2N VoiceBlue Next User manual
www.2n.czFirmware
Version
2N VoiceBlue Next
®
User Manual
3.4
1.16.5
The 2N TELEKOMUNIKACE joint-stock company is a Czech manufacturer and supplier of
telecommunications equipment.
The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways, private
branch exchanges (PBX), and door and lift communicators. 2N TELEKOMUNIKACE a.s. has
been ranked among the Czech top companies for years and represented a symbol of stability
and prosperity on the telecommunications market for almost two decades. At present, we
export our products into over 120 countries worldwide and have exclusive distributors on all
continents.
2N is a registered trademark of 2N TELEKOMUNIKACE a.s.. Any product and/or other
®
names mentioned herein are registered trademarks and/or trademarks or brands protected
by law.
2N TELEKOMUNIKACE administers the FAQ database to help you quickly find information and
to answer your questions about 2N products and services. On www.faq.2n.cz you can find
information regarding products adjustment and instructions for optimum use and procedures
„What to do if...“.
Declaration of Conformity
2N TELEKOMUNIKACE hereby declares that the 2N VoiceBlue product complies with all
®
basic requirements and other relevant provisions of the 1999/5/EC directive. For the full
wording of the Declaration of Conformity see the CD-ROM enclosed and at www.2n.cz.
The 2N TELEKOMUNIKACE company is the holder of the ISO 9001:2009 certificate. All
development, production and distribution processes of the company are managed by this
standard and guarantee a high quality, technical level and professional aspect of all our
Content
Content
1. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.3 Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.4 Terms and Symbols Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2. Description and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 Factory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.3 Brief Installation Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4 IP Voice Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.5 VoiceBlue Next Connection to VoIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3. VoiceBlue Next Configuration . . . . . . . . . . . . . . . . . . . . . . . . 28
3.1 Factory Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.2 Basic Configuration – Step by Step . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.3 Call Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.4 Web Configuration Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4. Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
4.1 Terminal-Based Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
4.2 AT Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
4.3 LOGs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
4.4 CDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
4.5 SDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
4.6 Available Status Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
4.7 Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
4.8 Tracing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
4.9 External SMS Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
5. Technical Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
6. Supplementary Information . . . . . . . . . . . . . . . . . . . . . . . . . . 106
6.1 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
6.2 List of Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
6.3 Regulations and Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
6.4 General Instructions and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
42N TELEKOMUNIKACE a.s., www.2n.cz
®
1. Product Overview
In this section, we introduce the product, outline its application2N VoiceBlue Next
®
options and highlight the advantages following from its use. This section also includes
safety instructions.
Here is what you can find in this section:
1.1 Product Description
1.2 Safety Precautions
1.3 Upgrade
1.4 Terms and Symbols Used
52N TELEKOMUNIKACE a.s., www.2n.cz
®
1.1 Product Description
2N VoiceBlue Next
® is a device that helps directly interconnect a SIP–supporting
VoIP network with GSM networks and can be used for direct connection with a
telephone set. The voice mode, i.e. outgoing and incoming calls, is the basic function of
the gateway. is equipped with all voice mode functions and 2N VoiceBlue Next
®
provides the highest user comfort. In addition to voice transmission, 2N VoiceBlue
®
enables you to send and receive text messages (SMS). No additional equipmentNext
(such as an external phone) is needed for normal operation. You can use the web
interface or AT commands for all the gateway settings. The programmable parameters
are set in such a way that you can make calls the moment you connect the system to
the Ethernet, connect an antenna and insert the SIM card. can 2N VoiceBlue Next
®
be combined with the service (remote GSM extension) for up 2N Mobility Extension
®
to 8 users . also provides connection to the syst
1 2N VoiceBlue Next
®2N SIM Star
®
em .
2
2N VoiceBlue Next Basic Features
®
Compact size
Two/four GSM/UMTS channels2
System rack installation option2
Intelligent incoming/outgoing call routing
SMS sending/receiving (web, AT interfaces)
User–friendly web interface
Power over Ethernet (PoE)
A single antenna for 1 or 2 GSM modules
Automatic call records and detailed statistics
2N Mobility Extension
® support
2N SIM
® supportStar
Possibility of SMS sending+receiving via web interface
Tone detection
[1] Depending on the available licence type
[2] Depending on the part number
62N TELEKOMUNIKACE a.s., www.2n.cz
®
1.2 Safety Precautions
It is prohibited to use any transmitters, including the UMTS/GSM devices, in
areas where explosives are used, such as quarries.
