AEG SANTO 1403-4 U User manual

Dekorfähiger Unterbau-Kühlschrank

Undercounter Refrigerator

Réfrigérateur à sous-encastrer

Onderbouwkoelkasten

ÖKO_SANTO 1403-4 U

Gebrauchsanweisung

Operating Instructions

Mode d’emploi

Gebruiksannwijzing

Contents

Important ……………………………………………………………………………………………… 17

General instructions ………………………………………………………………………………. 18

Choice of location ………………………………………………………………………………..19

Commercial use …………………………………………………………………………………… 19

Hints on proper use …………………………………………………………………………………20

Appliance packaging information ……………………………………………………………20

Removing the adhesive tapes …………………………………………………………………. 21

Hints on energy-saving ……………………………………………………………………………21

Mounting under a continuous worktop …………………………………………………..22

Rehingeing the door ………………………………………………………………………………. 22

Pannelling the door …………………………………………………………………………………23

Cleaning before using for the first time …………………………………………………. 23

Starting up and temperature regulation ………………………………………………….24

Correct storage ………………………………………………………………………………………..25

Icemaking ………………………………………………………………………………………………. 26

Defrosting ………………………………………………………………………………………………. 26

Cleaning and care ……………………………………………………………………………………27

When not in use …………………………………………………………………………………….. 27

Minor repairs that you can carry out yourself …………………………………………28

Faults and servicing …………………………………………………………………………………28

Electrical connection ……………………………………………………………………………….29

Plug socket …………………………………………………………………………………………..30

Internal lighting ………………………………………………………………………………………30

Your appliance needs air ………………………………………………………………………… 30

IMPORTANT

If your new appliance has been bought to replace an order model,

please make the old appliance unusable at once: pull the plug out

of the socket, cut the connecting lead off, and dispose of the plug

together with the remaining lead in an environmentally friendly

manner.

Any snap catch or lock on your old appliance should also be made

unusable before you put the appliance away or hand it over to be

disposed of in an environmentally friendly manner.

In this way you can prevent children from locking themselves in

when playing and thus endangering their lives.

Please make sure that the pipelines of your fridge-freezer are not

damaged before collection for environment-friendly disposal.

General instructions

You have just purchased a home refrigerator which has been produced

according to the standards applicable to these appliances.

During manufacture, the necessary measures have been taken as required by

the Appliance Safety Act (GSG), the Accident Prevention Regulations for

Refrigerating Installations (VBG 20), and the Specifications of the Institute

of German Electrical Engineers (VDE).

The refrigeration circuit has been checked for leakage.

This appliance complies with the following EC Directives:

- 73/23/EEC of 19.02.1973 - Low-Voltage Directive

- 89/336/EEC of 03.05.1989 (including Amendment Directive

92/31/EEC) - EMC (Electromagnetic Compatibily) Directive.

Before starting up, we recommend you to read the following Operating

Instructions, since only by doing so can you benefit from all the advantages

offered by your refrigerator. These Operating Instruction are intended for

several technically comparable models with different equipment. Please only

follow the instructions corresponding to your appliance version.

Choice of location

• If possible, your refrigerator should be installed in a dry, well-venti-

lated room. Its installation in a damp room or the occurrence of

weather-dependent high air humidity may temporarily lead to pre-

cipitation of moisture (dew formation) on the outside of the freezer

compartment.

• Ambient temperature has an effect on the power consumption of

the unit. The appliance should therefore:

- not stand in the direct sunshine, or close to a radiator or cooker

- stand in a position where the ambient temperature corresponds

with the climate category for which the appliance is designed.

• You will find data on this on the rating plate, which is in the interi-

or of the appliance on the left hand side. It will consist of one of

the following:

Climate category Ambient temperature

from ... to ...

SN +10 to +32°C

N +16 to +32°C

ST +18 to +38°C

T +18 to +43°C

• If installation beside a heat source is unavoidable, the following

minimum distances at the sides are to be complied with: To electric

cookers 3 cm, to oil or coal fired cookers 30 cm.

Install a heat protection panel between the two appliances.

The appliance should be installed on a firm, horizontal surface.

Correct any floor irregularities by twisting the adjustable feet in or

out.

