ADF Web HD67B16-B2 User manual
Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
EtherNet/IP Slave
Document code: MN67B16_ENG Revision 1.001 age 1 of 32
User Manual
Revision 1.001
English
OPC UA Client / EtherNet/IP - Converter
(Order Code: HD67B16-B2)
for Website information:
http://www.adfweb.com/? roduct=HD67B16
for rice information:
http://www.adfweb.com/? rice=HD67B16-B2
Benefits and Main Features:
Triple electrical isolation
ower Supply 18…35V DC and 8…24 V AC
Temperature range: -40°C/+85°C (-40°F/+185°F)
For others O C UA Client devices, see also the following links:
OPC UA Client from/to
www.adfweb.com? roduct=HD67B08 (Serial)
www.adfweb.com? roduct=HD67B09 (Modbus Slave)
www.adfweb.com? roduct=HD67B10 (Modbus TCP Slave)
www.adfweb.com? roduct=HD67B11 (Bacnet Slave)
www.adfweb.com? roduct=HD67B12 (CAN)
www.adfweb.com? roduct=HD67B13 (CANopen)
www.adfweb.com? roduct=HD67B14 (DeviceNet Slave)
www.adfweb.com? roduct=HD67B15 (DMX)
www.adfweb.com? roduct=HD67B17 (J1939)
www.adfweb.com? roduct=HD67B18 (KNX)
www.adfweb.com? roduct=HD67B19 (MQTT)
www.adfweb.com? roduct=HD67B20 (NMEA0183)
www.adfweb.com? roduct=HD67B21 (NMEA2000)
www.adfweb.com? roduct=HD67B22 (PROFINET)
www.adfweb.com? roduct=HD67B23 (SNMP Agent)
Do you have an your customer protocol?
See the following links:
www.adfweb.com? roduct=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
User Manual
Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
EtherNet/IP Slave
Document code: MN67B16_ENG Revision 1.001 age 2 of 32
INDEX:
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
OWER SU LY 7
FUNCTION MODES 8
LEDS 9
ETHERNET 10
USE OF COM OSITOR SW67B16 11
NEW ROJECT / O EN ROJECT 12
SOFTWARE O TIONS 13
SET COMMUNICATION 15
O C UA ACCESS 17
U DATE DEVICE 23
LC CONFIGURATION 25
MECHANICAL DIMENSIONS 29
ORDERING INFORMATIONS 30
ACCESSORIES 30
DISCLAIMER 31
OTHER REGULATIONS AND STANDARDS 31
WARRANTIES AND TECHNICAL SU ORT 32
RETURN OLICY 32
Pagina 2 di 32
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
Revision
Date Author
Chapter
Description
1.000 13/03/2019 Tf/Ff All First release version
1.001 22/04/2020 Ff All Revision
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
EtherNet/IP Slave
Document code: MN67B16_ENG Revision 1.001 age 3 of 32
SECURITY ALERT:
G
ENERAL
I
NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I
NTENDED
U
SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q
UALIFIED
P
ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R
ESIDUAL
R
ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE
CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.
Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
EtherNet/IP Slave
Document code: MN67B16_ENG Revision 1.001 age 4 of 32
EXAMPLE OF CONNECTION:
Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
EtherNet/IP Slave
Document code: MN67B16_ENG Revision 1.001 age 5 of 32
CONNECTION SCHEME:
Figure
1
: Connection scheme for HD67
B16
-
B2
Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
EtherNet/IP Slave
Document code: MN67B16_ENG Revision 1.001 age 6 of 32
CHARACTERISTICS:
The HD67B16-B2 is a O C UA Client / EtherNet/I Slave converter.
It allows the following characteristics:
Up to 1500 bytes in reading and 1500 bytes in writing;
Two-directional information between EtherNet/I and O C UA;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67B16 software on your C in order to perform the following:
Define the parameter of the O C UA;
Define the parameter of the EtherNet/I ;
Define the list of O C UA servers connected to the converter;
Update the device.
Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
EtherNet/IP Slave
Document code: MN67B16_ENG Revision 1.001 age 7 of 32
POWER SUPPLY:
The devices can be powered between a wide range of tensions. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
HD67B16-B2 8V 24V 12V 35V
Consumption at 24V DC:
Device W/VA
HD67B16-B2 4
Caution: Not reverse the polarity power
HD67B16-B2
Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
EtherNet/IP Slave
Document code: MN67B16_ENG Revision 1.001 age 8 of 32
FUNCTION MODES:
The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’:
The first, with Dip1 in Off position (factory setting), is used for the normal working of the device.
The second, with Dip1 in On position, is used for upload the roject/Firmware.
For the operations to follow for the updating (see ‘U DATE DEVICE’ section).
According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section).
Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
EtherNet/IP Slave
Document code: MN67B16_ENG Revision 1.001 age 9 of 32
LEDS:
The device has got six LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: O C UA comm. (yellow) Flashing: O C UA response
OFF: No O C UA response
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: EtherNet/I comm.
(yellow)
Flashing: EtherNet/I communication
OFF: No EtherNet/I communication
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Error state (yellow) ON: At least one O C UA Server is disconnected
OFF: all O C UA Servers are connected
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Link Ethernet (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected
Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
EtherNet/IP Slave
Document code: MN67B16_ENG Revision 1.001 age 10 of 32
ETHERNET:
The Ethernet connection must be made using Connector3 of HD67B16-B2 with at least a Category 5E cable. The maximum length of the
cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a C/ LC/other is recommended the use of a
cross cable.
