ZALMAN AMD Athlon 64 Socket 754 CPU User manual
User
’’
s Manual
(English Edition)
User
’’
s Manual
Intel Pentium 4
Socket 478 CPU
AMD Athlon 64
Socket 754 CPU
AMD Athlon/
Duron/Athlon XP
Socket 462 CPU
* Please read before installation
ZM-WB2 Gold
http:// .zalman.co.kr http:// .zalmanusa.com
* The specifications of any product may change without prior notice to improve the performance thereof.
1
1. Features
2. Specifications
1)
Gold plated pure copper base maximizes cooling performance and prevents CPU blocks from galvanic corrosion
2) Intel Pentium 4 Socket 478), AMD Athlon/Duron/Athlon XP Socket 462),Athlon 64 Socket 754)
compatible design for broad compatibility.
3) Three types of compression fitting are offered for use with water tubes 8X10mm,8X11mm,10X13mm)
* Zalman Tech. Co., Ltd. is not responsible for any damage resulting from CPU OVERCLOCKING.
NOTE 1) The maximum eight for the cooler is specified as 450g/450g/300g for socket
478/754/462 respectively. Special care should be taken hen moving a computer
equipped ith a cooler hich exceeds the relevant eight limit. Zalman Tech Is not
responsible for any damage that occurs hen moving a computer.
Part No
1
2
3
4
5
6
7
8
9
10
11
12
13
Part name
CPU block
Hand screw
Thermal grease
Clip
User’s manual
Clip supports
Clip supports A
Clip supports B
Bolts
Paper washer
Nipple
Back plate
Fitting
Q’ ty
1
2
1
1
1
2
2
2
4
1 set
2
3 set
Weight g)
447.0
8.0
1.8
9.6
8.2
5.0
5.0
0.8
6.2
60.0
Use
CPU mountimg
Clip mountimg
Apply to cpu core
CPU block mountimg
Socket 478
Socket 462
Socket 462
Clip supports, A, B-type
7, 8 mountimg
Socket 754 mountimg
Socket 754 mountimg
Fitting to
8 x 10mm, 8 x 11mm, 10 x 13mm tubes
* The specifications of any product may change without prior notice to improve the performance thereof.
2
3. E ploded View
Intel Pentium 4
Socket 478 CPU
AMD Athlon 64
Socket 754 CPU
AMD Athlon/
Duron/Athlon XP
Socket 462 CPU
⑪
⑩
⑫
⑦
⑨
⑨
⑩
⑧
②
④
④
④
①
①
①
⑥
②
②
1) Exploded view of CPU block
①①a Block base
①①bb BBlloocckk ccoovveerr
⑬⑬Fittings
2) Exploded view for CPU type using ZM-WB2 Gold
⑬
①b
①a
* The specifications of any product may change without prior notice to improve the performance thereof.
3
4. Components
1) Common Components
①CPU block - 1 pc.
②Hand screw - 2 pcs.
③Thermal grease - 1 pc.
④Clip - 1 pc.
⑤User’s manual
⑬Fittings - 6 pcs. 3 sets)
2) Components for Intel Pentium 4 Socket 478)
⑥Two 2) Clip Supports for Socket 478
3) Components for AMD Athlon / Athlon XP Socket 462)
⑦One 1) A -Type blue) Clip Support for AMD Socket 462
⑧One 1) B -Type white) Clip Support for AMD Socket 462
⑨Four Bolts - For Fastening Clip Supports
⑩One Set of Washers
4) Components for AMD Athlon 64 Socket 754)
⑪Two Nipples
⑫One Backplate
①②⑬ ⑤
③④
⑥
⑦⑧ ⑨ ⑩
⑪⑫
* The specifications of any product may change without prior notice to improve the performance thereof.
4
5. Compatible CPU Types
1) Intel Pentium 4 - Socket 478
All speeds of Pentium 4 Socket 478 CPUs
Caution
As sho n in Figure 2, a mainboard that is not compliant ith the “10.2 mm mainboard
component height restriction” standard, introduced by Intel, may create interference bet een
components and the clip. Please do not install the ZM-WB2 hen this interference is observed.
