AddBike U-Cargo User manual
U-Cargo
This document contains information on the correct way to use the U-Cargo. It is imperative that you
read this document in its entirety to keep your U-Cargo in good working order for as long as possible.
Please keep this guide.
Photo non contractuelle
User guide
October 2021
Welcome to the family
of AddBikers!
The U-Cargo is the ideal family bike, designed to meet your
daily mobility needs.
It is an urban, versatile, longtail bike.
Ride safely with your children and your belongings.
Easy to use thanks to its electric assistance
and its adaptable equipment!
1
Before you start cycling, here is some general information:
Transport
of children
2 seats available
Removable cushions included (U-Cargo Family)
Room for 1 to 2 child seats / Suitable for adults (<80kg)
Possibility to accommodate an additional child, up to 35kg
with AddBike+ (optional)
Available
space
Available loading area: 60cm x 50cm (length and width)
Available volume: 90L (can be extended in height)
Loading capacity: 180kg
Luggage rack
compatibility Thule - Polisport -Décathlon - Hamax - Bobike - Ortlieb
Front basket Removable front basket (4 screws)
Wooden base / Up to 20kg - 30L
Guarantee Frame: 5 years / Engine: 2 years
Spare parts are stored in our warehouse in Lyon.
In case of technical problems / after sales service :
- If you bought your U-Cargo via a dealer: contact him directly and you will be guided;
- If you bought your U-Cargo via AddBike, contact us, we will be happy to help you;
- If your U-Cargo was commissioned by a partner Technicentre, contact us directly.
+33 04 78 59 98 76 - [email protected]
Motor Bafang - BBS02 / Position: Pedal / Power rating: 250W
Torque: 80Nm / Smartphone application: Bafang Go
Battery
Phylion Battery, Samsung cells- 14.5Ah - 36V - 522 Wh
Autonomy : 65km - Space available for a 2nd battery
Display Position : left handle / 4 levels of assistance / buttons and
indicator lights
Features Easy-Start : easy start by activating the hand throttle
Bicycle parts
Frame
& Fork
6061- T6 painted aluminium frame (grey or white)
Fork wheelbase: 100mm
Weight & Size
Lite: 32kg - 192cm (L) x 68cm handlebar (l) x 110cm (h) /
Family: 40kg - 210cm (L) x 68cm (l) x 110cm (h) /
Protech'360: 60cm (l) x 110cm (H)
+2nd batterie: +3,5kg
Wheels Wheels: Mach1 : KARGO 20" - ETRTO 406x25C
Tyres: Innova : IA-2128 20"x 2.40
Transmission
Bafang 44 tooth chainring
7 speed cassette 11/32
Shifter Shimano Altus
Derailleur Shimano Acera
Chain: KMC E8 ebike series
Hydraulic disc brakes: Front and Back Ø180mm, ZOOM HB-870
Brakes
Light Spanninga: Front: Axendo 40Lux / Back: Elips - 13 Cd
Handlebar Rise: 75mm / Upsweed: 5° / Backsweep: 24° / Largeur: 68cm
Electrical parts
2
Table of content
1. General warning .................................................................................4
2. U-Cargo glossary ................................................................................6
3. Contents of the U-Cargo box ...........................................................7
4. Verification and safety ...................................................................7
5. Recommendations for use .............................................................8
6. The U-Cargo in use .............................................................................9
7. Motorisation of your U-Cargo .......................................................11
8. Battery ..................................................................................................13
9. General settings ................................................................................15
10. Maintenance .......................................................................................17
11. U-Cargo transport .............................................................................18
12. Cleaning and storage .....................................................................18
13. Assistance ...........................................................................................19
14. Warranty ..........................................................................................19
15. General dimensions ..........................................................................20
3
As with any conventional bicycle, the use of a U-Cargo involves risks of injury and
damage (risk of falls). By using the U-Cargo, you assume full responsibility for
these risks; you must know and apply the rules of the road to travel safely.
4
1. General warning
Global safety guidelines:
The safety instructions are intended to draw your attention to potential dangers.
They require your full attention and understanding. If you ignore a safety
instruction, you could injure yourself or others. The safety instructions alone are
not sufficient to prevent hazards; take them into account to avoid the risks
associated with using your U-Cargo.
Symbols and warnings :
AddBike and its dealers are not liable for damages resulting from improper use; use your
U-Cargo as described in this manual. Any other use is considered improper and can lead
to damage to the U-Cargo or even to accidents and serious injury. The U-Cargo is only
intended for use on smooth surface and paths. Be careful not to overload your
U-Cargo.
Read and follow the instructions in this guide: It is necessary to read the whole guide
carefully and follow the instructions to use your U-Cargo safely.
If you do not understand any of the instructions, please contact your dealer or
contact directly AddBike at the following address: [email protected]
Please keep these instructions for future reference.
