ABYSS BATTERY AB-12V100 User manual
INSTRUCTION MANUAL
WWW.ABYSSBATTERY.COM
BATTERY
ABYSS
DISCLAIMER
Thanks for choosing our lithium-ion batteries, please
read this User Manual carefully before using the
battery.
We do not take the responsibility for losses or accidents
resulting from improper use, or facts identified as the
following:
1) Defects caused by improper assembly or
disassembly; 2) defects occurring after purchase due to
product modification, intentional damage, accident,
misuse, abuse, negligence or exposure to corrosive
elements; 3) cosmetic damage and 4) labor or assembly
costs. Except as provided herein, Abyss Battery, Inc.
makes no express warranties, and any implied warranty,
including without limitation any implied warranty of
merchantability or fitness for a particular purpose, is
limited in its duration to the duration of the written
limited warranty set forth herein. Except as provided
herein, Abyss Battery, Inc. shall have no liability or
responsibility to the purchaser or any other person or
entity with respect to any liability, loss or damage
caused or alleged to be caused directly or indirectly by
use of the product, including, but not limited to, any
incidental or consequential damages.
THE WARRANTY CONTAINED HEREIN IS THE EXCLUSIVE WARRANTY MADE
BY ABYSS BATTERY®, INC. AND THERE ARE NO OTHER WARRANTIES,
EXPRESSED OR IMPLIED, INCLUDING A WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE OR OF MERCHANTABILITY MADE WITH RESPECT
TO SUCH BATTERIES. ABYSS BATTERY, INC. IS NOT LIABLE FOR ANY
INJURY OR MISHAPS SUSTAINED IN THE USE OF THIS PRODUCT. THE
USER OF THIS PRODUCT ACKNOWLEDGES ASSUMED RISKS AND WAIVES
ANY AND ALL CLAIMS AGAINST ABYSS BATTERY, INC. AND ANY OF IT’S
AGENTS.
2
WWW.ABYSSBATTERY.COM
Abyss Battery Instruction Manual
WWW.ABYSSBATTERY.COM
3
PRODUCT OVERVIEW............................................
PACKAGE INCLUDES.............................................
TECHNICAL SPECIFICATIONS...............................
INTRODUCTION.....................................................
KEY BENEFITS.......................................................
FEATURES.............................................................
WHERE TO USE......................................................
OPERATION METHOD............................................
SAFETY & PRECAUTIONS......................................
WARRANTY...........................................................
DISPOSAL AND RECYCLING.................................
CERTIFICATIONS...................................................
01
01
02
03
03
04
05
05
09
10
11
12
TABLE OF
CONTENTS
Abyss Battery Instruction Manual
1 x Lithium-Iron-Phosphate Battery
2 x M8 Stainless Terminal Bolts
2 x Stainless lock nuts & washers
1 x Abyss Battery Quick Start Guide
4
PRODUCT OVERVIEW:
PACKAGE INCLUDES:
Abyss Battery Instruction Manual
WWW.ABYSSBATTERY.COM
DIMENSIONS:
INTERNAL STRUCTURE:
208mm
260mm
170mm
260mm
Molded Plastic
cell holder
Molded Nickel
sheet Heating film
Cell
Bluetooth module
BMS
5
Abyss Battery Instruction Manual
WWW.ABYSSBATTERY.COM
TECHNICAL SPECIFICATIONS:
Model Nominal Voltage
Nominal Capacity Parallel Connection
Serial Connection BMS
Bluetooth Heat
Circuit Protection Cycle Life
Self-Discharge Charge Efficiency
Discharge Efficiency
Charge Voltage
Standard Current
Fast Current
Standard Current
Max. Con. Current
Peak Current
Cut-off Voltage
Dimensions (mm)
Approx. Weight (KG)
Terminal Type
Case Color/material
IP Rating 65
Cell Type: Lithium Iron Phosphate
Cell holder: Yes
Charge Temp
Discharge Temp
Storage Term
ELECTRICAL
SPECIFICATIONS
CHARGE
SPECIFICATIONS
DISCHARGE
SPECIFICATIONS
MECHANICAL
SPECIFICATIONS
TEMPERATURE
SPECIFICATIONS
Abyss Battery Instruction Manual
INTRODUCTION:
KEY BENEFITS:
WWW.ABYSSBATTERY.COM
Higher qualified cylindrical cells:
UL1642, IEC62619, and IEC62133 are listed with a
cycle life of more than 3000times and excellent
consistency.
Bluetooth Integration:
Monitor battery status (charge, discharge, current,
temperature, cycle life, and so on) and
manage/change the data for different applications.