Caution
①
This product requires "Heatsink Attach Holes" around
CPU Socket as sho n on the right.
②
This product can not be installed if any Motherboard
component(capacitor) taller than 1.5cm is located
under the clip.
2) AMD Athlon/Duron/Athlon XP - Socket 462
All speeds of AMD Socket 462 CPUs
3) AMD Athlon 64 - Socket 754
All speeds of AMD Socket 754 CPUs
Heat sink attach holes
Clip
①
②
10.2mm Motherboard component height restriction
Clip
Clip
Mainboard
component
Figure 1 (O) Figure 2 (X)
Top Vie Top Vie
Side Vie Side Vie
Mainboard
component
* The specifications of any product may change without prior notice to improve the performance thereof.
5
6. Cautions During Installation
1) Keep this product away from children.
2) Zalman Tech. Co., Ltd. is not responsible for any problems arising from using the product outside its
intended purpose..
3) The exposed core of a Socket 462 CPU can be damaged if proper care is not taken. Read the
“Installation” section thoroughly before installing.
4) Please do not install this product if ZM-WB2 interferes with any mainboard components.
5) Zalman Tech. Co., Ltd. is not responsible for any problems arising from using the ZM-WB2.
7. Installation
(INTEL Pentium 4, Socket 478)
1) Apply Thermal Grease
Spread thermal grease thinly and evenly
over the CPU core IHS).
2) Install Clip Support
Install the two clip supports at both sides of
the retention guide as shown on the right.
CPU
Thermal Grease
Retention Guide
Clip Support
* The specifications of any product may change without prior notice to improve the performance thereof.
6
8. Installation-AMD XP/Duron, Socket 462
3) Insert Hand scre s
Insert hand screws into the inner holes on the clip.
4) Fasten Hand scre s
Place the CPU block on the center of the CPU.
Screw in both Hand screws in an alternating
fashion until they are completely tightened.
1) Install Clip spport
Install the socket 462 clip supports
as shown on the right.
Be sure to install A -Type clip
support (Blue) next to the lever.
Hand screw
Outer hole
B-Type Clip Support White)
B-Type Clip Support White)
A-Type Clip Support Blue)
Paper
washer
Mainboard
Paper washer
Bolts
Lever
Clip
Clip
Inner hole
* The specifications of any product may change without prior notice to improve the performance thereof.
7
2) Apply Thermal Grease
Spread thermal grease thinly and evenly over the CPU.
1) Fasten Nipples
Position the backplate on the bottom of the
mainboard under the CPU socket, then
fasten the nipples as shown on the right.
* When installing the ZM-WB2 on an Athlon
64, the retention frame is not needed.
3) Insert Hand scre s
Insert hand screws into the outer holes on the clip.
4) Fasten Hand scre s
Place the CPU block on the center of the CPU.
Screw in both hand screws in an alternating
fashion until they are completely tightened.
Outer hole Clip
Inner hole
9. Installation-AMD XP/Duron, Socket 462
CPU
Nipple
Main board
Thermal Grease
B-Type Clip Support
A-Type
Clip Support
Large Hole
Washer
Backplate
* The specifications of any product may change without prior notice to improve the performance thereof.
8
2) Apply Thermal Grease
Spread thermal grease thinly and evenly over the CPU.
3) Insert Hand scre s
Insert hand screws into the outer holes on the clip.
4) Fasten Hand scre s
Place the CPU block on the center of the
CPU. Partially screw the bolts into the nipples.
Then, screw both bolts down further in an
alternating fashion until they are completely
tightened.
CPU
Thermal Grease
Hand screw
Clip
Inner hole
Outer hole
10. Build a noiseless system
Creating a Complete Noiseless System
Use the following Zalman products to achieve stable and silent operation of your computer, Noiseless
Power Supply, Fanless Coolers for Northbridge Chipset & Video Card, and Noiseless Fan.
Power supply
ZM400A-APF
Noiseless fan
HDD Cooler
ZM-2HC1
VGA Cooler
ZM80C-HP
Northbridge Cooler
ZM-NB47J
