Zonet ZSR9104WE User manual
Copyright Statement
is the registered trademark of Zonet Technology Inc. All the products
and product names mentioned herein are the trademarks or registered trademarks of
their respective holders. Copyright of the whole product as integration, including its
accessories and software, belongs to Zonet Technology Inc. ithout the permission of
Zonet Technology Inc., any individual or party is not allowed to copy, plagiarize, imitate
or translate it into other languages.
Table of Contents
Chapter 1 Introduction......................................................................... 1
elcome.............................................................................................. 1
Contents of Package .............................................................................. 1
System Requirement ............................................................................. 1
Getting to Know Your ZSR9104 E .......................................................... 2
Chapter 2 Installation ......................................................................... 4
Hardware Installation ............................................................................ 4
all Mount Installation .......................................................................... 7
Chapter 3 Configure Your Computer................................................... 9
TCP/IP Address Setting .......................................................................... 9
How to Check the Network Connection....................................................15
Chapter 4 Basic Configurations ...........................................................16
How to Access the eb-based Configuration Utility ..................................16
Setup izard.......................................................................................17
Chapter 5 Advanced ettings ..............................................................21
LAN Settings .......................................................................................21
AN Settings ......................................................................................22
MAC Address Clone ..............................................................................23
DNS Settings .....................................................................................26
Chapter 6 Wireless ettings ................................................................27
Basic Settings......................................................................................27
ireless Security Settings .....................................................................29
Advanced ireless Settings ...................................................................30
PS Settings.......................................................................................31
DS Settings ......................................................................................32
ireless Access Control ........................................................................36
ireless Connection Status ...................................................................37
Chapter 7 DHCP erver .......................................................................38
DHCP Server .......................................................................................38
DHCP Server List & Binding ...................................................................39
Chapter 8 Virtual erver......................................................................40
Port Range Forwarding..........................................................................40
DMZ Settings.......................................................................................41
UPnP Settings......................................................................................41
Chapter 9 Traffic Control ...................................................................42
Chapter 10 ecurity ettings...............................................................43
Client Filter .........................................................................................43
URL Filter............................................................................................44
MAC Filter ...........................................................................................45
Prevent Network Attack ........................................................................45
Remote EB Management ....................................................................46
an Ping ............................................................................................46
Chapter 11 Routing ettings ...............................................................47
Routing Table .....................................................................................47
Chapter 12 ystem Tools.....................................................................48
Time Settings ......................................................................................48
DDNS .................................................................................................48
Backup/Restore ...................................................................................49
Upgrade..............................................................................................49
Restore to Factory Default Settings ........................................................50
Reboot................................................................................................50
Change Password.................................................................................51
System Log .........................................................................................51
Appendix 1 Product Features & pecifications ..................................52
Appendix 2 Troubleshooting...............................................................54
1
Chapter 1 Introduction
Welcome
Thank you for purchasing Zonet ZSR9104 E – High Gain ireless N Router!
This high cost-efficiency router is the best choice for Small office / Home office
users, all computers and network devices can share a single xDSL / cable
modem internet connection at high speed. Easy install procedures allows any
computer users to setup a network environment in very short time - within
minutes, even inexperienced. hen the number of your computers and
network-enabled devices grow, you can also expand the number of network slot
by simple attach a hub or switch, to extend the scope of your network!
All computers and IEEE 802.11b/g/n wireless-enabled network devices
(including PDA, cellular phone, game console, and more!) can connect to
ZSR9104 E without additional cabling. The MIMO technology also gives you
the highest speed of wireless experience ever! ith a compatible wireless card
installed in your PC, you can transfer file for up to 300Mbps! The radio coverage
is also doubled, so don’t worry if your office or house is really big!
Moreover, the user-friendly Setup izard on the installation CD can assist you
to set up ZSR9104 E easily. It also can be managed or configured through
Local/Remote easy-to-use eb-based utility.
Contents of Package
One ZSR9104 E
One CD w/User Manual
One Quick Installation Guide
Two 7dBi Antennas
One Antenna Base
One all Mount Kit
One Cradle
One Power Adapter
One RJ-45 Ethernet Cable
Contact your local authorized reseller or the store purchased from for any items
damaged and/or missing.
ystem Requirements
Internet connection, provided by xDSL or cable modem with a RJ-45
Ethernet port.
Computer or network devices with wired or wireless network interface card.
eb browser (Microsoft Internet Explorer 6.0 or above, Firefox 2.0 or
above).
An available power socket (100–240V, 50/60Hz)
2
Getting to Know Your Z R9104WE
Top Panel
LED Indicator
tatus Description
PO ER ON ZSR9104 E is switched on and correctly powered
SYS Flashing Indicates the system works normally.
ON Indicates AN port is connected
AN Flashing Indicates AN activity (transferring or receiving
data)
LAN Flashing Indicates the wireless signal is OK.
ON Indicates LAN port is connected
LAN(1/2/3/4) Flashing Indicates LAN activity (transferring or receiving
data)
PS Flashing Indicates ZSR9104 E is negotiating with PS
clients in PS Mode (PBC or PIN).
3
Rear Panel
Item Name Description
Antenna These antennas are 7dBi dipole antennas.
PO ER Power connector, connects to power adapter
AN ide Area Network ( AN / Internet) port.
1-4 (LAN Ports) Local Area Network (LAN) ports 1 to 4
RESET/ PS
Reset ZSR9104 E to factory default settings (clear all
settings) or start PS function. Press this button and hold
for 7 seconds to restore all settings to factory defaults,
and press this button for 1 second to start PS function.
4
Chapter 2 Installation
Hardware Installation
Note: Before connecting ZSR9104WE, be sure to power off your computer, DSL Cable
modem, and ZSR9104WE.
1. Screw 2 applied antennas to the antenna base.
2. Attach the antennas to ZSR9104 E by connecting 2 antenna connectors at
the end of the cable.
5
3. Connect all your computers, network devices (network-enabled consumer
devices other than computers, like game console, or switch / hub) to the LAN
port of ZSR9104 E.
4. Connect the power adapter to the wall socket, and then connect it to the
“Power” socket of ZSR9104 E.
6
5. Connect your xDSL / cable modem to the AN port of ZSR9104 E by
Ethernet cable.
6. Please check all LEDs on the top panel.
PO ER LED should be steadily on.
AN and LAN LEDs should be on if the computer / network device
connected to the respective port of ZSR9104 E is powered on and
correctly connected.
Note: If any LED you expected is not on, please recheck the cabling, or jump to
“Troubleshooting” for possible reasons and solution.