Heating Functions:
Uniform internal heating is an important feature of
our cold-weather performance batteries, as many
external heating blanket options currently available
cannot sense the internal temperature of the cells
and may not be completely effective at heating the
battery throughout. The system features
proprietary technology that draws power from the
charger itself, requiring no additional components.
The entire process of heating and charging is
completely seamless. Simply plug the battery into
the regular lithium charger and the internal heating
and monitoring system takes care of the rest.
Not All Lithium Batteries Are Built Equal or
Perform the Same. With pre-programmed
intelligence, Abyss Batteries can better
understand how you use your boat and
trolling motor during each charge cycle.
Our battery's ability to learn and "adapt"
makes it stand out as a superior option
for lithium-ion technology.
There is no technical way to compare
against other brands of batteries on the
market today with similar specifications.
Abyss battery design offers more
capacity and amp-hours in a smaller size
while also maintaining stability
throughout discharge cycles -all without
sacrificing performance!
Abyss Battery Instruction Manual
FEATURES:
7
WWW.ABYSSBATTERY.COM
-
More Stable and Firm Internal Structure:
Our cell holder design construction protects and separates each cell within the battery to avoid any
circuit short risk caused by vibration or impact or over current, while also improving heat dissipation.
Smaller size + less weight:
The size of our battery is just 3/4 size of the standard 12V 100Ah battery from other Lithium Battery
Companies.
Cell matching:
Strict cell matching standard, the difference of Internal resistance is 1mn and voltage is 5mV.
Automatic cell welding:
Cells are assembled with Automatic welding equipment to ensure quality, reliability, and consistency.
100% Cycle test:
All battery packs are 100% cycle tested (Fully -Discharged- Fully Charged - Fully Discharged - 60%
Charged) before package and all test reports are stored.
Unique tracking number:
All battery packs are lasered with a unique serial number on the case side for quality tracking.
Abyss Battery Instruction Manual
a. General instructions
Read the following instructions completely before installation. The information contained in this manual will
assist you in properly installing a functioning operating system, proper disposal, and avoiding serious injury
or harm.
Caution: LiFePO4 batteries if punctured may emit a hazardous electric vapor.
Toxic Vapor: It may be harmful to inhale and cause inflammation of the lungs.
Danger: Short Circuitry.
8
WHERE TO USE:
OPERATION METHOD:
WWW.ABYSSBATTERY.COM
RV MARINE
GOLF CART CLEANING
LIGHT EV
ROBOTICS LIGHTING
ENERGY
STORAGE
Abyss Battery Instruction Manual
b. Battery Installation
Series Battery Connections
9
WWW.ABYSSBATTERY.COM
24V CONNECTION
WITH TWO 12V BATTERIES (FIGURE 1.)
36V CONNECTION
WITH THREE 12V BATTERIES (FIGURE 2.)
To trolling motor negative
+24 Volts to trolling motor
positive (or circuit breaker)
24 Volt Series Connection
pos +
Neg - pos +
Neg -
Battery #1
(Low Side)
Battery #2
(High Side)
To trolling motor negative
24 Volt Series Connection
pos +
Neg - pos +
Neg -
Battery #1
(Low Side) Battery #2
(Middle)
+36 Volts to trolling motor
positive (or circuit breaker)
36 Volt Series Connection
pos +
Neg -
Battery #3
(High Side)
WWW.ABYSSBATTERY.COM
10
TRANSPORTATION
REQUIREMENTS:
Abyss Battery Instruction Manual
c. Charging
Only use ABYSS® Approved Lithium Battery chargers or Compatible battery chargers recommended.
DO NOT leave your battery charging overnight. Our batteries only take two hours to fully charge.
Recommended Charging Method: Plug in your Battery Charger the night before your fishing trip, by doing
this and only fully charging your battery when you need it you will drastically extend your battery life cycle.
1. ABYSS BATTERY™ is an approved Hazmat shipper which is required to ship lithium-ion batteries. All our
products are delivered in packaging that meets or exceeds federal and international standards for shipping
lithium-ion batteries.
2. FedEx and UPS require you to be Hazmat trained and certified to ship lithium ion batteries. If you do not have
an open and active Hazmat account you will not be allowed to ship us your batteries with these carriers. Abyss
Battery® will be required to arrange an LTL Freight shipment to return your batteries to us.
3. Please do not attempt to ship your battery back to us without proper packaging or if you are not an
approved hazmat shipper!
4. All lithium batteries are required to be shipped in accordance with UN38.3 certification and must meet or
exceed international and federal regulations for lithium-ion batteries. If you do not have your original packaging,
ABYSS BATTERY™ can send you the proper packaging for a small fee including shipping costs.
