet to have the necessary

space between the appliance and the

carpet.

Electrical connection

WARNING!

Risk of fire and electrical shock.

• The appliance must be earthed.

• Make sure that the electrical informa-

tion on the rating plate agrees with

the power supply. If not, contact an

electrician.

• Always use a correctly installed shock-

proof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

mains plug and to the mains cable.

Should the appliance power supply

cable need to be replaced, this must

be carried out by our Service Centre.

• Connect the mains plug to the mains

socket only at the end of the installa-

tion. Make sure that there is access to

the mains plug after the installation.

• Do not pull the mains cable to discon-

nect the appliance. Always pull the

mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

• This appliance complies with the

E.E.C. Directives.

4www.aeg.com

Water connection

• Make sure not to cause damage to the

water hoses.

• The appliance is to be connected to

the water mains using the new sup-

plied hose-sets. Old hose sets must

not be reused.

• Before you connect the appliance to

new pipes or pipes not used for a long

time, let the water flow until it is clean.

• The first time you use the appliance,

make sure that there is no leakage.

2.2 Use

WARNING!

Risk of injury, electrical shock,

fire, burns or damage to the ap-

pliance.

• Use this appliance in a household en-

vironment.

• Do not change the specification of this

appliance.

• Obey the safety instructions on the

detergent packaging.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

• Do not touch the glass of the door

while a programme operates. The

glass can be hot.

• Make sure that you remove all metal

objects from the laundry.

• Do not put a container to collect pos-

sible water leakage under the appli-

ance. Contact the Service to ensure

which accessories can be used.

2.3 Care and Cleaning

WARNING!

Risk of injury or damage to the

appliance.

• Before maintenance, deactivate the

appliance and disconnect the mains

plug from the mains socket.

• Do not use water spray and steam to

clean the appliance.

• Clean the appliance with a moist soft

cloth. Only use neutral detergents. Do

not use abrasive products, abrasive

cleaning pads, solvents or metal ob-

jects.

2.4 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

3. TECHNICAL INFORMATION

Dimensions Width / Height / Depth 600 / 850 / 605 mm

Total depth 640 mm

Electrical connection: Voltage

Overall power

Fuse

Frequency

230 V

2200 W

10 A

50 Hz

Level of protection against ingress of solid particles

and moisture ensured by the protective cover, ex-

cept where the low voltage equipment has no pro-

tection against moisture

IPX4

ENGLISH 5

Water supply pressure Minimum 0,5 bar (0,05 MPa)

Maximum 8 bar (0,8 MPa)

Water supply

Cold water

Maximum load Cotton 7 kg

Spin speed Maximum 1200 rpm

1) Connect the water inlet hose to a water tap with a 3/4'' thread.

4. PRODUCT DESCRIPTION

1 2 3 8 9

1Worktop

2Detergent dispenser

3Control panel

4Door handle

5Rating plate

6Drain pump

7Feet for the appliance level

8Water drain hose

9Water inlet valve

10 Mains cable

11 Transit bolts

12 Feet for the appliance level

6www.aeg.com

4.1 Accessories

1 2

1Spanner

To remove the transit bolts.

2Plastic caps

To close the holes on the rear side

of the cabinet after the removal of

the transit bolts.

3Anti-flood inlet hose

To prevent possible leakage

4Plastic hose guide

To connect the drain hose on the

edge of a sink.

5. CONTROL PANEL

1 2 3

45678910

Ein/Aus

Schleudern/Pumpen

Essorage/Vidange

Spülen

Rinçage

Gardinen

Rideaux

Schnell Intensiv

Intensif

20 Min. - 3 Kg

Super Eco

Jeans

Baumwolle Eco

Coton Eco

Marche/Arrêt

Koch/Bunt

Blanc/Couleurs

+Vorwäsche

+Prélavage

+Vorwäsche

+Prélavage

Extra Leise

Extra Silence

Pflegeleicht

Synthétiques

Leichtbügeln

Repassage Facile

Feinwäsche

Délicats

Wolle/Seide

Laine/Soie

Temp.

Start/Pause

Départ/Pause

Zeitvorwahl

Départ

Différé

Gain de

Temps

Flecken Extra

Spülen

Rinçage +

Taches

U./Min.

T/Min.

Zeit Sparen

1On/Off button (Ein/Aus — Marche/

Arrêt)

2Programme knob

3Display

4Start Pause button (Start/Pause —

Départ/Pause)

5Delay start button (Zeitvorwahl —

Départ Différé)

6Time saving button (Zeit Sparen —

Gain de Temps)

7Extra rinse button (Extra Spülen —

Rinçage+)

8Stain button (Flecken — Taches)

9Spin reduction button (U./Min. — T/

min.)

