ZALMAN CNPS9700 LED User manual
* Please read this manual thoroughly before installation.
http://www.zalman.co.kr http://www.zalmanusa.com
IInntteell SSoocckkeett 777755 CCPPUU
Core 2 Duo
Dual Core Pentium
Pentium D
Pentium 4
Celeron D
AAMMDD SSoocckkeett AAMM22//775544//993399//994400 CCPPUU
Athlon 64 FX
Athlon 64 X2 Dual- Core
Athlon 64
Opteron
Sempron
(English version)
CNPS9700 NT
※
The specifications of any product may change without prior notice to improve performance.
1
3. Exploded View
Fan
Fan Support
CPU Block Cover
Heat sink
CPU Block Fixing Bolt
1. Features
1) Compatible with all single and dual core CPUs or Intel Socket 775 and AMD Sockets AM2/754/939/940.
2) Automatic Fan Speed Control eature included in the Ultra Quiet 110mm PWM(Pulse Width Modulation)
enabled an.
3) 100% copper heatsink with aerodynamically optimized “tunnel” design or maximum cooling e iciency.
4) Innovative, patented, “ igure 8” heatpipe design or a heat trans er capacity o up to six heatpipes with
the use o just three.
5) 0.2mm ultra-slim ins or minimized weight and reduced air low resistance.
6) Super Thermal Grease (ZM-STG1) included.
Rotation Speed
Note (1) The maximum weight or a cooler is speci ied as 450g or Intel Socket 775 and AMD Sockets
AM2/754/939/940. Special care should be taken when moving a computer equipped with a cooler
that exceeds the speci ied weight limit. Zalman is not responsible or any damage that occurs when
moving a computer.
Note (2) Measured at 1m rom noise source.
Note (3) Optimal per ormance will be reached a ter approximately 7 days o regular computer use rom the
time o installation.
CNPS9700 NT
Model
Spec.
Materials
Dimensions
(mm)
Heat Dissipation Area (
㎠
)
Weight(g)
Bearing Type
Noise Level (dBA)
Control Method
Capacity
Temperature Range
Pure Copper and Aluminum
90(L) X 124(W) X 142(H)
5,490
Heatsink : 690g, Total (including fan) : 764g
(1)
2 Ball-Bearing
1,250RPM ± 30 % ~ 2,800RPM ± 10 %
19.5dBA ~ 35dBA ± 10%
(2)
PWM Control, Auto Restart
3.5g
-40℃~150℃ (-40℉~302℉)
2. Specificatio s
Fan
ZM-STG1
(3)
※
The specifications of any product may change without prior notice to improve performance.
2
Korean Patent Reg. No. 10-0600448
Korean Design Reg. No. 30-0403411, 0403412
Patent applications pending in over 20 nations around the world including USA, EU, and Japan.
4. Pate ts
1) Excessive orce exerted on the an may damage the an, resulting in damage to the system.
2) Avoid inserting any objects into the an while it is in operation.
3) Use and keep the product away rom the reach o children and pets.
4) Check the components list and condition o the product be ore installation. I any problem is ound, contact
your place o purchase to obtain a replacement.
5) Do not ingest or make oral contact with the Thermal Grease. I ingested, get medical attention.
Disclaimer)
Zalman Tech Co., Ltd. is not responsible or any damages due to external causes, including but not limited
to, improper use, problems with electrical power, accident, neglect, alteration, repair, improper installation,
or improper testing.
5. Precautio s
7. Compatible CPUs
1) All Intel CPUs o Socket 775
2) All AMD CPUs o Socket AM2/754/939/940
2) Components for A D Sockets A 2/754/939/940
❹
One (1) Clip or AMD Sockets
❺
One (1) Clip Lever or AMD Sockets
3) Components for Intel Socket 775
❻
One (1) Clip (S-Type)
❼
Four (4) Bolts ( or installing the cooler)
❽
Four (4) Clip Support Fixing Bolts or Socket 775
❾
One (1) Clip Support or Socket 775
❿
One (1) Backplate or Socket 775
1) General Components
❶
One (1) CNPS9700
❷
One (1) Thermal Grease (ZM-STG1)
❸
One (1) User’s Manual
6. Compo e ts
❶
❺
❹
❷
❿
❸
❼
❽
❾
❻
※
The specifications of any product may change without prior notice to improve performance.
3
8. I stallatio Requireme ts
I the case is equipped with an Air Guide, then the Air Guide Duct must be removed be ore installation.
Re er to the ollowing diagrams, and install only on systems that meet the ollowing installation requirements :
①
No inter ering components (PSU, graphic card etc.) within 62mm rom the center o the CPU.
No inter ering components (ODD etc.) within 48mm rom the center o the CPU.
Case cover must be at least 150mm apart rom the motherboard.
9. I stallatio
※※
The Clip Installation ethod
The CNPS9700 must be installed in the orientation that matches the rear system fan’s airflow.
(Re er to the diagram above)
The Clip installation method depends on the motherboard’s socket orientation.
Follow the correct installation method or your motherboard type.
Be care ul not to exert excessive orce on the an during installation o the Clip, as it may damage the an.
A. For motherboards with a horizontally-oriented Retention Guide
B. For motherboards with a vertically-oriented Retention Guide
Retention Guide
Clip
Retention Guide
Clip
Case Cover
150mm
Motherboard
PSU
62mm
62mm
System Fan
Air Flow
Case
48mm
Graphic Card Slot
※
The specifications of any product may change without prior notice to improve performance.
