Part Number 09-0700-002

The following information will help you install the 3Com



Impact



ISDN External digital modem models 3C871,3C872,

3C876,or 3C877.Refer to the

3Com Impact ISDN External

Digital Modem User Guide

for additional information.

Site Preparation

The Basic Rate ISDN line and computer serial port must be

properly conﬁgured.

Ordering,Installing, and Conﬁguring the ISDN Line

3Com has determined the optimal ISDN line conﬁgurations

for the 3Com Impact digital modem and has provided that

conﬁguration data to many telephone companies.To simplify

the ordering process for an ISDN digital line,use the following

simpliﬁed ISDN ordering code:

3ComA * J6

If your digital modem has an internal analog fax modem

(Models 3C872 and 3C877),then two directory numbers

(telephone numbers) will be required to allow a voice call and

a fax modem call to occur at the same time.When you tell the

telephone company the ISDN ordering code (3ComA * J6) let

the representative know that you will need two directory

numbers.

If your telephone company does not support simpliﬁed ISDN

ordering codes,refer to Table 1 for ISDN ordering information.

An internal NetworkTermination Type 1 device (NT1) is built

into the 3Com Impact digital modem,so an external NT1 is

not usable.When the telephone company installs the ISDN

09-0700-002 Page 1 Sunday, December 22, 1996 3:40 PM

MPACT

ISDN E

XTERNAL

IGITAL

ODEM

UICK

TART

NSTRUCTIONS

line at your location,be sure it provides you with the

following information.For future reference,write the

information in the blank spaces.

Table 1

ISDN Ordering Information by SwitchType

* Two directory numbers are required for Models 3C872 and 3C877. This allows a voice call and a

call using the internal analog fax modem to occur at the same time.

ISDN Switch Type:

(See Table1) ___________________

Phone #1:

(Local ISDN Directory Number 1) ___________________

SPID #1:

(Service Profile Identifier Number 1) ___________________

Phone #2:

(Local ISDN Directory Number 2) ___________________

SPID #2:

(Service Profile Identifier Number 2) ___________________

ISDN Switch Type

ISDN Line

Configuration

Parameter AT&T



5ESS

Custom

AT&T 5ESS

National

ISDN-1

Northern

Telecom



DMS100

National

ISDN-1

Siemens



EWSD

National

ISDN-1

Line Code 2B1Q (no NT1

required) 2B1Q (no NT1

required)

Directory

Numbers 1

Channels 2B alternate

circuit-switched

data and voice

2B alternate

circuit-switched

data and voice

2B alternate

circuit-switched

data and voice

2B alternate

circuit-switched

data and voice

Terminal Type A with

Point-to-Point A with

Point-to-Point Functional PVC 2 Functional

TEI Dynamic Dynamic Dynamic Dynamic

Call

Appearances Idle Idle — —

Supplemental

Voice Features None None None None

EKTS Features No No No No

D Channel

Packet No No No No

B Channel

Packet No No No No

09-0700-002 Page 2 Sunday, December 22, 1996 3:40 PM

Installing the 3Com Impact Digital Modem

The 3Com Impact digital modem has an RS-232-C

asynchronous interface port that operates at data rates of up

to 115.2 Kbps.Some computers may need additional

hardware or driver software for reliable operation.

IBM PCs and Compatible Computers

An IBM



PC or compatible computer must have a buffered

UART (universal asynchronous receiver/transmitter) chip,called

the 16550 UART,to operate at 115 Kbps.Under Microsoft



Windows



,run the Microsoft Diagnostic Program (

msd

) at the

DOS prompt and select COM Ports within msd.The UARTs

present in your computer are listed under each COM port.

To operate at the maximum data rate,install an enhanced

16550 UART expansion card in your PC.If you have a

nonupgradable PC with a slower UART (16450 or 8250),the

3Com Impact digital modem can operate at lower data rates,

since it automatically adjusts to the PC serial COM port data

rate.The COMM.DRV driver for Windows 3.1 only allows data

rates of up to 38.4 Kbps.If you have a UART that supports

higher rates than this (for example,16550),you must install the

TurboCom



enhanced driver that is provided with the digital

modem.

Apple Macintosh Computers

Motorola



68XXX-based Macintosh



systems support a

maximum asynchronous serial port data rate of 57.6 Kbps.