It is prohibited to use the GSM gateways at petrol stations where mobile
telephones are also prohibited.
GSM phones may affect sensitive life–saving devices in medical centres.
Therefore, it is forbidden to use GSM/UMTS devices, including the GSM gateways,
in such facilities.
In general, any prohibition regarding mobile phones based on RF energy
radiation applies to GSM/UMTS devices too.
If necessary, the GSM gateways may be installed at a safe distance from the
prohibited area and connected with the original place through an Ethernet cable.
Although GSM gateways are not intended for cars or aeroplanes, all relevant
prohibitions and regulations regarding mobile phones apply to them too.
72N TELEKOMUNIKACE a.s., www.2n.cz
®
1.3 Upgrade
The manufacturer reserves the right to modify the product in order to improve its
qualities.
In response to the customers' requirements, the manufacturer constantly improves the
software contained in the product (firmware). For the latest firm2N VoiceBlue Next
®
ware version and the User Manual refer to the .2N web sites
For a detailed description of the firmware upgrade see the2N VoiceBlue Next
®
section devoted to the system installation.
Manual
Version Upgrade
1.1 The User Manual relates to the firmware version 2N VoiceBlue Next
®
01.00.02.
2.0 The User Manual relates to the firmware version 2N VoiceBlue Next
®
01.00.04.
3.0 New four–channel version.2N VoiceBlue Next
®
3.2 The User Manual relates to the 2N VoiceBlue Next
® firmware version
1.14.0.
3.3 The User Manual relates to the firmware version 2N VoiceBlue Next
®
. Text correction.1.14.0
3.4 The User Manual relates to the 2N VoiceBlue Next
® firmware version
1.16.5.
82N TELEKOMUNIKACE a.s., www.2n.cz
®
1.4 Terms and Symbols Used
Symbols in Manual
The following symbols and pictograms are used in the manual:
Safety
abide by this information to prevent persons fromAlways
injury.
Warning
abide by this information to prevent damage to theAlways
device.
Caution
Important information for system functionality.
Tip
Useful information for quick and efficient functionality.
Note
Routines or advice for efficient use of the device.
Future Functions, Innovations
The in this document designates the functions that are undergrey-marked text
preparation or development at present.
92N TELEKOMUNIKACE a.s., www.2n.cz
®
2. Description and Installation
This section describes the proper product installation and2N VoiceBlue Next
®
connection.
Here is what you can find in this section:
2.1 Before You Start
2.2 Factory Settings
2.3 Brief Installation Guide
2.4 IP Voice Transmission
2.5 VoiceBlue Next Connection to VoIP
102N TELEKOMUNIKACE a.s., www.2n.cz
®
2.1 Before You Start
Caution
Make sure that you are equipped with all system components
necessary for putting in operation (SIM2N VoiceBlue Next
®
card, VoIP phone and/or duly configured SIP line of your SIP
Proxy, an available 100BaseT socket and a PC for initial
settings).
Product Completeness Check
Before installing this product, check whether the delivery2N VoiceBlue Next
®
complies with the following packing list. Be careful because there may be differences in
the packing list depending on whether you have ordered a two-channel or four-channel
version of the product (different part numbers).2N VoiceBlue Next
®
Package 2ch VBN 4ch VBN
2N VoiceBlue Next
®1 1
Power supply adapter 1 1
Short antenna 1 None
Long antenna 1 1
Ethernet cable 1 1
Quick Start manual 1 1
Wall–mounting set 1 None
SIM card cover including screws 1 None
Rubber feet None 4
Connector Lay–Out (2-Channel Version)
The following connectors are mounted on the bottom:2N VoiceBlue Next
®
Power supply connector – DC jack 2.1mm
10/100BaseT Ethernet connector
RESET button – press for a short time to restart the GSM gateway and for a long time
to restart the GSM gateway and download the factory settings.
