ADF Web HD67643-A1 User manual

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

EtherNet/IP

Master /

PROFIBUS

Slave

Document code: MN67643_ENG Revision 1. Page 1 of 24

User Manual

Revision 1.

English

EtherNet/IP Master / PROFIBUS Slave -

Converter

(Order Code: HD67643-A1)

for Website information:

http://www.adfweb.com/?Product=HD67643

for Price information:

http://www.adfweb.com/?Price=HD67643-A1

Benefits and Main Features:

Triple electrical isolation

Two Ethernet ports

Temperature range: -4 °C/+85°C (-4 °F/+185°F)

For others EtherNet/IP Master devices, see also the following links:

EtherNet/IP Master from/to

www.adfweb.com?Product=HD67158 (SNMP Agent)

www.adfweb.com?Product=HD67643 (PROFIBUS Slave)

www.adfweb.com?Product=HD67645 (CAN)

www.adfweb.com?Product=HD67646 (CANopen)

www.adfweb.com?Product=HD67647 (DeviceNet Slave)

www.adfweb.com?Product=HD67661 (PROFINET)

www.adfweb.com?Product=HD67665 (Modbus TCP Slave)

www.adfweb.com?Product=HD67667 (Serial)

www.adfweb.com?Product=HD67669 (Modbus Slave)

www.adfweb.com?Product=HD67689 (BACnet Slave)

www.adfweb.com?Product=HD678 6 (KNX)

www.adfweb.com?Product=HD67955 (MQTT)

Do you have an your customer protocol?

See the following links:

www.adfweb.com?Product=HD67 3

Do you need to choose a device? do you want help?

Ask it to the following link:

www.adfweb.com?Cmd=helpme

User Manual

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

EtherNet/IP

Master /

PROFIBUS

Slave

Document code: MN67643_ENG Revision 1. Page 2 of 24

INDEX:

Page

INDEX 2

UPDATED DOCUMENTATION 2

REVISION LIST 2

WARNING 2

TRADEMARKS 2

SECURITY ALERT 3

EXAMPLE OF CONNECTION 4

CONNECTION SCHEME 5

CHARACTERISTICS 6

CONFIGURATION 6

POWER SUPPLY 7

FUNCTION MODES 8

LEDS 9

PROFIBUS 1

ETHERNET 11

USE OF COMPOSITOR SW67643 12

NEW PROJECT / OPEN PROJECT 13

SOFTWARE OPTIONS 14

SET COMMUNICATION 16

ETHERNET/IP ACCESS 17

GSD FILE 18

UPDATE DEVICE 19

MECHANICAL DIMENSIONS 21

ORDERING INFORMATIONS 22

ACCESSORIES 22

DISCLAIMER 23

OTHER REGULATIONS AND STANDARDS 23

WARRANTIES AND TECHNICAL SUPPORT 24

RETURN POLICY 24

Pagina 2 di 24

UPDATED DOCUMENTATION:

Dear customer, we thank you for your attention and we remind you that

you need to check that the following document is:

Updated

Related to the product you own

To obtain the most recently updated document, note the “document code”

that appears at the top right-hand corner of each page of this document.

With this “Document Code” go to web page www.adfweb.com/download/

and search for the corresponding code on the page. Click on the proper

“Document Code” and download the updates.

REVISION LIST:

Revision

Date Author

Chapter

Description

1. 13/ 3/2 18 Ff All First release version

WARNING:

ADFweb.com reserves the right to change information in this manual about

our product without warning.

ADFweb.com is not responsible for any error this manual may contain.

TRADEMARKS:

All trademarks mentioned in this document belong to their respective

owners.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

EtherNet/IP

Master /

PROFIBUS

Slave

Document code: MN67643_ENG Revision 1. Page 3 of 24

SECURITY ALERT:

ENERAL

NFORMATION

To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and

safety regulation are required for each individual application. The same applies also when using accessories.

NTENDED

Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.

independent limit switches, mechanical interlocks, etc.).

UALIFIED

ERSONNEL

The device can be used only by qualified personnel, strictly in accordance with the specifications.

Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and

who have appropriate qualifications for their job.

ESIDUAL

ISKS

The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and

operated by untrained personnel. These instructions refer to residual risks with the following symbol:

This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or

death and / or the possibility of damage.

CONFORMITY

The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

EtherNet/IP

Master /

PROFIBUS

Slave

Document code: MN67643_ENG Revision 1. Page 4 of 24

EXAMPLE OF CONNECTION:

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

EtherNet/IP

Master /

PROFIBUS

Slave

Document code: MN67643_ENG Revision 1. Page 5 of 24

CONNECTION SCHEME:

Figure 1: Connection scheme for HD67643-A1

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

EtherNet/IP

Master /

PROFIBUS

Slave

Document code: MN67643_ENG Revision 1. Page 6 of 24

CHARACTERISTICS:

The HD67643-A1 is a EtherNet/IP Master / PROFIBUS slave Converter.

It allows the following characteristics:

Two-directional information between EtherNet/IP and PROFIBUS;

Electrical isolation between PROFIBUS – EtherNet/IP, Power Supply – EtherNet/IP, Power Supply – PROFIBUS;

Mountable on 35mm Rail DIN;

Wide power supply input range: 8…24V AC or 12…35V DC;

Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].

CONFIGURATION:

You need Compositor SW67643 software on your PC in order to perform the following:

Define the parameter of the PROFIBUS;

Define the parameter of the EtherNet/IP;

Define the list of EtherNet/IP slaves connected to the converter;

Update the device.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

EtherNet/IP

Master /

PROFIBUS

Slave

Document code: MN67643_ENG Revision 1. Page 7 of 24

POWER SUPPLY:

The devices can be powered between a wide range of tensions. For more details see the two tables below.

VAC

VDC

Vmin Vmax Vmin Vmax

HD67643-A1 8V 24V 12V 35V

Consumption at 24V DC:

Device W/VA

HD67643-A1 4

Caution: Not reverse the polarity power

HD67643-A1

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

EtherNet/IP

Master /

PROFIBUS

Slave

Document code: MN67643_ENG Revision 1. Page 8 of 24

FUNCTION MODES:

The device has got two functions mode depending of the position of the Dip2 of ‘Dip-Switch A’:

The first, with Dip2 in Off position (factory setting), is used for the normal working of the device.

The second, with Dip2 in On position, is used for upload the Project/Firmware.

For the operations to follow for the updating (see ‘UPDATE DEVICE’ section).

According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section).

Warning:

Dip1 of ‘Dip-Switch A’ must be at ON position to work even if the Ethernet cable is not inserted.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

EtherNet/IP

Master /

PROFIBUS

Slave

Document code: MN67643_ENG Revision 1. Page 9 of 24

LEDS:

The device has got six LEDs that are used to give information of the functioning status.

The various meanings of the LEDs are described in the table below.

LED Normal Mode Boot Mode

1: ON [supply voltage ]

(green)

ON: Device powered

OFF: Device not powered

ON: Device powered

OFF: Device not powered

2: PROFIBUS communication

(green) Blinks when PROFIBUS communication is running Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

3: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

4: Not used (green) OFF Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

5: Ethernet1 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

6: Ethernet2 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

EtherNet/IP

Master /

PROFIBUS

Slave

Document code: MN67643_ENG Revision 1. Page 1 of 24

PROFIBUS:

The PROFIBUS uses a 9-pin D-SUB connector. The pin assignment is defined like in the following figure.

Here some codes of cables:

Belden: p/n 183 79A - Continuous Armor DataBus® ISA/SP-5 PROFIBUS Cable.
