ZENEC Z-E6150 User manual

Z-E6150

INSTALLATION MANUAL

COMPATIBILITY LIST

1. Ifyourvehiclehasabasicfactory-tted

radio(similartotheonepicturedhere),

youneedtoacquireasuitableToyota

coverforyourvehiclebeforeyoucan

installyourZ-E6150.

2. Ifyourvehiclehasahigh-quality

factory-ttedradio(asshownhere

H=100mm,B=200mm),youcan

easilyswaptoaZ-E6150.

1 2

NOTE

● Theinformationinthecompatibilitylistissubjecttocorrection.Dependingontheequipmentttedin

yourvehicle,youmayrequireanadditionaloriginalToyotacover.Theseareavailableonlineorfromyour

Toyotadealer.

ThefollowingsectionshowshowtotellthedifferenceonthebasisofaToyotaAvensis3G(TypeT27).

Manufacturer Model Model type Model year

Toyota Auris 1GTypeE150 2006–2012

Toyota Avensis 1GTypeT22 2001–2003

Toyota Avensis 2GTypeT25 2003–2009

Toyota Avensis 3GTypeT27 2009–2015

Toyota AvensisVerso – 2001–2005

Toyota Camry 5GTypeXV30 2001–2006

Toyota Celica 7GTypeT23 1999–2005

Toyota Corolla 9GTypeE120 2001–2007

Toyota Corolla 10GTypeE14/15 2007–2013

Toyota CorollaVerso 2GTypeZER/ZZE 2004–2009

Toyota GT86 – from2012

Toyota Hilux 7GTypeT25 2005–2015

Toyota Previa/Estima 2GTypeXR30/XR40 2000–2006

Toyota RAV4 2GTypeACA20/21ZCA25/26 2001–2006

Toyota RAV4 3GTypeCA30W 2006–2013

Toyota Ya r is 2GTypeXP9 2006–2011

Subaru BRZ – from2012

ATTENTION

● TheZENECsystemshouldbeinstalledbyanauthorisedretailer.Specicknowledgeandtoolsare

 requiredforinstallation.IncorrectinstallationcandamagethevehicleandtheZENECsystem.

● Fault-freeoperationcanonlybeguaranteedifyouusetheequipmentsupplied,ortheoptionalZENEC

originalaccessories.TheZENECsystemandoriginalaccessoriesmustneverbemodiedoralteredin

anyway.

IncorrecthandlingcandamagethevehicleandtheZENECsystem.

NOTE

● TheZENECZ-E6150isequippedwithanintegratedDAB+receiver.Touseit,youneedasuitableDAB

antenna(notsupplied),whichmustbeconnectedtotheZENECsystem.

● IfthetargetvehicleisttedwithanoriginalDABantenna,itcanstillbeusedinconjunctionwiththe

ZENECsystem.

● ZENECsystemsoftwareupdatesareinstalledusingaUSBdatastick.Youmustthereforeensure

thattheUSBconnectionontheZENECsystemremainsaccessibleduringinstallation(installationof

USBextension).

● IfyouhaveanyqueriesorproblemswiththeZENECsystem,pleasecontacttheretailerwhereyou

purchasedit.

SUPPLIED ITEMS

No. Item Quantity

1ZENECsystem 1

2MainpowercableforToyota 1

3 20-pincable(AUX-IN/SWC) 1

4 28-pincable(AUX-IN/SWC/Rev.) 1

5 24-pinconnectioncable(4.2,Cam,MZone,Mic) 1

No. Item Quantity

6 FMISOantennainterfaceforToyota 1

7 1mUSBextensioncable 1

8 Cableforhandbrakecontact 1

9 GPSantennawithcableandFakraplug 1

10 Mainunitmanual 1

TOOLS REQUIRED

●Ratchetwith10mmhexnut

●Cross-headscrewdriver(PhillipsPH2)

●Plasticlevertool

●Insulatingtape

OPTIONAL INSTALLATION ACCESSORIES

●DABantennawithSMBplug(e.g.Z-EACC-DAB1orZ-EACC-DAB2)

●Externalmicrophone(N-ZENC-MIC)

Example of installation: Toyota Avensis 3G (Type T27)

Disassembly and preparation:

NOTE

1. Removetheignitionkeyandleaveitoutsidethevehicleforthedurationofinstallation.

2. Startwiththeuninstallationoftheoriginalunit.

3. Donotswitchtheignitionbackonuntilallthepointsintheassemblymanualhavebeencompleted

andtheZENECsystemhasbeenfullyinstalled.

