Yealink T18P User manual



Regency5000‐YealinkT18PIPUserGuide.Docx V1.00.0001

1

YealinkT18PIPUserGuide



Regency5000‐YealinkT18PIPUserGuide.Docx V1.00.0001

2

IntroducingyourYealinkT18PIPPhone



TheT18PisacompactIPbusinessphone,supportingawidefeatureset;theT18Pisthe

intelligentpurchaseforreliableIPbusinessperformance.

An

Overviewof

yourYealinkT20PIP

Phone







Regency5000‐YealinkT18PIPUserGuide.Docx V1.00.0001

3

TipsforUsingyourYealinkT18PIPPhone



MakingaCall

PickuptheHandsettomakeacall.

DialNumberDirectly:Dialthenumberdirectly,andpressthe#keytocallout

Re‐dial:DialtheRDButtontodialoutthelastcallednumberdirectly

AnsweringaCall

Answeringanincomingcallinthefollowingways:

Ifyouareonanothercall,presstheHoldkeytoanswerit

Ifyouarenotonanothercall,justliftthehandsettoanswerit

YoucanalsopresstheMutebuttontodenytheincomingcall

MutingaCall

PresstheMutebuttonduringaconversationtomutethecall,andpressitagaintoget

themicrophonereturntonormalconversation

VolumeAdjustment

Duringthecall,youcanpressthevolumeadjustmentbardstoadjustthevolume

PuttingaCallonHold

PresstheHOLDbuttontoputyouractivecallonhold

Ifthereisonlyonecallonhold,presstheHOLDkeyagaintoretrieveit

Iftherearetwocallsonhold,pressHOLDtoputthecurrentcallonhold,andretrieve

thethirdparty

VoiceMail

ThePresenceofnewVoiceMailmessageswillbeindicatedbytheLED,userscanpick

upthehandsetanddialtheconcatenatedcodetogetthevoicemailintheserver

ConferenceCall

PresstheHoldkeyduringanactivecall

Thefirstcallisplacedonhold.Youcandialthethirdnumber,thenpress#keytocall

out.

Whenthecallisanswered,presstheRedialkeytoestablishathree‐partyconference.

Hanguptodisconnecttheconferencecall



Regency5000‐YealinkT18PIPUserGuide.Docx V1.00.0001

4

CallTransfer

Therearethreewaystotransferthecall:BlindTransfer,AttendedTransferandSemi‐Attend

Transfer.

BlindTransfer:

AandBisonaconversation,ApressTRANbuttontoputBonhold,thenAcandialthe

thirdnumberCandpressTRANbuttontocallout.ThenAwillturntoidlestatus

AfterCansweredit,BcantalktoC

AnnouncedTransfer:

AandBisonaconversation,ApressTRANButtontoputBonhold,thenAcandialthe

thirdnumberCandpressthe#buttontocallout

AfterCansweredit,AandCcanhaveaprivateconversationwithoutBhearingit,then

AhunguporpresstheTRANbuttontocompletethetransfer

Awillbedisconnectedfromthecall,BcantalktoC

Semi–AnnouncedTransfer:

