Acetech iTarget User manual
Contents
iTarget-12T Kit Accessories -----------------------------P1
Introduction to Product
--------------------------------P2
Introduction to Each Unit
-------------------------------P3
iTarget Setup --------------------------------------------P5
1-1 Setup of Round Target
1-2 iTarget System Wiring Instructions
1-3 iTarget System Setup Instructions
2-1 Controller Operation Instructions
2-2 Set Target ID
2-3 Set Moving Target ID
2-4 Call Target
Controller Operation Instructions ----------------------P9
System Status
Main Menu
Unit1：Game Setup
( Shot Timer / Whack a Mole / Rescue /
Compete / Demo)
Unit2：Scoreboard Information/ Scoring Instructions
Unit3：Target setup
Unit4：iTracer Pairing: iTracer Unit/SCU Pairing
Unit5：System setup
Warranty ------------------------------------------------P15
iTarget-12T Kit Accessories
1 EN
8 cm round target
10cm round target
PDU
(Power Distribution Unit)
1-meter wire
5-meter wire
adaptor
12
12
1
14
2
1
FPR material, thickness of 1.6mm
FPR material, thickness of 1.6mm
Power Din to RJ45 power tap.
Used for connecting to iTarget, 12 ones for
normal use and 2 ones for spares.
One is connected to the controller and one to
the scoreboard.
Input：100-240VAC 50-60Hz
Output：19V / 4.7A
2
3
M3*10mm self-tapping screw 30
4
8
9
10
11
Name Quantity
No.
Target 12 Each iTarget is comes with an 8 cm and 10 cm
round target
1
Controller 1
5Operate and control the operation of iTarget.
LED scoreboard
Control button
1
1
6
7
16x64 white LED display.
Start and stop iTarget .
24 screws for normal use. rest of them for spares
Instructions
Introduction to Product
iTracer SCU
iTracer Unit Shot limit and incorporate the number of
shot into the fractional calculation
Individually paired iTracer Unit can
score the amount of shots.
Perform the function of limiting the amount
of shots fired, When the game is over,
iTracer SCU interrupts the power of the AEG,
making it impossible for the AEG to shoot.
The game must be started again before it
can shoot again.
The function of limiting shots can
only be performed by
simultaneously pairing iTracer Unit
and SCU.
Connection
Device Functions Remarks
2 EN
1. iTraget system consists of iTargets, moving targets, scoreboard, controller, start button, adaptor
and network wires.
2. Basic requirements of iTraget: a number of targets (3~32)+ controller to construct iTarget system
3. 16*64 dot LED Scoreboard: Real-time display of current scores
4. Use controller to execute game and set system parameters
5. The controller is equipped with RF communication and iTracer Unit, iTracer SCU connection
(as shown in the figure below), and the function description is as follows:
6. The controller is equipped with Bluetooth communication and can be connected to the phone
or tablet, making it easier to use the APP.
7. 8cm and 10cm round target are provided. Users can install 8cm or 10cm round target on
iTargets as they like
8. Moving target (optional) : Target that will move left and right. The higher the difficulty (Level) is
set, the faster the moving speed will be, thereby improving the fun and difficulty of the game.
9. Adaptor: 19V/ 4.7a can supply 20 power consumption units
10. Description of power consumption:
The user calculates the power consumption according to the system installation requirements
to determine whether the adaptor can supply the power consumption of the system.
Power consumption of target : 1power consumption unit
Power consumption of moving target: 4 power consumption units
(including the iTargets on moving platform)
Power consumption of scoreboard : 3power consumption units
Power consumption of controller : 1 power consumption unit
For example: iTarget-12T kit accessories:
target *12+ controller *1+ scoreboard *1=1*12+1*1+3*1=16 power consumption units
11. A set of iTarget can support up to 32 target connections (including 1 moving target).
Introduction of Each Unit
1.Target :
This device is responsible for raising and knocking down the target, and when setting up the
target, it will give out a warning sound to alert the shooter.Meanwhile, LED will illuminate
red or green light to add the fun of shooting on the target surface.
A. Comes with one 8cm and 10cm round target.
B. RGB LED light: green light means shooting, red light means not shooting,
blue light means self-correcting.
C. Horn hole: for making beep sounds, the volume is adjustable.
D. Two RJ45 ports, using RJ45 cable connection to set up the system.
E. There are two 1/4 inch camera tripod screw holes at the bottom. Install the screw holes as
required
F. Dimensions: 94mm x 127mm x 49mm
G. Weight: 337g
2.Controller: the game and device can be set and the game can be started. The following is the
description of each part. (Figure 2)
A. Two RJ45 ports, using RJ45 cable connection
to set up the system.
B. Horn hole: give out button prompt sound,
volume can be adjusted.
C. 1.5 inch 128*128 dot OLED
D. 3.5mm headphone jack, inserted to activate
the button wire connector.
E. Dimension: 92mm x 92mm x 28mm
F. Weight: 105g
3.16x64 LED scoreboard: (Figure 3)
Dimension : 640mm x 160mm x 50mm
Weight: 2.5kg
A
B
D
E
C
(Figure 1.)
