ZANE ARTS LT-230 User manual
LT-230 / COZ HANGER 30
LT-232 / COZ HANGER 32
MANUAL - Ver 1.01
EN
2
Metal Lock
Nut
Silicone Band
Hook
Clamp
■ PARTS NAME
Please be sure to read the manual before using this product.
If you have any questions or if there is a problem with the
product, please contact the store where you purchased the
product or us directly.
Maximum Load 2kg
3
The maximum load capacity is 2kg. For fuel-burning lanterns,
such as gas or kerosene, the lantern should weigh 2kg or less
with fuel.
2kg
Hanging more than 2
kg may damage the
product or cause it to
drop out.
■ABOUT THIS PRODUCT
Please take some time to understand the characteristics of
this product before using it.
●High risk of fire. Never use gas, gasoline, or kerosene
lanterns under or near flammable objects such as tents,
shelters, tarps, and trees.
●When using this product with gas lanterns, please take extra
precaution not to drop the hanger from the pole. The gas
lantern may become damaged by the fall, causing fuel to
leak and the risk of fire.
●The maximum load capacity is 2kg. For fuel-burning lanterns,
such as gas or kerosene, the lantern should weigh 2kg or less
with fuel.
4
■ Handling Precautions
Be sure to read and understand the following contents
before use to prevent harm to the user and others, and
damage to property.
INDICATES CONTENT THAT MAY RESULT
IN DEATH OR SERIOUS INJURY.
!
!
DANGER
●Only attach this product to stable poles. If your poles
unstable, please try resetting them, or refrain from using this
product.
●Attach to upright poles only. Attaching the hanger to a pole
set on an angle is dangerous.
●May slip or not securely attach to wet or oily poles.
●Sand or dirt on the silicone band and clamp may cause the
hanger to slip or not securely fix to a pole.
●Do not use in rainy or high wind conditions.
There is a higher risk of the hanger falling under such
conditions.
●Please use this product with the correct pole size. Use on an
incorrect pole size may cause the product to not fasten
securely or to become damaged.
●Please confirm that the nut and silicone band are secure
before hanging a lantern.
●Remove the lantern when sleeping or when away.
●Please remove your lantern from the hanger before pumping,
refueling, or replacing a cartridge.
●Inspect the connecting parts after each use. If any
abnormality is found in the product immediately stop using.
5
6
●This product is for temporary outdoor use only. Do not install
permanently or use in undesignated ways.
●After each use, wipe off any moisture and dry thoroughly
before storing. If stored wet or uncleaned the product may
corrode.
●Salt accelerates corrosion. When used near the ocean
always wash with fresh water and dry thoroughly before
storing.
●Please keep out of reach of infants and children.
●Do not modify this product, it may impair its performance.
INDICATES CONTENT THAT MAY CAUSE
INJURIES OR PROPERTY DAMAGE.
WARNING
!
■ SETUP PROCEDURES
7
ATTACH TO POLE
1
Check the Size
φ30 mm Pole (30)
φ32 mm Pole (32)
A: Check the size on the top of the clamp.
B: Open the silicone band and metal lock.
C: Attach the clamp to the pole.
Silicone Band
Metal Lock
Clamp
Image of Coz Hanger from above
32
Pole
A
B
C
8
FASTEN SILICONE BAND
2
When the silicone band
is being closed, the metal
lock will move in tandem.
A: Wrap the silicone band around the pole.
B: Lock the silicone band to the hook on the clamp.
C: Installation is complete when the metal
lock is securely touching the clamp.
Pole
A
C
B
Hook
Silicone
Band
For size 32,
use the first hole
For size 30,
use the second hole
First hole
32
Second hole
■ PRECAUTIONS DURING REMOVAL
9
When removing the hanger from the pole, be sure to fully open,
not only the silicone band but also the metal clamp.
Removing the hanger while the metal lock is closed may cause
the pole to be scratched or the lock to be disfigured.
Silicone Band
Be sure to open the
metal lock before removing.
Metal Lock
Image of Coz Hanger from above
Pole
10
■WARRANTY AND REPAIR
If you find any defects in the product, please contact the store where you
purchased it or us directly. We will replace or repair any item found to have
a manufacturing defect free of charge. We will repair products with damage
caused by wear and aging at a reasonable price. Please note that it may be
difficult to obtain some materials due to the discontinuation of products and
parts, and repairs may not be possible based on the condition of the
product.
※When sending a product for repair, please remove dirt and moisture from
the product before sending it. Moisture and dirt may interfere with repairs.
Items that are not clean and dry upon arrival for repair will incur additional
charges at their own expense for cleaning. Thank you for your
understanding.
Zain Arts Co., Ltd.
7190-2 Shimauchi, Matsumoto, Nagano 390-0851
Phone: 0263-87-2955 FAX: 0263-87-2966
