Xantrex GRIB and Ethernet interface User manual

GPIB and Ethernet

Interface for

XG Series

Programmable DC

Power Supplies

Operating Manual

GPIB

ENET

www.programmablepower.com

XG 850 Watt Series

Programmable DC Power

Supply

Operating Manual

M370078-01 ii

About Xantrex

Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with

products from small mobile units to utility-scale systems for wind, solar, batteries, fuel cells,

microturbines, and backup power applications in both grid-connected and stand-alone systems. Xantrex

products include inverters, battery chargers, programmable power supplies, and variable speed drives

that convert, supply, control, clean, and distribute electrical power.

Trademarks

XG 850 Watt Series Programmable DC Power Supply is a trademark of Xantrex International. Xantrex

is a registered trademark of Xantrex International.

Other trademarks, registered trademarks, and product names are the property of their respective owners

and are used herein for identification purposes only.

Notice of Copyright

XG 850 Watt Series Programmable DC Power Supply Operating Manual© November 2007 Xantrex

Exclusion for Documentation

UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC.

(“XANTREX”)

(A) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF

ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER

DOCUMENTATION.

(B) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR

EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL,

WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH

INFORMATION WILL BE ENTIRELY AT THE USER’S RISK; AND

ENGLISH, ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE

TRANSLATION, THE ACCURACY CANNOT BE GUARANTEED. APPROVED XANTREX

CONTENT IS CONTAINED WITH THE ENGLISH LANGUAGE VERSION WHICH IS POSTED

AT WWW.PROGRAMMABLEPOWER.COM.

Date and Revision

November 2007 Revision A

Part Number

M370078-01

M370078-01 iii

Product Numbers (FGAs)

Part Numbers for Rack Mount Kits

Contact Information

XG6-110 XG60-14

XG8-100 XG80-10.5

XG12-70 XG100-8.5

XG20-42 XG150-5.6

XG33-25 XG300-2.8

XG40-21 XG600-1.4

Rack Mount Kit Part Number

Dual XG 850 Watt RM-D-XG1

Single XG 850 Watt RM-S-XG1

Rack mount rails for

XG Series

RM-XG

Telephone: 1 800 733 5427 (toll free North America)

1 858 450 0085(direct)

Fax: 1 858 458 0267

Email: sales@programmablepower.com

service@programmablepower.com

Web: www.programmablepower.com

M370078-06 v

About This Manual

Purpose

This Operating Manual provides explanations and procedures for

programming the XG 850 Watt Series Programmable DC Power Supply

from the GPIB interface and connecting and configuring the power supply

to the Ethernet.

Scope

The Manual covers the GPIB and Ethernet interface options only. Refer to

the XG 850 Watt Series Programmable DC Power Supply Operating

Manual (Part number: M370078-01) for installation, operating procedures,

setup, calibration and troubleshooting for your power supply.

Audience

The Manual is intended for the user who is familiar with electronic power

supplies, Constant Current and Constant Voltage operating modes and the

control of output power. The user should be familiar with practicing safe

techniques while making supply or pin connections. The user should also

have experience with network-based communications software and

protocols.

Organization

This Manual is organized into two chapters, two appendices, and provides

Warranty and Product information.

Chapter 1, “GPIB” provides information and procedures on programming

the XG 850 Watt Series Programmable DC Power Supply from the GPIB

(General Purpose Interface Bus) interface.

Chapter 2, “Ethernet (ENET)” provides information and procedures to

connect and configure the power supply to the ENET.

Appendix A, “Troubleshooting” provides troubleshooting information for

the combined ENET and RS-485 communication and for ENET

communication.

Appendix B, “Links” provides the Web site links for relevant third party

vendors.

About This Manual

vi M370078-06

Conventions Used

The following conventions are used in this Manual.

Related Information

For related materials on this product, see also:

•XG 850 Watt Series Programmable DC Power Supply Operating

Manual (Part number: M370078-01).

•XG 850 Watt Series Programmable DC Power Supply Rack Mount

Kit Options (Part number: M370078-05).

•XG 850 Watt Series Programmable DC Power Supply: Quick

Reference Guide (Part number: M370078-04). This document is

included with your power supply and provides a quick start on using

the front panel interface.

More information about Xantrex Technology Inc. as well as its products

and services is available at www.programmablepower.com.

WARNING

Warnings identify conditions or practices that could result in personal injury or

loss of life.

CAUTION

Cautions identify conditions or practices that could result in damage to the unit or

other equipment.

Important:

Important notes provide information that is important for you to

know. They are not as serious as Cautions or Warnings.

M370078-06 vii

Important Safety Instructions

WARNING: High Energy and High Voltage

Exercise caution when using a power supply. High energy levels can be stored at

the output voltage terminals on a power supply in normal operation. In addition,

potentially lethal voltages exist in the power circuit and on the output and sense

connectors of a power supply with a rated output greater than 40 V. Filter

capacitors store potentially dangerous energy for some time after power is

removed.

WARNING

Operate the power supply in an environment free of flammable gases or fumes.

To ensure that the power supply's safety features are not compromised, use the

power supply as specified in this manual and do not substitute parts or make any

unauthorized modifications. If service is necessary, please return the power

supply to the factory Authorized Service Center. See “Return Material

Authorization Policy” on page WA–3.

WARNING: Limitations on use

The XG 850W GPIB and Ethernet Interface Option is not intended for use in

connection with life support systems or other medical equipment or device.

viii

This manual suits for next models

Table of contents