1. Levertheplasticcoverontherightofthecen-

treconsoleoutofitsxture,asshowninthe

diagram.Yourequireaplasticlevertoolforthis

step.

2. Levertheplasticcoverontheleftofthecentre

consoleoutofitsxture,asshowninthedia-

gram.Yourequireaplasticlevertoolforthis

step.

3. Tobeginwith,levertheradiocover/airventnoz-

zleupwardsoutofitsxture.Slidethelevertool

aroundtheplasticframeoncefromrighttoleft.

4. Removethelowersectionofthecoverfromits

xture.Thereisaconnectionforthehazardlight

switchontherearofthecover.Youmustdis-

connectthisbeforeremovingtheplasticframe

completely.

5. UnscrewandremovethefourPhillips(PH2)or

hex(10mm)screwsfromtheoriginalunit.

6. Carefullypulltheoriginalunitoutoftheradiobay.

Thenunplugallcablesontherearoftheunit.

7. Transfertheoriginalradiobrackets(leftand

right)toyourZENECsystem.

8. (Nopicture)

 InstalltheGPSantenna(No.9)inasuitable

position,makingsurethattheGPSreceptionis

notadverselyaffectedbyunwantedshieldingof

metallicvehicleparts(thermalinsulationglazing,

etc.).Thenroutetheconnectioncableintothe

radiobay.

9. (Nopicture)

 IfyouhavepurchasedtheoptionalexternalBlue-

toothmicrophone(N-ZENC-MIC),installitnow

andtheninserttheconnectioncableintotheradio

bay.Dependingonyourpreference,andwhether

youselectaninternalorexternalmicrophone,the

microphonesourceforBluetoothmodemustbe

setaccordinglyintheunitmenu.

10. (Nopicture)

 RoutetheUSBextensioncable(No.7)fromthe

radiobaytoyourpreferredposition.

Installation:

11. Connectthemainconnectioncable(No.2)ofthe

ZENECsystem(No.1)tothetworadioplugson

the vehicle.

 Dependingonyourvehicle,youmustuseeither

the20-pin(No.3)orthe28-pinconnector(No.4)

tooperatetheAUXconnectorandthesteering

wheelremotecontrol.Youmustconnecttheseto

themainconnectioncable.

 Thereversegearsignalissupportedonlybythe

28-pinconnector(No.4).Ifyourvehicleistted

witha20-pinconnector(No.3),youneedtouse

agaugetosearchforthereversegearsignaland

connectitdirectlytothemainconnectioncable

(No.2).

 IfyoucannotndanISOantennapluginyour

vehicle,itismostlikelythatyourvehicleisusing

aspecialToyotaantennaplug.Ifthisisthecase,

thesetincludesaFMISOantennainterface(No.

6)whichyoucansimplyconnecttotheoriginal

unit.Iftheantennaisactive,youmustalsocon-

nectthebluephantompowercabletothemain

connectioncable(No.2).

12. Removebothscrewsfromthetransportlock

priortoinstallingtheZENECsystem(No.1).

13. (Nopicture)

Connectallcablespreviouslyinstalledinthe

radiobaytotheZENECsystem(No.1).

14.Carefullyroutethevariousconnectioncablesof

theZENECsysteminthelowersectionofthe

radiobay.ThenslidetheZENECsystemcareful-

lyintotheradiobaybyapplyingcontrolledforce.

ScrewitbackintopositionwiththefourPhillips

(PH2)orhex(10mm)screws.

15. Youmustreattachtheradiocoveronceyou

havexedtheZENECsystembackintoposition.

Remembertoreconnecttheplugforthehazard

lightstotherearoftheradiocover.Tonishin-

stallation,simplyattachtheplasticcoverstothe

leftandrightofthecentreconsole.