AddBike takes no liability for failure of compliance with the instructions in this
manual or in case of improper modification of the product by the user.
DISCLAIMER!
This symbol indicates a danger that can cause serious injury if the instructions are not followed.
WARNING!
This symbol indicates a danger that may cause minor injuries if the instructions are not followed.
ADVICE!
This symbol indicates a tip for the use or maintenance of your AddBike.
Regularly check your U-Cargo to identify any signs of wear and tear,
Do not use your U-Cargo if you observe cracks, deformations or colour
changes due to material fatigue,
Get your U-Cargo checked. If you notice excessive wear, loose screws, cracks,
deformations or colour changes, please contact your dealer immediately or
contact our customer service.
Caution:
Excessive wear and tear, material fatigue or insufficiently tightened screws can lead
to failures that can result in accidents or falls.
Our advice is to :
Cargo bikes are exposed to attrition and deterioration, by which the various
materials may react differently.
Worn parts must be replaced.
5
Hard knocks, shocks and tension can damage the frame, forks and wheels.
2. U-Cargo glossary
6
Easy-Start
Start riding without
any effort!
Bafang BBS02 pedal motor
80Nm / 250W
Phylion battery
Samsung cells
14.5Ah/ 522 Wh
Extra slot
for a second battery
Front basket
removable basket,
for carrying bags
(20 kg)
Front light
Spanninga brand,
Axendo 40
20" thick wheel
thick and small for a
low centre of gravity
and better handling
Step'n'Load
Wood platforms to easily
step on the bike
Additional storage space
Seat belts included
The backrest can be removed +
Standard backseats for children can be added
Door opens on
one side only
(sidewalk)
Check that the stem is tight, the front wheel must be perfectly aligned with the
handlebars,
Check the tightness of the front and rear wheels,
Check the operation of the brakes by fastening the brake lever of the bike,
Check the tyre pressure,
Check that the battery is correctly inserted in its slot,
Check that the front and rear lights are working properly,
Visually check the rest of the bike,
Adjust the seat height to your liking,
Adjust the saddle to your height , do a test ride in a safe area
Check the tyre pressure,
Make sure the front and rear lights are working properly,
Check that the battery is sufficiently charged for the duration of your ride,
Visually check the rest of the bike,
Make your usual adjustments for maximum riding comfort
4. Verification and safety:
Before your first ride:
Your U-Cargo has been checked upon departure by our engineers and should be
ready to ride. Nevertheless, a double-check from the user is imperative before the
first ride (see safety checklist):
Before each ride:
7
U-Cargo with its battery
Charger
User guide
Theft document (bicycle registration)
Safety check list
Welcome document
3. Contents of the U-Cargo box:
8
Use the U-Cargo only on surfaces that are suitable for urban bicycles,
When cycling, wear a helmet that complies with traffic regulations.
5. Recommendations for safe use of the U-
Cargo (safety on the road):
The following general safety instructions will help you to use your U-Cargo on the
road in the safest possible way:
When travelling with the U-Cargo, light clothing with reflective bands should be
worn,
Do not use the U-Cargo if you are under the influence of alcohol, drugs or
medication that may impair your driving ability,
Do not use portable devices such as a telephones when cycling,
When travelling, do not get distracted by other activities such as turning on the
lights,
Never let go of the handlebars when riding a bicycle except to indicate a
change of direction,
Ride in a way that does not injure, endanger, block or hinder anyone,
Preferably ride on cyclable paths designed for bicycles,
Drive carefully, especially in poor visibility,
Make your movements and changes of direction predictable,
Announce your intention to turn or overtake in advance with your bell.
We strongly advise to always wear a helmet while riding a bike.
The level of assistance is customisable by pressing the UP button and DOWN button
on the display.
You can monitor the battery level on the right of the display, each blue led (5 total)
corresponds to 20% of the charge level.
To turn the lights on or off, press and hold the UP button for 2 seconds.
6. The U-Cargo in use:
Starting:
The U-Cargo turns on by pressing the "on/off" button
on the display to the left of the handlebars. The electric
assistance starts as soon as you start pedalling. To help
you start the U-Cargo, press the trigger next to the display
(see figure 6).
Total maximum weight:
The maximum load is 180 kg (load + pilot).
Riding with one or more passengers and/or a heavy load affects the balance, center
of gravity and handling of the U-Cargo. The total weight of the bike also affects the
braking time.
The maximum load of the U-Cargo must be respected: 20kg in the front basket and
80kg at the back. For passengers, we recommend that no more than two kids are
carried.
The weight of the rider and the weight that can be safely carried by the rider are proportional.
The load should not exceed 80% of the riders' weight.
9
figure 2 - DP E12 Bafang display
max. 20kgmax. 80kg
Familiarise yourself driving the bike loaded in a safe setting before
driving on the road.
