Zanussi Professional 700 User manual
ZANUSSI
P R O F E S S I O N A L
2/4 BURNER GAS BOILING TOPS
N 700
178000
Net weight - kg. 20 38
gas 11 22
Power - kW
Front burners power - kW 5.5 5.5, 5.5
Front burners dimension - mm Ø 60 Ø 60, Ø 60
Back burners power - kW 5.5 5.5, 5.5
Back burner dimensions - mm Ø 60 Ø 60, Ø 60
height 250 250
depth 700 700
width 400 800
External dimensions - mm
Power supply Gas Gas
KCG400
178000
KCG800
178001
CHARACTERISTICS MODELS
TECHNICAL DATA
RANGE
COMPOSITION
N 700: a range of over 100 models
for the professional caterer designed
to guarantee the highest level of
performance, reliability, energy
saving, safety standards and
ergonomic operation. These
concepts are reflected in the total
modularity of the range that ensures
numerous configurations, either
free-standing or bridged. N 700
demonstrates how advanced
technology can satisfy the needs of
the professional caterer.
The models detailed on this sheet
are 2 and 4 burners gas boiling tops.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
� Burners:
- Flame failure.
- 5,5 kW with flame regulator.
- Pilot light for each burner.
� All models have right-angled side
edges to allow flush-fitting joins
between units.
� Pan supports are cast iron.
� IPX4 water protection.
� Main connections can be via the
rear or the base of the unit.
� All models can be easily mounted
on open base cupboards or bridging
supports.
� All top models provided with
service duct to facilitate installation.
� All gas appliances are supplied for
use with natural gas, LPG or town
gas. Conversion jets supplied as
standard.
� Worktop in 1,5mm stainless steel.
Front panel in stainless steel with
Scotch Brite finish.
2/4 BURNER GAS BOILING TOPS
N 700
BABB1 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L
WATER COLUMN WITH SWIVEL ARM 206289 206289
WATER COLUMN EXTENSION FOR 700 LINE 206291 206291
SUPPORT FOR "BRIDGE" SYSTEM 800 MM 206137 206137
SUPPORT FOR "BRIDGE" SYSTEM 400 MM 206154 206154
SUPPORT FOR "BRIDGE" SYSTEM 1600 MM 206141 206141
SUPPORT FOR "BRIDGE" SYSTEM 1400 MM 206140 206140
SUPPORT FOR "BRIDGE" SYSTEM 1200 MM 206139 206139
SUPPORT FOR "BRIDGE" SYSTEM 1000 MM 206138 206138
SINGLE BURNER SMOOTH PLATE 206260 206260
SINGLE BURNER RIBBED PLATE 206261 206261
SINGLE BURNER RADIANT PLATE 206264 206264
S/S GRID FOR DOUBLE BURNER-700 LINE 206297 206297
RIGHT AND LEFT SIDE HANDRAILS 206240 206240
PRESSURE REGULATOR FOR GAS UNITS 927225 927225
LARGE HANDRAIL(PORTIONING SHELF)800 MM 206186 206186
LARGE HANDRAIL(PORTIONING SHELF)400 MM 206185 206185
FRONTAL HANDRAIL 800 MM 206167 206167
FRONTAL HANDRAIL 400 MM 206166 206166
FRONTAL HANDRAIL 1600 MM 206192 206192
FRONTAL HANDRAIL 1200 MM 206191 206191
DOUBLE BURNER SMOOTH PLATE 921684 921684
DOUBLE BURNER RIBBED PLATE 921685 921685
CHIMNEY UPSTAND 800MM 206304
CHIMNEY UPSTAND 400MM 206303
CHIMNEY COVER 800MM OPEN-SMALL CHIMNEY 206272
CHIMNEY COVER 400MM CLOSED 206269
2 SIDE COVERING PANELS FOR TOP-D=700MM 206277 206277
KCG400
178000
KCG800
178001
ACCESSORIES MODELS
OPTIONAL ACCESSORIES
2/4 BURNER GAS BOILING TOPS
N 700
BABB1 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L
G - Gas connection 1/2"
KCG400
178000
LEGEND
178000
2/4 BURNER GAS BOILING TOPS
N 700
BABB1 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L
G - Gas connection 1/2"
KCG800
178001
LEGEND
178001
