AEG LAVAMAT 64850L User manual

LAVAMAT 64850L EN User manual

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you

impeccable performance for many years, with innovative technologies that help

make life simpler – features you might not find on ordinary appliances. Please

spend a few minutes reading to get the very best from it.

ACCESSORIES AND CONSUMABLES

In the AEG webshop, you’ll find everything you need to keep all your AEG

appliances looking spotless and working perfectly. Along with a wide range of

accessories designed and built to the high quality standards you would expect,

from specialist cookware to cutlery baskets, from bottle holders to delicate

laundry bags…

Visit the webshop at:

www.aeg.com/shop

CONTENTS

4 Safety information

5 Safety instructions

6 Product description

8 Special accessories for installation

8 Control panel

10 Personalization

11 Daily use

16 Helpful hints and tips

17 Washing programmes

20 Consumption values

21 Care and cleaning

26 What to do if…

30 Technical data

30 Installation

34 Environment concerns

The following symbols are used in this user

manual:

Important information concerning your

personal safety and information on how to

avoid damaging the appliance.

General information and tips

Environmental information

Subject to change without notice.

Contents 3

SAFETY INFORMATION

Before the installation and use of the appliance, carefully read the

supplied instructions. The manufacturer is not responsible if an incor-

rect installation and use causes injuries and damages. Always keep the

instructions with the appliance for future reference.

Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

• Do not let persons, children included, with reduced physical senso-

ry, reduced mental functions or lack of experience and knowledge

use the appliance. They must have supervision or instruction for the

operation of the appliance by a person who is responsible for their

safety.

• Do not let children play with the appliance.

• Keep all packaging away from children.

• Keep all detergents away from children.

• Keep children and pets away from the appliance door when it is

open.

• If the appliance has a child safety device, we recommend you acti-

vate it.

General Safety

• Before maintenance, deactivate the appliance and disconnect the

mains plug from the mains socket.

• Do not change the specification of this appliance.

• Obey the maximum load volume of 7 kg (refer to the “Programme

chart” chapter).

• If the supply cord is damaged, it must be replaced by the manufac-

turer, its service agent or similarly qualified persons in order to

avoid a hazard.

• The operating water pressure (minimum and maximum) must be

between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa)

4Safety information

• The ventilation openings in the base (if applicable) must not be ob-

structed by a carpet.

• The appliance is to be connected to the water mains using the new

supplied hose-sets. Old hose sets must not be reused.

SAFETY INSTRUCTIONS

Installation

• Remove all the packaging and the transit bolts.

• Keep the transit bolts. When you move the appliance again you must block the drum.

• Do not install or use a damaged appliance.

• Do not install or use the appliance where the temperature is less than 0 °C or where it is

exposed to the weather.

• Obey the installation instruction supplied with the appliance.

• Make sure that the floor where you install the appliance is flat, stable, heat resistant and

clean.

• Do not install the appliance where the appliance door can not be fully opened.

• Always be careful when you move the appliance because it is heavy. Always wear safety

gloves.

• Make sure that there is air circulation between the appliance and the floor.

• Adjust the feet to have the necessary space between the appliance and the carpet.

Electrical connection

WARNING!

Risk of fire and electrical shock.

• The appliance must be earthed.

• Make sure that the electrical information on the rating plate agrees with the power sup-

ply. If not, contact an electrician.

• Always use a correctly installed shockproof socket.

• Do not use multi-plug adapters and extension cables.

• Make sure not to cause damage to the mains plug and to the mains cable. Contact the

Service or an electrician to change a damaged mains cable.

• Connect the mains plug to the mains socket only at the end of the installation. Make

sure that there is access to the mains plug after the installation.

• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

• Do not touch the mains cable or the mains plug with wet hands.

• This appliance complies with the E.E.C. Directives.

Water connection

• Make sure not to cause damage to the water hoses.

Safety instructions 5

• The appliance is to be connected to the water mains using the new supplied hose-sets.

Old hose sets must not be reused.

• Before you connect the appliance to new pipes or pipes not used for a long time, let the

water flow until it is clean.

• The first time you use the appliance, make sure that there is no leakage.

Use

WARNING!

Risk of injury, electrical shock, fire, burns or damage to the appliance.

• Use this appliance in a household environment.

• Obey the safety instructions on the detergent packaging.

• Do not put flammable products or items that are wet with flammable products in, near

or on the appliance.

• Do not touch the glass of the door while a programme operates. The glass can be hot.

• Make sure that you remove all metal objects from the laundry.

• Do not put a container to collect possible water leakage under the appliance. Contact the

Service to ensure which accessories can be used.

Care and Cleaning

WARNING!

Risk of injury or damage to the appliance.

• Do not use water spray and steam to clean the appliance.

• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use

abrasive products, abrasive cleaning pads, solvents or metal objects.

Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent children and pets to get closed in the appliance.

Service

• Contact the Service to repair the appliance. We recommend only the use of original

spare parts.

PRODUCT DESCRIPTION

Your new appliance meets all modern requirements for effective treatment of laundry with

low water, energy and detergent consumption.

The ECO VALVE system allows total use of detergent and reduces water consumption so

saving energy.

6Product description

1Detergent dispenser drawer

2Control panel

3Door opening handle

4Rating plate

5Drain pump

6Adjustable feet

Detergent dispenser drawer

Compartment for prewash phase or stain re-

mover.

The prewash detergent is added at the beginning

of the wash programme.

The stain remover is added during the STAIN-Ac-

tion phase in the main wash.

Compartment for powder or liquid detergent

used for main wash.

Compartment for liquid additives (fabric soft-

ener, starch).

Follow the product manufacturer’s recommendations on quantities to use and do not ex-

ceed the «MAX» mark in the detergent dispenser drawer. Any fabric softener or starching

additives must be poured into the compartment before starting the wash programme.

Product description 7

Child safety device

Make sure that children or pets do not climb into

the drum. To prevent children or pets becoming

trapped inside the drum the machine incorporates

a special feature. To activate this device, rotate

the button (without pressing it) inside the door

clockwise until the groove is horizontal. If neces-

sary use a coin. To disable this device and restore

the possibility of closing the door, rotate the but-

ton anticlockwise until the groove is vertical.

SPECIAL ACCESSORIES FOR INSTALLATION

Rubber feet kit (4055126249)

Available from your authorized dealer.

The rubber feet are particularly recommended on floating, slippery and wooden floors.

Mount the rubber feet to prevent vibration, noises and displacement of the appliance dur-

ing operation.

Read carefully the instructions supplied with the kit.

Fixing plate kit (4055171146)

Available from your authorized dealer.

If you install the appliance on a plinth, secure the appliance in the fixing plates.

Follow the instructions supplied with the kit.

CONTROL PANEL

Henceforth the programme selector dial, the buttons and the display will be indicated with

the numbers given in this table.

1 2 3 4 5 6 87 9 10

1Programme selector dial

2TEMPERATURE button

3SPIN button

4STAIN button

5SENSITIVE button

6TIME SAVING button

7Display

8START/PAUSE button

9DELAY START button

10 Indicator pilot lights

Table of symbol

= Handwash = Rinse Hold

= Cold = Child Lock

Display (7)

7.1 Duration of selected programme:

Duration of selected programme : After selecting a programme, the duration is displayed in

hours and minutes (for example ). The duration is calculated automatically on the

basis of the maximum recommended load for each type of fabric. After the programme has

started, the time remaining is updated every minute.

Alarm codes

Control panel 9

In the event of operating problems, some alarm codes can be displayed, for example

(see chapter «What to do if...»).

End of programme

When the programme has finished a blinking zero is displayed, the DOOR pilot light

(10.2), the WASHING pilot light (10.1) and the pilot light of button 8go out and the door

can be opened.

Incorrect option selection

If an option which is not compatible with the set wash programme is selected, the message

Err is displayed for about 2 seconds and the yellow pilot light of button 8light starts blink-

ing.

7.2 Delay start:

The selected delay (20 hours max) set by means of the relevant button appears on the dis-

play for about 3 seconds, then the duration of the previously selected programme is dis-

played. The symbol 7.2 will appear on the display. The delay time value decreases by one

unit every hour. When only 1 hour remains, the time decreases every minute.

7.3 Child safety lock symbol

Indicator pilot lights (10)

After having pressed the button 8, the WASHING

pilot light (10.1) comes on.

When the pilot light 10.1comes on this means

that the machine is operating.

The DOOR pilot light (10.2) indicates if the door

can be opened:

• light on: the door cannot be opened.

• light blinking: the door is opening.

• light off: the door can be opened.

When the appliance is performing additional rinses the EXTRA RINSE pilot light (10.3)

comes on. To add an additional rinse, please see chapter «Select an additional rinse».

PERSONALIZATION

Acoustic signals

The machine is provided with an acoustic device, which sounds in the following cases:

• at the end of the cycle

• in the event of operating problems.

By pressing the 3and 4buttons simultaneously for about 6 seconds, the acoustic signal is

deactivated (except for the events of operating problems). By pressing these 2 buttons

again, the acoustic signal is reactivated.

Child safety lock

This device permits you to leave the appliance unsupervised and not to worry that children

might be injured by or cause damage to the appliance.

This function remains able also when the washing machine is not working.

There are two different ways to set this option:

10 Personalization

Table of contents

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide

Beko

Beko WKB 51231 PTMA manual