Commercial use

Should you use your home refrigerator commercially or for purpos-

es other than refrigeration of food and drinks, you must observe

the legal requirements applicable to your area.

Hints on proper use

• Store your food, depending on type and sensitivity, in the appropri

ate temperature zones. This will enable you to achieve an optimum

storage duration (see illustration under “Correct storage”).

• Ensure good packaging and coverage of food intended for storage

in the refrigerator to retain flavour, colour, moisture, and freshness.

• Clean the refrigerator compartment regularly to ensure hygienic

storage of food and to prevent undesirable odours from forming.

• Never place hot food in your refrigerator for cooling.

Appliance packaging information

All materials used are environmentally compatible! They can be safely

disposed of or burnt in a refuse incinerator!

Regarding the materiale: The plastics can also be recycled and are

marked as follows:

>PE< for polyethylene e.g. as used in the outer wrapping and bags

inside

>PS< for polystyrene foam e.g. as used in the packing; this material!

is basically CFC-free.

The cardboard parts are made of waste paper and should be put back

into the waste paper collection system.

Removing the adhesive tapes

The door is secured to the housing with adhesive tapes. Remove any

adhesive tape residues with a suitable petroleum-based cleansing

agent.

Hints on energy-saving

One or two additional hints on energy-saving are given below:

• Do not install your refrigerator next to a radiator or oven. Through

high ambient temperature, the temperature regulator switches on

the refrigerating unit more frequently and for longer.

• Do not place any hot food in the refrigerator - first allow the food

to cool to room temperature.

• Do not open the door unnecessarily and close it again as quickly as

possible.

• Set the most energy-saving frozen food storage temperature (see

"Starting up and temperature regulation").

• Ensure good ventilation.

• Keep the heat-emitting condenser (heat exchanger), the metal grille

on the rear wall of your appliance, clean. Thoroughly clean it at

least once per year.

Mounting under a continuos worktop

Supplied with the appliance is a kit including a venting grille (B) and

two brackets (A) to fix the appliance to the kitchen unit.

☞Fit the two brackets on the upper hinges (see detail) and fix them

by means of the screws supplied with the kit.

☞Insert the appliance into the kitchen unit recess and fix the two

brackets to the unit by means of two woodscrews.

☞Push-fit the front venting grille (B)

in its housing.

Rehingeing the door

Before connecting your appliance to the power supply, you should

check whether the door hinge should be changed over from right (as

delivered) to left if required by the installation site and operability.

☞Tilt the appliance slightly towards the rear and prop it securely.

☞Remove bottom hinge (4).

☞Remove door (3).

☞Remove pivot (1) from the top hinge and refit it in the outer hole of

the hinge on the opposite side.

☞Refit the door and the bottom hinge.

☞Remove handle (2) and refit it on the opposite side.

Pannelling the door

☞Take off the door frame section opposite to

the door handle.

☞Loosen, without removing them, all remain-

ing screws securing the door frame.

☞Slide in the decor panel from the frameless

side, then fasten again the frame to the

door including the previously removed

frame section.

Note

The overall dimensions of the decor panel

must be 1 to 2 mm less than those of the

door, with a maximum thickness of 4 mm.

Cleaning before using for the first time

Like all new appliances, your refrigerator will smell "new". For this

reason, the interior of the refrigerator and all accessories sh oul d be

cleaned before use (see also "CIeaning and care"). The rating plate is

located inside the appliance.

Starting up and temperature regulation

☞Insert the plug of the connection lead into

the plug socket with protective earth con-

tact. When the refrigerator compartment

door is opened, the internal lighting is

switched on. The temperature selector

knob is located on the RH side of the

refrigerator compartment.

Setting "0" means: Off.

Turning clockwise in direction "1":

Refrigerating unit on, the latter then oper-

ating automatically.

Setting "1" means: Highest temperature,

warmest setting.

Setting "6" (end -stop) means: Lowest temperature, coldest setting.

☞For normal refrigeration, we recommend setting "3". If you require a

lower temperature, select setting "4".

☞For icemaking, rapid refrigeration, and shortterm storage of frozen

food in the icemaking compartment, select setting "5" or "6".

The internal temperature is strongly affected by the ambient tempe-

rature, loading, and frequent door opening.