(Figure 3.)
A
B
C
D
(Figure 2.)
3 EN
(Figure 6.)
(Figure 7.)
4 EN
(Figure 5.)
B
B
A
B
Input ：100~240VAC
Output : 19V/4.7A
(Figure 4.)
4.Moving Target:
It is composed of a moving platform and an iTarget, so that the iTarget can move left and right,
and the moving speed can be set to increase the fun and difficulty of the iTarget (Figure 4).
A.Use the RJ45 cable connection to set up the
system.
B.Institutional introduction: stepper motor, belt,
shaft, electronic target, optical interrupter.
C.Dimension: 740mm x 160mm x 91mm
D.Weight: 3.5kg
5.PDU (Power Distribution Unit): (Figure 5)
The PDU is used to connect the power supply and all devices via RJ45 cable.
A.Adaptor Power Din connector, connected to adaptor.
B.Three RJ45 couplers are connected to iTarget, moving
target, scoreboard and controller respectively.
6. Adaptor: (Figure 6)
7.RJ45 network wire: provide 1 m and 5 m cable dual isolation network wire respectively.
The use of non-original wire may lead to system abnormality.
8. Control button: button for starting or stopping the game (Figure 7.)
iTarget Setup
1-1.Setup of Round Target :
Select 8 cm or 10 cm round target as desired,
and lock the target into the screw hole of the
iTarget shaft with M3*10 screws, as shown in
the figure.
1-3.iTarget System Setup Instructions:
The basic elements of iTarget system are controller and electronic target. Therefore,
as long as there are controllers and more than 3 targets, an iTarget system can be
set up. Moving target, scoreboard and start button are designed to increase the fun
and difficulty of iTarget. Users may increase the number of targets on demand.
Examples are shown in A, B and C.
For example: 1 controller+5 targets
Select one of the PDU RJ45 connectors and sequentially connect 5
targets by using a 1-meter network wire
Select one of the PDU RJ45 connectors and connect to the controller
by using a 5-meter network cable
When all devices are connected, plug the adaptor into the power din
of the PDU to power it.
(The orange line represents RJ45 cable. Please refer to Chapter 1-2. iTarget
System Wiring Instructions.)
1
2
3
A 1 controller+ n targets
5 EN
1-2.
iTarget System Wiring Instructions
Use RJ45 cable (shown by the orange line below) for wiring connection as shown
in the figure below.(for setup, please refer to chapter 1-3 below. iTarget System
Setup Instructions)
C iTarget-12T + a set of moving targets
For example, 12 targets +1 moving target +1 controller +1 scoreboard +1 control button
Select one of the PDU RJ45 connectors and use a 1-meter network wire to
connect 6 iTargets and scoreboard sequentially.
Select one of the PDU RJ45 connectors and use a 1-meter network wire to
connect the moving target
Select one of the PDU RJ45 connectors and use a 1-meter network wire to
connect 6 iTargets, controller and start button sequentially.
When all devices are connected, plug the adaptor into the power din of the
PDU to power it.
(The orange line represents RJ45 cable. Please refer to Chapter 1-2. iTarget System
Wiring Instructions.)
1
2
3
4
6 EN
1
2
3
Select one of the PDU RJ45 connectors and use a 1-meter network wire
to connect 6 targets and scoreboard sequentially.
Select one of the PDU RJ45 connectors and use a 1-meter network wire
to connect 6 targets controller and start button sequentially.
When all devices are connected, plug the adaptor into the power din of
the PDU to power it.
B iTarget-12t set: controller +12 targets + scoreboard + start button
(The orange line represents RJ45 cable. Please refer to Chapter 1-2. iTarget
System Wiring Instructions.)
2-1.Controller Operation Instructions :
When the iTarget system is set up, plug in the power and turn it on. At this time,
the controller OLED displays iTarget. Press any button of the controller to enter
the System Status screen, press the “Right” button to enter the Main Menu
and then press the “Right” button again to enter the Target Setup.
7 EN
2-2.Set Target ID :
In the iTarget Setup screen, press the “Down” button on the controller to
select Set target ID, and press the “Right” button to perform this function.
At this time, all targets will be raised, please knock down the targets manually in
sequence (as shown in the figure below), and the system will set numbers
according to the sequence of falling, the target ID of the first knocked down is 1,
the target ID of the second knocked down is 2, and so on.
2-3.Set Moving Target ID:
[This function can only be performed when users are equipped with
moving targets (optional equipment)]
In the iTarget Setup screen, press the “Down” button to select On Motion ID,
press the “Right” button to perform this function and enter the screen to
select the automatic target ID number on the moving platform, and then press
the “OK” button to complete the setting.
8 EN
2-4.Call Target
Upon completion of ID setting, ITarget ID confirmation can be confirmed through
this function.
In the iTarget Setup screen, press the “Down” button to select Call ID, and
press the “Right” button to perform this function. The target with ID=n will
be called. The No. n target will raise up and the green LED will be projected and
a beep will sound.
