Yifan NR100 User manual
NR100 5G Router
User Manual
Product Version
class
V1.0.4
Product name：NR100
Page：80
NR100 5G Router User Manual
Xiamen Yifan Communicaton Technology Co., Ltd.
Add：Floor 14th, A06 Building, No. 370, ChengYi Street,
Jimei District, XiaMen, China Zip Code: 361000
Tel：+86 592-6101492
Fax:+86 592-5222813
http://www.yifanwireless.com
NR100 5G Router User Manual
Xiamen Yifan Communication Technology Co.,Ltd. Page 2 of 80
Add: Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China,361021.
Web:www.yifanwireless.com Tel：0592-6101492 Fax：0592-5222813
Version History
Date
Version
Content
By
2020-4-17
V1.0.0
First Version
XRC
2020-4-20
V1.0.1
Modify picture
LJH
2020-4-29
2020-4-29
2020-09-18
V1.0.2
V1.0.3
V1.0.4
Delete Duplicate content
Modify Package Content
XRC
Fish_yan
NR100 5G Router User Manual
Xiamen Yifan Communication Technology Co.,Ltd. Page 3 of 80
Add: Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China,361021.
Web:www.yifanwireless.com Tel：0592-6101492 Fax：0592-5222813
NR100 5G Router User Manual
Xiamen Yifan Communication Technology Co.,Ltd. Page 4 of 80
Add: Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China,361021.
Web:www.yifanwireless.com Tel：0592-6101492 Fax：0592-5222813
Content
Chapter 1 Product Introduction....................................................................................6
Chapter 2 Installation....................................................................................................8
2.4 Power supply........................................................................................................12
2.5 Indicators..............................................................................................................12
2.6 Reset Button.........................................................................................................12
Chapter 3 Configuration and Management.......................................................................13
3.1 Configuration Connection..................................................................................13
3.2 Access the Configuration Web Page.................................................................14
3.3 Management and configuration.........................................................................15
3.3.1 Setting........................................................................................................15
3.3.1.1 Basic Setting....................................................................................15
3.3.1.2 Dynamic DNS ..................................................................................21
3.3.1.3 Clone MAC Address ........................................................................23
3.3.1.4 Advanced Router.............................................................................23
3.3.1.5 VLANs..............................................................................................24
3.3.1.6 Networking.......................................................................................25
3.3.2 Wireless......................................................................................................28
3.3.2.1 Basic Settings..................................................................................28
3.3.2.2 Wireless Security.............................................................................31
3.3.3 Services......................................................................................................33
3.3.3.1 Services...........................................................................................33
3.3.4 VPN............................................................................................................36
3.3.4.1 PPTP................................................................................................36
3.3.4.2 L2TP.................................................................................................37
3.3.4.3 OPENVPN .......................................................................................38
3.3.4.4 IPSEC ..............................................................................................43
3.3.4.5 GRE.................................................................................................45
3.3.5 Security ......................................................................................................47
3.3.5.1 Firewall.............................................................................................47
3.3.6 Access Restrictions....................................................................................49
3.3.6.1 WANAccess....................................................................................49
3.3.6.2 URL Filter.........................................................................................52
3.3.6.3 Packet Filter.....................................................................................53
3.3.7 NAT.............................................................................................................54
3.3.7.1 Port Forwarding ...............................................................................54
3.3.7.2 Port Range Forward ........................................................................55
3.3.7.3 DMZ .................................................................................................56
NR100 5G Router User Manual
Xiamen Yifan Communication Technology Co.,Ltd. Page 5 of 80
Add: Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China,361021.