Power Macintosh



computers may operate at higher serial

port data rates.

Installing the 3Com Impact Digital Modem

Follow the appropriate procedure for installing the

3Com Impact digital modem in your computer.Refer to

Figure1 during the installation procedure.

09-0700-002 Page 3 Sunday, December 22, 1996 3:40 PM

MPACT

ISDN E

XTERNAL

IGITAL

ODEM

UICK

TART

NSTRUCTIONS

Figure 1

3Com Impact Digital Modem Rear Panel

Installing the Digital Modem in an IBM-compatible PC

To install the 3Com Impact digital modem in an IBM or

compatible PC,follow these steps:

Turn off the computer.

Insert the 9-pin male end of the 3Com Impact digital

modem-to-PC serial signal cable into the connector labeled

Computer on the digital modem’s back panel and tighten the

connector screws.

Connect the other end of the 3Com Impact digital

modem-to-PC serial signal cable to a serial communications

(COM) port on the back of your PC and tighten the connector

screws.

Connect the 3Com Impact digital modem power cable to the

connector marked 12V AC on the back panel of the digital

modem.

Plug the transformer end of the power cable into a standard

117V ac wall outlet.

Connect the RJ-45 (8-pin) connector end of the RJ-45/RJ-11

ISDN cable to the RJ-45 connector labeledWall on the

digital modem’s back panel.

Connect the RJ-11 (6-pin) connector end of the RJ-45/RJ-11

ISDN cable to the RJ-11 telephone ISDN jack.

Power 12V AC RS232D Wall

ISDN BRI-U ONLY

RS232D

09-0700-002 Page 4 Sunday, December 22, 1996 3:40 PM

Installing the 3Com Impact Digital Modem

CAUTION:

The 3Com Impact digital modem is designed to

operate with Basic Rate ISDN 2B1Q U Interface network

terminations.AninternalNetworkTerminationdevice(NT1)is

built into the digital modem.Do not connect the 3Com

Impact digital modem ISDN port to a standard analog

telephone jack or to an external NT1 device.Make sure that it

is connected to the ISDN jack.

Turn on the 3Com Impact digital modem by toggling the

power switch on the back panel to the On position.

Turn on the computer’s power switch.

Go to the section “Conﬁguration for IBM PC or Compatible

Computer” to conﬁgure the 3Com Impact digital modem for

your computer.

Installing the Digital Modem in an Apple Macintosh

Computer

To install the 3Com Impact digital modem in an Apple

Macintosh computer,follow these steps:

Turn off the computer.

Insert the 9-pin male end of the 3Com Impact digital

modem-to-Macintosh serial signal cable into the

connector labeled Computer on the digital modem’s back

panel and tighten the connector screws.

Connect the other end of the 3Com Impact digital

modem-to-Macintosh serial signal cable to the serial

communications port on the back of the Macintosh.

The serial communications port is the mini-DIN,8-pin serial

port connector,indicated on the Macintosh connector panel

by the telephone handset imprint.

Connect the 3Com Impact digital modem power cable to

the connector marked 12V AC on the back panel of the

digital modem.

09-0700-002 Page 5 Sunday, December 22, 1996 3:40 PM

MPACT

ISDN E

XTERNAL

IGITAL

ODEM

UICK

TART

NSTRUCTIONS

Plug the transformer end of the power cable into a

standard 117V ac wall outlet.

Connect the RJ-45 (8-pin) connector end of the RJ-45/RJ-11

ISDN cable to the RJ-45 connector labeledWall on the

digital modem’s back panel.

Connect the RJ-11 (6-pin) connector end of the RJ-45/RJ-11

ISDN cable to the RJ-11 telephone ISDN jack.

CAUTION:

The 3Com Impact digital modem is designed to

operate with Basic Rate ISDN 2B1Q U Interface network

terminations.An internal NetworkTermination device (NT1)

is built into the digital modem.Do not connect the 3Com

Impact digital modem ISDN port to a standard analog

telephonejackortoanexternal NT1 device.Makesurethatit

is connected to the ISDN jack.

Turn on the 3Com Impact digital modem by toggling the

power switch on the back panel to the On position.

Turn on the computer’s power switch and restart.

Go to the section “Conﬁguration for Apple Macintosh

Computer” to conﬁgure the 3Com Impact digital modem for

your computer.