4
⑤⑤
Power Connection
◆
Please re er to “10. Power Connection” on page 6.
1) Intel Socket 775
①①
Clip Installation
Re er to “The Clip Installation Method” on page 3 to correctly install the Clip (S-Type,
⑥
) according to
the orientation o the Retention Guide.
②②
Clip Support Installation
Align the Clip Support or Socket 775 (
⑨
) and the Backplate or Socket 775 (
⑩
) with the mounting holes
on the motherboard, and asten them together by using the Clip Support Fixing Bolts (
⑧
).
The Lever Slot on the Clip Support or Socket 775 (
⑨
) must be properly oriented on the hinged side
o the socket lever when installing.
※
The Backplate Support on the Backplate or Socket 775 (
⑩
) can be removed i deemed unnecessary.
③③
Thermal Grease Application
Clear o particles or any residue rom the contact sur ace o the CPU and heatsink. Shake the
Thermal Grease (ZM-STG1,
②
) well then apply on the contact sur ace o the CPU and heatsink base.
CPUCPU
CPUCPU
※
Note
When installing the CNPS9700 on a motherboard with a horizontally-
oriented Retention Guide, take extra care to not exert excessive orce
on the an. Excessive force may damage the fan.
Clip Support Fixing Bolt, ⑧
Clip Support or Socket 775, ⑨
Motherboard
Backplate or Socket 775, ⑩
Backplate Support
Socket Lever Hinge
Socket Lever
Lever Slot
④④
Cooler Installation
Insert two Bolts (
⑦
) into the holes o the Clip (S-type,
⑥
) and
place the CNPS9700 on the center o the CPU. Slightly asten
the Bolts (
⑦
) into the holes o the Clip Support or Socket 775
(
⑨
), then asten the Bolts (
⑦
) in an alternating manner until the
Clip (S-Type,
⑥
) is completely pressed against the Clip Support
or Socket 775.
Bolt, ⑦
Clip(S-Type), ⑥
※
The specifications of any product may change without prior notice to improve performance.
5
④④
Power Connection (FAN ATE 2)
◆
Please re er to “10. Power Connection” on page 6.
2) A D Socket A 2/754/939/940
①①
Thermal Grease Application
Clear o particles or any residue rom the contact sur ace o the CPU and heatsink. Shake the
Thermal Grease (ZM-STG1,
②
) well then apply on the contact sur ace o the CPU and heatsink base.
②②
Clip Installation
Re er to “The Clip Installation Method” on page 3 to correctly install the Clip or AMD Sockets (
④
) and Clip
Lever (
⑤
) on the CNPS9700 according to the orientation o the Retention Frame. First insert the Clip or
AMD Sockets (
④
) into the Heatsink (
①
), then connect the Clip Lever (
⑤
) with the Clip (
④
).
③③
Cooler Installation
Place the CNPS9700 on the center o the CPU. Align and connect the Slot o the Clip (
④
) with the
Center Lug o the Retention Frame. Press onto the Clip Lever (
⑤
) when aligning the Clip Slot and
Center Lug.
Clip’s Slot
Center Lug
Clip Lever,
⑤
Lever’s Slot
Center Lug
※
The specifications of any product may change without prior notice to improve performance.
6
10. Power Co ectio
Connect the CNPS9700 NT’s Fan Connector to the Motherboard as shown in the diagram.
11. Notes o Usage
1) Checking CPU Compatibility
Please re er to “Compatible CPUs” on page 2 to con irm that your CPU is compatible with the CNPS9700
be ore using it.
2) Cautions During Booting
Operation o the PWM an varies depending on the motherboard’s BIOS settings. Please activate the
PWM Control mode in the BIOS settings a ter installation. Re er to the motherboard’s manual or detailed
in ormation regarding the PWM Control mode.
3) Overclocking
Zalman Tech Co., Ltd. is not responsible or any damages resulting rom CPU Overclocking.
Fan Connector
(CNPS9700)
Motherboard
※
The specifications of any product may change without prior notice to improve performance.
7
14.
Home Theatre PC E closures
TNN Computer Enclosures are the world’s irst environment- riendly noiseless computer enclosures
that operate without the use o a an. TNN Computer Enclosures use the aluminum enclosure itsel
as a heatsink. They are ideal or environments that require silence, as well as or home theatre
systems and multi-media systems.
The HD160 is designed or ultra quiet home theatre
PC operation, utilizing optimized ventilation and
anti-vibration rein orcements, making it ideal or
environments that require silence such as living
rooms, bedrooms, educational acilities, and o ices.
For more information, please visit our website.
13.
TNN (Totally No Noise) Computer E closures
TNN 300 TNN 500AF
HD160
Zalman's Noiseless Power Supplies, Fanless Northbridge Coolers, Heatpipe HDD Cooler, Noiseless
Case Fans, VGA Coolers, and Fan Controllers acilitate stable per ormance and a noiseless
computing environment.
12. Zalma Computer Noise Preve tio System
Noiseless Power Supply Fanless Northbridge Cooler Heatpipe HDD Cooler
Noiseless Case Fan Ultra Quiet VGA Cooler Fan Controller
