ZyXEL Communications NWA-1100 User manual

NWA1100 Series

802.11b/g/n PoE

Access Point

NWA1100 Series

802.11b/g/n PoE

Access Point

Ł

Easy deployment via multiple

operating modes and IEEE

802.3af PoE support

Ł

Multiple 4 SSIDs benefit

different service levels

Ł

Certified WPA/WPA2 support for

strict network protection

Ł

Comprehensive management

solutions that effortlessly

merge into the existing network

administration system

Ł

Environmental friendly through

IEEE 802.11az Energy Efficient

Ethernet and WMM Power

Saving features

Secure and Reliable WLAN Connectivity

for Small- to Medium-scale Businesses

The ZyXEL NWA1100 Series is designed for small- and medium-sized businesses to extend

the existing wired networks.The ZyXEL NWA1100 Series consists of two models: NWA1100

and NWA1100-N Access Points (APs).The NWA1100-N is the 802.11n version of ZyXEL’s

entry-level PoE AP with data rates of up to 300 Mbps, while the NWA1100 is an 802.11b/g

PoE AP with data rates up to 54 Mbps.

With the prevalence of the 802.11n standard,Wi-Fi is now fast enough to be considered as

the exclusive network standard for all office users, as such the ZyXEL NWA1100 Series is an

ideal solution that meets small business requirements. Featuring PoE support and multiple

operating modes,the NWA1100 Series provides the highest flexibility for WLAN

deployments.

Benefits

Multiple operating modes and PoE support for easy deployment

The NWA1100 Series has a 4-in-1 design consisting of AP, repeater, bridge and Wi-Fi client

operating modes to provide superior flexibility for WLAN network deployments.

By eliminating the need for AC power adapters, the PoE support of the NWA1100 Series makes it

easier than ever for users to overcome installation difficulties. ZyXEL’s PoE switches and other

802.3af standard-based PoE devices can transmit power and data to the AP simultaneously

utilizing existing Ethernet wires.

Enhanced coverage and data throughput with 11n standard (NWA1100-N

only)

With the newly ratified 802.11n Wi-Fi standard, businesses can now take advantage of high-speed

wireless networking through the 11n-certified ZyXEL NWA1100-N.With the 11n standard and

MIMO technology, the NWA1100-N supports data rates of up to 300 Mbps and provides a wider

coverage with the same transmit power.

Multiple SSID for multiple application services (NWA1100-N only)

The NWA1100-N supports up to 4 SSIDs on one hardware platform, and this turns the unit into

several virtual APs.Businesses can take advantage of this technology to allow the APs to support

several applications such as public Internet access and inventory control.

SNMP management and WiFi-certified security

With a web-based configuration utility, SNMPv3 can be used to configure hundreds of APs with

optional ZyXEL Enterprise Network Center* (ENC) software.The NWA1100 Series is WiFi-certified

for enterprise-class security and IEEE interoperability to work as an ideal choice to establish an

easy-to-use wireless network in the workplace.

* To learn more about ENC, please refer to the ENC datasheet.

5-100-00711002 04/11

For more product information, visit us on the web at www.ZyXEL.com

ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their

respective owners. All specifications are subject to change without notice.

NWA1100 Series

802.11b/g/n PoE

Access Point

NWA1100 Series

802.11b/g/n PoE

Access Point

Specifications

* The output power is measured without antennas.

Model NWA1100 NWA1100-N

Product Name 　802.11b/g PoE AP 802.11b/g/n PoE AP　

Main Design

Wireless Frequency 2.4 GHz 2.4 GHz

Radio 1 1

Number of Antenna 2 2T2R MIMO

Frequency Band 2.4 GHz Bands

USA: 2.412 to 2.462 GHz; ETSI:2.412 to 2.472 GHz;Taiwan: 2.412 to 2.462 GHz

Maximum Output Power*

11b/g USA 23 dBm 20 dBm

Worldwide 17 dBm 16 dBm

11b/g/n USA - 20 dBm

Worldwide - 16 dBm

LAN & WAN

Number of 10/100M LAN 1 -

Number of 10/100/1000M LAN - 1

PoE Yes Yes

PoE Power Draw 7.2 W 10 W

WLAN Features

WLAN Maximum Net Throughput Up to 25 Mbps Up to 110 Mbps

WMM (Wi-Fi Certified) Yes Yes

WEP Yes Yes

WPA/WPA2-PSK Yes Yes

WPA/WPA2-Enterprise Yes Yes

WLAN Access Control List Yes Yes

EAP-TLS,TTLS, PEAP, SIM Yes Yes

Security

IEEE 802.1x Yes Yes

MAC Filtering Yes Yes

RADIUS Authentication Yes Yes

Network

VLANs Yes Yes

DHCP Client Yes Yes

QoS

WMM Yes Yes

DiffServ Marking - -

WLAN Management

Standalone AP Mode Yes Yes

CLI with SSH Yes Yes

SNMP Yes Yes

Standard Compliance

Ethernet IEEE 802.3, IEEE 802.3u, IEEE 802.3af IEEE 802.3, IEEE 802.3u,

IEEE 802.3az, IEEE 802.3af

PoE IEEE 802.3af IEEE 802.3af

802.11b: DBQSK, DQPSK, CCK 802.11b: DBQSK, DQPSK, CCK

Radio Modulation Type 802.11g: BQSK, QPSK, 16-QAM, 64-QAM 802.11g: BQSK, QPSK, 16-QAM, 64-QAM

802.11n: BQSK, QPSK, 16-QAM, 64-QAM

WLAN Management

Radio FCC Part 15C 15.247, ETSI EN 300 328, DGT LP0002

EMC FCC Part 15/107, EN 301 489-17 V1.2.1: 08-2002, EN 301 489-1 V1.5.1:11-2004

Safety EN 60950-1,IEC 60950-1

Environmental Specifications

Operating Temperature 0°C to 50°C/32°F to 122°F

Operating Humidity 20% to 95% (non-condensing)

Storage Temperature -30°C to 60°C/-22°F to 140°F

Storage Humidity 10% to 90%

Physical Specifications

Item Dimensions (WxDxH)(mm)(in.) 152 x 92 x 45 (5.98”x 3.62”x 1.77”) 152 x 92 x 45 (5.98”x 3.62”x 1.77”)

Item Weight (g/lb.) 180/0.40 200/0.44

Packing Dimensions (WxDxH)(mm)(in.) 275 x 147 x 100 (10.82”x 5.79”x 3.94”) 275 x 147 x 100 (10.82”x 5.79”x 3.94”)

Packing Weight (g/lb.) 750/1.66 770/1.70