NOTE

● Ensurethatalltheplugsontherearoftheunithavesufcientclearanceandarenotkinked.

● Anyplug-inconnectionswhichdonothaveasecuringmechanismmustalsobesecuredwith

insulatingtape.

STARTUP

Finally,carryoutageneralfunctiontestandperformthebasicsettingsandvehicle-specicsettings(steering

wheelremotecontrol,etc.).Alsomakesurethatnoerrormessagesaredisplayedinthevehicle.

B24 B2

B23 B1

E14 E1

E28 E15

C6 C3

C2 C1

D20 D11

D10 D1

B4 B1

B10 B5

20PINCONNECTOR

(DEVICEBACKSIDE)

A11

A10

A20

Z-E6150

DAB HDMI

USB 2

GPS

UKW/

USB 1

CONNECTION DIAGRAM

USB1:

•AppleMFI

•USBMediaPlayback-SmartlinkDirect-SoftwareUpdates

USB2

•AppleMFI

•USBMediaPlayback-SmartlinkDirect-SoftwareUpdates

A1 N.A.

A2 Reverse

A3 KL15/Switched+12VPWR

A4 Illumination

A5 AnalogWheelKEY2

A6 AnalogWheelKEY1

A7 SpeakerRearLeft(-)

A8 SpeakerRearLeft(+)

A9 SpeakerFrontLeft(-)

A10 SpeakerFrontLeft(+)

D6 N.A.

D7 Reverse

D8 KL15/Switched+12VPWR

D15 AUXright

D16 AUXGND

D17 AUXleft

E1 AUXleft

E2 AUXGND

E3 AUXright

E6 AnalogWheelKEYGND

E7 AnalogWheelKEY2

E8 AnalogWheelKEY1

E27 Reverse

B1 RearMonitorOut

B2 FCameraIN

B3 RCameraIN

B4 VideoIN

B5 AUXINL

B6 AUXINR

B7 LineOutRearL

B8 LineOutRearR

B9 LineOutFrontL

B10 LineOutFrontR

B11 LineOutSubWoofer

B12 LineOutSubWoofer

B13 MIC

B14 FrontCamera12Vmax300mA

B15 IR/IN

B16 GND

B17 GND

B18 RearCamera12Vmax300mA

B19 N.A.

B20 N.A.

B21 N.A.

B22 N.A.

B23 N.A.

B24 N.A.

B1 SpeakerFrontRight(+)

B2 SpeakerFrontLeft(+)

B3 KL15/Switched+12VPWR

B4 KL30/Constant+12VPWR

B5 SpeakerFrontRight(-)

B6 SpeakerFrontLeft(-)

B7 KL31/PowerGND

B8 P.ANT

B9 N.A.

B10 Illumination

C1 SpeakerRearRight(+)

C2 SpeakerRearLeft(+)

C3 SpeakerRearRight(-)

C4 N.A.

C5 N.A.

C6 SpeakerRearLeft(-)

F1 P.ANT

F2 N.A.

F3 FMAntenna

A11 N.A.

A12 P.ANT+12V**(Antenna)

A13 P.CNTR+12V**(Amplier)

A14 Parking

A15 KL31/PowerGND

A16 KL30/Constant+12VPWR

A17 SpeakerRearRight(-)

A18 SpeakerRearRight(+)

A19 SpeakerFrontRight(-)

A20 SpeakerFrontRight(+)

**300mAmaxcurrent

*Connectionofthe20-pinor28-pin

plugdependsonvehicle

Connectionofthe20-pinor28-pin

plugdependsonvehicle

E D

DAB

USB1

USB2

HDMI

28Pin 20Pin

P.ANT

B C

AUX-INR

AUX-INL

AUX-INR

AUX-INL

Rev.

AnalogWheelKEY(KEY1/KEY2/GND)

B13

B12

B11

B10

B15

B14

B17

B16

B18

“E”or“D”con-

nectioncable

dependson

the vehicle!

Technicalmodificationsexcepted.Noliabilityforprintingerrors.