Conﬁguring the 3Com Impact Digital Modem

The 3Com Impact digital modem requires the ﬁve essential

conﬁguration parameters below before it can operate

properly on an ISDN line.Before conﬁguring the digital

modem,make sure you have this information readily

available.These ﬁve parameters are provided to you at the

time of installation of your ISDN line by the telephone

company installer.

■

ISDN Switch Type

■

Phone #1 (local directory telephone number)

■

SPID #1 (Service Proﬁle Identiﬁer)

09-0700-002 Page 6 Sunday, December 22, 1996 3:40 PM

Configuring the 3Com Impact Digital Modem

■

Phone #2 (if required by the telephone company)

■

SPID #2 (if required by the telephone company)

Each of these items is stored in special S registers within the

digital modem.These S registers are set by issuing ATSxx=

commands to the digital modem.The 3Com Impact digital

modem software will automatically issue the AT commands

to set the S registers as part of the conﬁguration process.

The following three sections describe how to conﬁgure the

3Com Impact digital modem using the Windows,DOS,or

Macintosh operating systems,respectively.

After you conﬁgure the digital modem and verify that it is

working properly,you should install theTurboCom software.

Refer to the installation instructions that came with the

TurboCom software.This software is required only for

IBM PC or compatible computers runningWindows 3.X.

Conﬁguration for IBM PC or Compatible Computer

You can conﬁgure the 3Com Impact digital modem for

an IBM PC or compatible using either theWindows-based

installation program or the MS-DOS



–based installation program.

Conﬁguration Using Windows

To conﬁgure the digital modem for an IBM PC or compatible

computer using Windows:

Insert the 3Com Impact DOS & Windows Installation

Diagnostic Utilities diskette into an available diskette drive.

Select Run from the File menu.In the Run dialog box,type:

a:setup

The check box labeled Run Minimized should be left

unchecked.

Click OK.

The installation process begins copying the conﬁguration

program to the hard disk.A message box provides the status

of the installation and indicates when it is complete.

09-0700-002 Page 7 Sunday, December 22, 1996 3:40 PM

MPACT

ISDN E

XTERNAL

IGITAL

ODEM

UICK

TART

NSTRUCTIONS

Double-click the 3Com Impact icon to access the 3Com

Impact Conﬁguration dialog box.

COM1 is the default COM port.

■

If the digital modem is connected to COM1,the 3Com

Impact Conﬁguration dialog box appears,as shown in

Figure2.Go on to step 5.

■

If the digital modem is not connected to COM1,the

COM Port Provisioning dialog box appears.Choose the

COM port to which the digital modem is connected.Click

Connect.The 3Com Impact Conﬁguration dialog box

appears,as shown in Figure 2.

Figure 2

Conﬁguration Dialog Box

A status bar below the Help,Tools,Conﬁgure,and Exit

buttons provides the following ISDN status information:

■

Layer 1 status

■

Service Proﬁle Identiﬁer (SPID) for telephone numbers 1 and 2

■

Terminal Endpoint Identiﬁers (TEI) 1 and 2 (for information

purposes only)

09-0700-002 Page 8 Sunday, December 22, 1996 3:40 PM

Configuring the 3Com Impact Digital Modem 9

A message bar at the bottom of the dialog box provides help

for completing the ﬁelds.If you click in a ﬁeld,the message

bar tells you what information to enter in the ﬁeld.The

message bar also provides status information about the

digital modem.If the digital modem is disconnected from

the ISDN telephone line,for example,a message indicates

this condition.

The right side of the dialog box shows the digital modem

software version,along with any installed options (such as

Multilink PPP or internal analog fax modem).

5Select the type of switch,as speciﬁed by your telephone

company,from the Telephone Company Switch

drop-down list box.

6Click in the Telephone Number ﬁeld in the Number 1 area

and enter the telephone number to which your digital

modem is connected.

7Click in the Service Proﬁle Identiﬁer (SPID) ﬁeld and enter

the corresponding SPID for the telephone number you

entered in the previous step.

You should have received this SPID from your telephone

company.

CAUTION:If the ISDN line has been conﬁgured with only one

telephone number (Point-to-Point),do not include the SPID.

8Specify which device should receive the calls coming to

Telephone Number 1.

You can select Phone Port or Internal Fax/Modem.If your

model has the internal analog fax modem installed

(Models 3C872 and 3C877),you can select both.