Web:www.yifanwireless.com Tel：0592-6101492 Fax：0592-5222813
3.3.8 QoS Setting................................................................................................56
3.3.8.1 Basic................................................................................................56
3.3.8.2 Classify ............................................................................................57
3.3.9 Applications................................................................................................58
3.3.9.1 Serial Applications ...........................................................................58
3.3.10 Administration...........................................................................................59
3.3.10.1 Management..................................................................................59
3.3.10.2 Keep Alive......................................................................................61
3.3.10.3 Commands.....................................................................................62
3.3.10.4 Factory Defaults.............................................................................63
3.3.10.5 Firmware Upgrade.........................................................................63
3.3.10.6 Backup...........................................................................................64
3.3.11 Status........................................................................................................65
3.3.11.1 Router.............................................................................................65
3.3.11.2 WAN...............................................................................................67
3.3.11.3 LAN ................................................................................................69
3.3.11.4 Wireless .........................................................................................72
3.3.11.5 Bandwidth ......................................................................................74
3.3.11.6 Sys-Info..........................................................................................75
Appendix............................................................................................................................78
NR100 5G Router User Manual
Xiamen Yifan Communication Technology Co.,Ltd. Page 6 of 80
Add: Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China,361021.
Web:www.yifanwireless.com Tel：0592-6101492 Fax：0592-5222813
Chapter 1 Product Introduction
1.1 Product overview
NR100 is a wireless communication router for the Internet of Things, which uses public
3G/4G/5G networks to provide users with wireless long-distance big data transmission
functions.
The product adopts high-performance industrial-grade 32-bit communication processor
and industrial-grade wireless module, with embedded real-time operating system as the
software support platform, and provides 1 RS232 (or RS485) + 4 Ethernet LAN + 1
Ethernet WAN + 2 WIFI interfaces, which can connect serial devices, Ethernet devices
and WIFI devices at the same time to realize data transparent transmission and routing
functions.
This product has been widely used in the M2M industry in the Internet of Things industry
chain, such as smart grid, smart transportation, smart home, finance, mobile POS
terminals, supply chain automation, industrial automation, smart buildings, fire protection,
public safety, environmental protection, meteorology , Digital medical treatment, remote
sensing survey, military, space exploration, agriculture, forestry, water affairs, coal mine,
petrochemical and other fields.
NR100 5G Router User Manual
Xiamen Yifan Communication Technology Co.,Ltd. Page 7 of 80
Add: Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China,361021.
Web:www.yifanwireless.com Tel：0592-6101492 Fax：0592-5222813
1.2 Block diagram of working principle
NR100 5G Router User Manual
Xiamen Yifan Communication Technology Co.,Ltd. Page 8 of 80
Add: Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China,361021.
Web:www.yifanwireless.com Tel：0592-6101492 Fax：0592-5222813
Chapter 2 Installation
2.1 Overview
5G routers must be installed correctly to achieve the designed functions. Usually the
installation of the equipment must be carried out under the guidance of qualified engineers
approved by the company.
2.2 Packing list
When you open the box, please keep the packing materials, so that you can use it when
you need to transfer in the future.
The list is as follows:
·5G router host x 1
·5G wireless cellular antennas (SMAmale) x 4
·WIFI antenna (SMAfemale) x2
·Matching power supply x 1
·Ethernet direct connection x 1
NR100 5G Router User Manual
Xiamen Yifan Communication Technology Co.,Ltd. Page 9 of 80
Add: Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China,361021.
Web:www.yifanwireless.com Tel：0592-6101492 Fax：0592-5222813
2.3 Installation and cable connection
Size(mm)：
Antenna installation:
The 5G antenna interface is an SMA female socket. Screw the SMAmale of the matching
wireless cellular antenna to the antenna interface and make sure to tighten it. In order to
increase the isolation of the 5G antenna, try to keep the antenna at an angle of 30
degrees to enhance Signal quality.
NR100 5G Router User Manual
Xiamen Yifan Communication Technology Co.,Ltd. Page 10 of 80
Add: Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China,361021.
Web:www.yifanwireless.com Tel：0592-6101492 Fax：0592-5222813
The WIFI antenna interface is an SMA male socket. Screw the SMA female of the
matching WIFI antenna to the antenna interface and make sure to tighten it. In addition, to
increase the isolation of the wifi antenna, it is recommended that the two wifi are placed at
a 90 degree angle.
SIM/UIM installation：
When installing or removing the SIM/UIM card, first use a pointed object to gently hold the
eject button, and the SIM/UIM card sleeve will pop out. Put the SIM/UIM card into the card
holder first, and make sure that the metal contact surface of the SIM/UIM card is facing
outward, then insert the SIM/UIM card holder into the drawer .
