zortrax M200 User manual
MANUAL
ENTER AN ENVIRONMENT OF
PROFESSIONAL 3D PRINTING
3
CONTENTS
INTRODUCTION
Thank you for choosing Zortrax M200®
SAFETY
Before you start working with Zortrax M200®
read safety tips
ZORTRAX M200
In the box
Filaments
PREPARATION FOR FIRST USE
Prepare your printer to work
Loading lament
Auto-calibration
SOFTWARE&FIRMWARE
Z-Firmware™ update
Z-Suite® software installation
PRINTING
Start printing
Removing print
Removing support
SUPPORT & MAINTENANCE
Periodic maintenance
Changing the lament
Cleaning the nozzle
Cleaning the platform
Straightening perforated plate
Drive belts maintenance
Drive pulleys maintenance
Lubricating
Extruder maintenance
TROUBLESHOOTING
DICTIONARY
SPECIFICATIONS
4
4
5
5
5
6
7
9
11
11
13
16
16
16
17
17
18
19
20
21
22
22
23
24
25
27
31
33
37
38
40
4
Thank you for choosing Zortrax M200®
Zortrax M200® manual allow you to easily and securely install and
congure our product. Keep it in a safe place so you can use it if
needed.
In the Contents you will nd a description of the solutions used
in Zortrax M200® 3D printer. To use current software version,
download latest updates from www.zortrax.com
Lear more about all Zortrax® products. Contact us via email
Information given in all Zortrax® documents and help system
related to this software may change without prior notice. No part
of this manual may be copied, sent over, stored in an information
retrieval systems or translated to any language in any way using any
media (electronic, mechanical, photocopying, recording or other)
without the written permission of Zortrax sp. z o.o.
Zortrax® company may possess patents, copyright, trademarks
and other intellectual property rights for content and documents.
Transmission of this document and other documents is not
tantamount to granting a license to this patents, copyrights,
trademarks and other intellectual property, unless it was explicitly
stated in the written license given by Zortrax sp. z o.o.
INTRODUCTION
5
Before you start working with Zortrax M200® read safety tips:
• Never touch the model, hotend or platform during printing
process – there is a risk of burns and deformation of model.
Remember to always wait until the printer parts cool down
(~30min.).
• Stay away from workspace during printing process – do not put
hands or any other parts of your body inside the workspace - it
may cause burns and printer damage.
• Always use safety gloves when removing the platform.
• Wear safety glasses when removing the model from the
platform.
• Never touch heated extruder – even with safety gloves.
SAFETY
Caution – these actions may harm you if you won’t follow the instruction.
Wear safety glasses - risk of injury to eyes.
Wear safety gloves - risk of burns.
SAFETY SIGNS USED IN THIS TEXT:
6
ZORTRAX M200
3D printing is a technology for industry and design.
Using 3D printer in technical and design studios
lowers the costs of prototyping.
The integration of key elements of the printer -
dedicated Z-Suite® software and composition of
the Z-Filaments™ let us create new 3D printing
technology – Layer Plastic Deposition (LPD™). With
LPD™ technology you can create precisely projected
model. Precise layered process of the lament
application makes printed elements suitable for
prototyping models in molding technology.
7
Zortrax M200®
3D Printer
Filament Spool
Holder Filament Guide Filament
Spool
Build
Platform Power Cable
SD Card
&
SD Card Reader
Z-Suite®*
&
Quick Start Guide
Safety
Gloves
Cutting Knife
&
Scalpel
Allen Keys
Nozzle Key
&
Nozzle Needle
Pliers
Spatula
&
Tweezers
Service Grease Safety Glasses
* online
IN THE BOX
8
Extruder Extruder Cable
Filament
Guide
Power Connector
and Switch
Build Platform Display
Z Axis Screw Control
Knob
Filament Mount
HotendFilament
OVERVIEW
9
PRINTING MATERIALS OVERVIEW
For Zortrax M200® we use high quality thermoplastic material –
laments. All our materials have carefully selected composition and
properties. We advise you to print with dedicated laments only.
Only Z-Filaments™ guarantee safe and high quality prints.
USING OTHER FILAMENTS THAT DEDICATED
Unlike inkjet printers, printing materials for 3D printers need to be
prepared strictly for a particular model of the machine. Filaments
from all manufacturers have dierent physical and chemical
properties, even at similar terminology.
Using laments from dierent manufacturers you risk printing
problems and extruder clogging – even if you use high quality
laments. Zortrax M200® is adjusted to work with Z-Filaments™
only. Only Z-Filaments™ guarantee safely and trouble-free operation
of your printer. Using laments from other store, than Zortrax
Store, you automatically loose Z-Care 1-st Year Service Program™.
To buy dedicated laments please go to www.zortrax.com/store
* available soon
10
MATERIAL PROPERTIES
Z-ABS™ Suitable for mechanical
treatment High printing precision Available in a wide range of
colors Suitable for utility models
Z-ULTRAT™ Suitable for mechanical
treatment Durable High quality prints Suitable for large prints
Z-FLEX™*Suitable for mechanical
treatment Elastic Models are exible and elastic For malleable models e.g. seals
Z-PCABS™*Resistant to cracking Highly durable Resistant to high temperature Used for automotive parts
Z-GLASS™*Suitable for mechanical
treatment Fragile Transparent Used for decorative parts
Z-ALU™*Suitable for mechanical
treatment Fragile Unique texture of prints Imitates metal
Z-NYLON™*Elastic, extensile Highly durable Bendable For elements subjected to load
PRINTING MATERIALS OVERVIEW
