Advantech SmartStart Series Guide

Start Guide

SmartStart, SmartFlex, SmartMotion

Start Guide

Safety instructions

Please take care to following instructions:

•Use the router in compliance with national and international law and in compliance with

any special or additional restrictions regulating the use of the router in the various appli-

cations and environments.

•To avoid possible injury and/or damage to the device, observe the relevant provisions

and standards. Use only the original accessories as recommended. Unauthorized de-

vice or accessory modiﬁcation, or using accessories that have not been approved can

result in router damage and/or violation of the regulations.

•Unauthorized device or accessory modiﬁcation or using the accessories that have not

been approved can result in warranty termination.

•Do not open the router.

•Caution! The SIM card can be swallowed by small children.

•When connecting the device to a power supply do not exceed the deﬁned voltage.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture, and high temperature.

•Only routers with appropriate certiﬁcation and labelling should be used in locations where

ﬂammable and explosive materials are present, including gas stations, chemical plants,

or locations in which explosives are used. We remind users of the duty to observe the

restrictions concerning the utilization of radio devices at such places.

•While using the router close to personal medical devices, such as cardiac pacemakers

or hearing aids, proceed with heightened caution.

•Operating the router too close to TV sets, radio receivers, personal computers, or tele-

phones can cause interference.

•It is recommended that you create a copy or backup of the important settings stored in

the memory of the router.

QSG-0002-EN, January 24, 2020 1Released in the Czech Republic

Start Guide

Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) direc-

tive was introduced to ensure that electrical/electronic products are recycled us-

ing the best available recovery techniques in order to minimize impact on the en-

vironment. This product contains high-quality materials and components which

can be recycled. At the end of it’s life this product MUST NOT be mixed with

other commercial waste for disposal. The device contains the battery. Remove

the battery from the device before disposal. The battery in the device needs to be disposed

apart accordingly. Check the terms and conditions of your supplier for disposal information.

Open Source Software License

The software in this device uses various pieces of open-source software governed by the

following licenses:

•GPL versions 2 and 3

•LGPL version 2

•BSD-style licences

•MIT-style licences

The list of components together with complete license texts can be found on the device

itself. See Licenses link at the bottom of the router’s main Web page (General Status) or point

your browser to this address (replace the DEVICE_IP string with real router’s IP address):

https://DEVICE_IP/licenses.cgi

This is a written offer valid for 3 years since the device purchase offering any third party

for a charge no more than the cost of physically performing source distribution, a complete

machine-readable copy of the corresponding source code on a ﬂash drive medium. If you are

interested in obtaining the source, please contact us at:

[email protected]

Modiﬁcations and debugging of LGPL-linked executables:

The manufacturer of the device hereby grants the right to use debugging techniques (e.g.

decompilation) and making customer modiﬁcations of any executable linked with an LGPL

library for own purposes. Note these rights are limited to the customer’s own usage. No further

distribution of such modiﬁed executables and no transmission of the information obtained

during these actions may be done.

QSG-0002-EN, January 24, 2020 2Released in the Czech Republic

Start Guide

QSG-0002-EN, January 24, 2020 3Released in the Czech Republic

SmartStart

SmartStart Router

SL302, SL304, SL306

QSG-0002-EN, January 24, 2020 4Released in the Czech Republic

SmartStart

First Use

Before applying power to the router, connect the components that you required for your

applications. You cannot operate the router without a connected antenna, inserted SIM card,

nor a connected power supply.

If you do not have connected the main antenna during operation of the router, the router

can be damaged!

1. Antenna

Use an SMA connector to connect the antennas to the router. The main antenna is con-

nected to the router by screwing on the ANT connector (see the ﬁgure below). A second

diversity antenna can also be connected to the DIV connector to improve performance.

2. SIM card

The SIM card readers, for 3 V and 1.8 V SIM cards, are located on the rear panel of the

router. If you intend to use this device to communicate over a cellular network, please place

an activated data-provisioned SIM card with an unblocked PIN into the SIM card reader. Push

your SIM card into the SIM1 or SIM2 slot until it clicks in place.

QSG-0002-EN, January 24, 2020 5Released in the Czech Republic

SmartStart

Before handling the SIM card disconnect the router from the power supply!

3. Power

The router requires an external DC power supply. The DC voltage required is between

+9 to +36 V DC. The router has built-in protection against reverse polarity without signaling.

Connect the power supply cable to the PWR connector on the front panel of the router (see

the ﬁgure below).

QSG-0002-EN, January 24, 2020 6Released in the Czech Republic

SmartStart

4. Ethernet

An Ethernet cable may be connected to the ETH connector (designated as ETH0 in some

versions of this router) on the front panel (see the ﬁgure above). By default, the Ethernet port

is conﬁgured as follows:

Connector Purpose Default Setting

ETH LAN port (default)

Connect your laptop or PC to this port to

get a local web-server for device conﬁgu-

ration and diagnostics.

DHCP Server

IP Address: 192.168.1.1

NetMask: 255.255.255.0

Conﬁguration

1. Conﬁguring the Device Using the Web Browser

You can access the router for status monitoring, conﬁguration, and administration after

entering the IP address of the router into the web interface. The default router IP address is

192.168.1.1 (netmask 255.255.255.0). Conﬁguration access is allowed for the user "root". The

default password is printed on the router’s label.1Attention, it is necessary to use HTTPS

protocol for secure communication over a network! For a detailed description and exam-

ples of the router conﬁgurations, see the Conﬁguration manual.

2. Conﬁguration Settings via WebAccess/DMP

If your router has been pre-installed with the WebAccess/DMP client, you may conﬁgure it

from WebAccess/DMP. Navigate your browser to:

https://hub.bb-smartworx.com

If this is your ﬁrst time, please register with the site. If not, please login with your username

and password. Once logged in, further assistance can be found here:

http://hub.bb-smartworx.com/Login/Help?HelpFile=hub.pdf

3. Restoring and Backing up the Router Conﬁguration

After you reset the router, the current conﬁguration is overwritten by the default settings.

We recommend that you back up the router conﬁguration before resetting the device. Refer to

the Conﬁguration manual for more information.

1If the router’s label does not contain a unique password, use the password "root".

QSG-0002-EN, January 24, 2020 7Released in the Czech Republic

SmartStart

When the PWR LED starts blinking, it is possible to restore the default conﬁguration of the

router by pressing the RST button on the rear panel. After pressing this button, the default

conﬁguration is restored and then the router reboots (green LED will be on).

Important Notes

After logging on to the device for the ﬁrst time, we strongly recommend changing the

default password due to security reasons. Simultaneously, you will gain access to all

functions of the router.

For security reasons, it is highly recommended to update the ﬁrmware of the router to the

latest version regularly. Downgrading the ﬁrmware to an older version than the production

version or uploading a ﬁrmware intended for a different device may cause the malfunction

of the device.

Documentation

User’s Manual and Conﬁguration Manual for the router can be found and downloaded on

this web site: www.advantech-bb.cz/download

Hereby, Advantech Czech s.r.o. declares that the radio equipment type SmartStart

SL304 is in compliance with Directive 2014/53/EU.

The full text of the EU Declaration of Conformity is available at the following internet address:

www.advantech-bb.cz/eudoc