AandBisonaconversation,ApressTRANbuttontoputBonhold,thenAcandialthe

thirdnumberCandpressthe#buttontocallout

WhiteCisringing,AhanguporpresstheTRANbuttontocompletethetransferAwill

bedisconnectedfromthecallwhenCpickup,BcantalktoC





Regency5000‐YealinkT18PIPUserGuide.Docx V1.00.0001

5

ChecktheIPstatusofyourYealinkT18PIPPhone



IPAddress

Pickupthehandsetdial**90#,followthevoiceprompttogettheIPAddress

SubnetMask

Pickupthehandsetdial**91#,followthevoiceprompttogettheSubnetMask

Gateway

Pickupthehandsetdial**92#,followthevoiceprompttogettheGateway

DNS1

Pickupthehandsetdial**93#,followthevoiceprompttogettheDNS1

DNS2

Pickupthehandsetanddial**94#,followthevoiceprompttogettheDNS2

PowerIndicationLEDonyourYealinkT18PIPPhone



GreenLight

LEDStatusDescription

SteadyGreenThephoneisundertheidlestatus

SlowBlinkingThereisacallonmute

FastBlinkingTwiceThephoneisunderDND/ForwardStatus



RedLight

LEDStatusDescription

SteadyRedThereisanewvoicemailtoyourextension

SlowBlinkingThereisanincomingcalltothedevice

FastBlinkingTwiceThereisacallonhold



OrangeLight

LEDStatusDescription

SteadyOrangePowerOn

BlinkingOrangeNetworkunavailable,theaccountisnot

registeredorregisteredfailed

SteadyOrangeUpdating



Regency5000‐YealinkT18PIPUserGuide.Docx V1.00.0001

6

PhoneDivertsandPickups



PhoneDivertOn*72pressDialanddestinationnumber

RemovePhoneDivert*73pressDial

PhoneDivertOnBusy*90pressDial

RemoveDivertOnBusy*91pressDial

PhoneDivertNoAnswer*92pressDial

RemoveDivertNoAnswer*93pressDial

CallPickup*98pressDial

DNDActivate*78pressDial

DNDDe‐activate*79pressDial

StarCodes



AutomaticCallBackDeactivation #8

CallForwardingAlwaysToVoiceMailActivation*21

CallForwardingAlwaysToVoiceMailDeactivation#21

CallForwardingBusyToVoiceMailActivation*40

CallForwardingBusyToVoiceMailDeactivation#40

CallForwardingNoAnswerActivation*92

CallForwardingNoAnswerDeactivation*93

CallForwardingNoAnswerToVoiceMailActivation*41

CallForwardingNoAnswerToVoiceMailDeactivation#41

CallForwardingNotReachableActivation*94

CallForwardingNotReachableDeactivation*95



Regency5000‐YealinkT18PIPUserGuide.Docx V1.00.0001

7

CallingLineIDDeliveryBlockingperCall*67

CallingLineIDDeliveryperCall*65

CallReturn*69

CallWaitingPersistentActivation*43

CallWaitingPersistentDeactivation#43

CancelCallWaiting*70

ClearVoiceMessageWaitingIndicator*99

CustomerOriginatedTrace*57

DirectedCallPickup*97

DirectedCallPickupwithBarge‐in*33

DirectVoiceMailTransfer*55

LastNumberRedial*66

PerCallAccountCode*71

PushtoTalk*50

SpeedDial100*75

SpeedDial8*74



Regency5000‐YealinkT18PIPUserGuide.Docx V1.00.0001

8

OperatingInstructions







Notice1.IftheWAN(wideareanetwork)connectionfailstoasiteforanyreason,

includingafaultonthecircuitorapowercut,thentheabilitytomake

andreceivecallsfromtheIPphonesutilisingthatWANcircuitwillbe

restricted.Thesefailuresmaybecausedforreasonsoutsideour

control. Otherserviceswillbefullymaintainedincludingvoicemailand

theabilitytodivertcallstoothernumbersincludingmobiles.Ifanother

workingWANcircuitisavailableatthatsitethenthiscanbeusedtofully

restoreservicetoallphones.



2.TheR5000serviceallowsforcallsto999and112,howevertheseservices

willbeaffectedifthereisapowercutoryourWANcircuitfails



3.Withregard999servicesnolocationinformationispassedtothe

emergencyservicesoperatorthiswillmeanthatyouwillhavetostate

theaddressthatyouwishtheemergencyservicetoattend.



4.R5000doesnotofferapaperbasedtelephonedirectoryservice



5.IfyourequireaPDFthatallowsyoutoprintoffstickerstoattachtothe

phonedeviceexplainingtheabovepleasecontactus.