If both boxes are checked,the internal analog fax modem and

the phone will both ring,enabling you to answer using either

device.

09-0700-002 Page 9 Sunday, December 22, 1996 3:40 PM

10 3COM IMPACT ISDN EXTERNAL DIGITAL MODEM QUICK START INSTRUCTIONS

9If you have a second telephone number associated with

your ISDN telephone line (some telephone companies

require two),enter the number and corresponding SPID in

the appropriate ﬁelds in the Number 2 area.

10 Specify which device should receive the calls coming to

Telephone Number 2.

11 Click the Conﬁgure button to download the parameters

listed in steps 5 through 10 to your digital modem’s

S registers.

12 If you have changed theTelephone Company Switch type,

you must reset the digital modem by turning the power

switch off and then on.

13 Verify the conﬁguration.

Check the status bar (located beneath the Help,Tools,

Conﬁgure,and Exit buttons of the Conﬁguration dialog box)

to verify correct conﬁguration.If the parameters were

conﬁgured accurately and the digital modem is ready to

send and receive calls,the status bar ﬁelds will appear as

shown below.Note that theTEI number(s) are not conﬁgured

by the user.The TEI number is provided by the telephone

company for informational purposes only.

■Layer 1:UP

■SPID 1:Init

■TEI 1:Number from 0 to 127

■SPID 2:Init (if required)

■TEI 2:Number from 0 to 127 (if required)

14 Click Exit to leave the utility.

This completes the conﬁguration procedure.

15 Install the TurboCom software.

Refer to the installation instructions that came with the

TurboCom software.

09-0700-002 Page 10 Sunday, December 22, 1996 3:40 PM

This manual suits for next models

Table of contents

Other 3Com Modem manuals

3Com

3Com 000839-08 User manual

3Com

3Com 3C892 - OfficeConnect ISDN Lan Modem Router User manual

3Com

3Com ISDN Modem User manual

3Com

3Com ADSL Modem Ethernet User manual

3Com

3Com OfficeConnect 3C886A Instruction Manual

3Com

3Com U.S. Robotics 56K Voice User manual

3Com

3Com OfficeConnect User manual

3Com

3Com 005699-00 - User manual

3Com

3Com 3C892 - OfficeConnect ISDN Lan Modem Router User manual

3Com

3Com U.S. Robotics 56K Voice User manual

3Com

3Com OfficeConnect 3CR29210 User manual

3Com

3Com EtherLink 3C900B User manual

3Com

3Com CMX 3CR292-DE56 User manual

3Com

3Com U.S. Robotics 56K Voice User manual

3Com

3Com 3C892 - OfficeConnect ISDN Lan Modem Router User manual

3Com

3Com Cable Modem External User manual

3Com

3Com DIGITAL MODEM User manual

3Com

3Com 3CP5610A - U.S. Robotics 56K V90 PCI Performance Pro Faxmodem... User manual

3Com

3Com OfficeConnect 3C891A Instruction Manual

3Com

3Com HomeConnect 3CP4130 User manual

3Com

3Com U.S. Robotics 56K Winmodem User manual

3Com

3Com 3C16720 User manual

3Com

3Com HomeConnect 3CR29223 User manual

3Com

3Com 3C892 - OfficeConnect ISDN Lan Modem Router User instructions

Popular Modem manuals by other brands

Davicom

Davicom DM562AP Operation manual

EpiValley

EpiValley TATA indicom SXC-1080 user guide

Zte

Zte WiMAX user manual

Intelimax

Intelimax MA-2060 user manual

SMC Networks

SMC Networks D3CM1604V Administrator's manual

Telstra

Telstra Wi-Fi 4G Advanced Pro X user guide

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 user manual

Samsung

Samsung AceLink SAM-335A user guide

Enfora

Enfora Enabler-G Integration guide

iRZ

iRZ ATM2-232 user guide

Zhone

Zhone 6310 installation instructions

Paradyne

Paradyne Hotwire 7976 installation instructions

US Robotics

US Robotics 3453C datasheet

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... user manual

Zte

Zte MF823 user guide

Four-Faith

Four-Faith F1403 user manual

Sierra Wireless

Sierra Wireless AIRLINK MP595W user guide

Gemtek

Gemtek WiMAX WIXFBR-103 user manual