10 Temperature button (Temp.)

5.1 On Off button

Press this button to activate or deacti-

vate the appliance. A tune sounds when

the appliance is activated.

The AUTO Stand-by function automati-

cally deactivates the appliance to de-

crease the energy consumption when:

• You do not use the appliance for 5 mi-

nutes before you press button

– All settings are cancelled.

–Press button

to activate the ap-

pliance again.

ENGLISH 7

– Set again the washing programme

and all possible options.

• After 5 minutes from the end of the

washing programme. Refer to 'At the

end of programme'.

5.2 Programme knob

Turn this knob to set a programme. The

related programme indicator comes on.

5.3 Display

A B C D

The display shows:

A• The maximum temperature of the programme.

B• The default spin speed of the programme.

•'No Spin'

and 'Rinse Hold' symbols.

C•The display symbols.

Symbols Description

Washing phase

Rinse phases

Spin phase

Child lock

You cannot open the appliance door when the symbol is

on.

You can open the door only when the symbol goes off.

If the programme is completed but the symbol stays on:

• There is water in the drum.

• The 'Rinse Hold' function is on.

Delay start

8www.aeg.com

D• The programme time

When the programme starts, the time decreases with steps of 1 mi-

nute.

• The delay start

When you press the delay start button, the display shows the delay

start time.

• Alarm codes

If the appliance has a malfunction, the display shows alarm codes. Re-

fer to 'Troubleshooting' chapter.

•Err

The display shows this message for some seconds if:

– You set a function that is not applicable for the programme.

– You change the programme while it operates.

The indicator of the Start/Pause button

flashes.

•

When the programme is completed.

1) Only available for Spin/Drain programme.

2) The symbols appear on the display when the related phase or function is set.

5.4 Start/Pause button

Press button

to start or interrupt a

programme.

5.5 Delay start button

Press button

to delay the start of a

programme from 30 minutes to 20 hours.

5.6 Time save button

Press the button

to decrease the

programme duration.

• Press one time to set 'Shortened dura-

tion' for items with daily soil.

• Press two times to set 'Extra Quick' for

items with almost no soil.

Some programmes accept only

one of the two functions.

5.7 Extra rinse button

Press button

to add rinsing phases to

a programme.

Use this function for persons allergic to

detergents and in areas where the water

is soft.

5.8 Stain button

Press button

to add the stain phase

to a programme.

Use this function for laundry with hard

stains to remove.

When you set this function, put the stain

remover into compartment .

This function increases the pro-

gramme duration.

This function is not available with

a temperature lower than 40° C.

5.9 Spin button

Press this button to:

• Decrease the maximum speed of the

spin phase when you set a pro-

gramme.

The display shows only the spin

speeds available with the set

programme.

• Deactivate the spin phase.

• Activate the 'Rinse Hold' function. Set

this function to prevent fabric creases.

The appliance does not drain the wa-

ter when the programme is comple-

ted.

ENGLISH 9

Spin phase is off.

'Rinse Hold' function is

on.

5.10 Temperature button

Press button

to change the default

temperature.

- - = cold water

5.11 Acoustic signals function

You can hear the acoustic signals when:

• You activate the appliance.

• You deactivate the appliance.

• You press the buttons.

• The programme is completed.

• The appliance has a malfunction.

To deactivate/activate the acoustic sig-

nals, press button

and button

the same time for 6 seconds.

If you deactivate the acoustic sig-

nals, they continue operate only

when you press the buttons and

when a malfunction occurs.

5.12 Child lock function

This function prevents children to play

with the control panel.

• To activate the function, press button

and button

at the same time

until the display shows the symbol .

• To deactivate the function, press but-

ton

and button

at the same

time until the symbol goes off.

You can activate the function:

• Before you press the Start/Pause but-

ton

: the appliance cannot start.

• After you press the Start/Pause button

, all the buttons and the pro-

gramme knob are deactivated.

5.13 Permanent extra rinse

function

With this function you can keep the extra

rinse function permanently on when you

set a new programme.

• To activate the function press button

and button

at the same time

until the indicator of button

is on.

• To deactivate the function press but-

ton

and button

at the same

time until the indicator of button

off.

6. PROGRAMMES

Programme

Temperature

Type of load

max. weight of

load

Cycle

description

Functions

Koch/Bunt

Blanc/Couleurs

Cottons

95° - Cold

White and coloured

cotton with normal

soil.

max. 7 kg

Wash

Rinses

Long spin

SPIN REDUCTION

RINSE HOLD

STAIN

EXTRA RINSE

TIME SAVING

10 www.aeg.com

Table of contents

Languages:

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide

Beko

Beko WKB 51231 PTMA manual
