WOMOW W5 S User manual
USER
MANUAL
W5 S
CORDLESS STICK
VACUUM CLEANER
Content
1. Package contents and product specifications
2. Unpacking and assembling
3. Product operation & Maintenance
4. Important safety instructions
5. Troubleshooting
6. Warranty
Package contents and product specifications
01
01
02
04 05 06
03
07
04 2 In 1 Brush
05 Crevice Tool
06 Charger
07 wall mount
01 Main Body (Battery Included)
02 Motorized Floor Brush
03 Tube
26V 400mA
Model : W5 S
Max suction : 10Kpa
Voltage : 22.2 V
Rated power : 140W
Charging time : 5.5 hourRuntime : ≥20min(max)≥ 40min(standard)
Battery : 2200mAh lithium
Dust cup capacity : 0.5 L
Power adapter input : Power adapter output :100-240V 50/60Hz
Especicaciones:
02
Tube
Slide the tube into hand vacuum until it clicks into place.
Motorized floor brush
Slide the motorized brush into the tube until it clicks into place. Press the release
button to remove the tube.
Press the release button to remove the tube.
Unpacking and assembling
03
Accessories
Push the crevice tool /2 in 1 brush to suction tube or hand vacuum until it clicks into
place.
Note:
The crevice tool is suitable for cleaning narrow, slit or irregular object surface, such as
corner, window slit, drawer, frame, keyboard, etc.
04
Product Operation & Maintenance
Storage
Install the wall-mounted tool on the wall with the screws in the package. Put the
vacuum cleaner by inserting it into hook.
Charging
The power adapter plugs into the host to charge, and the host charging interface is
located on the side of the host
Note:
1.Please only use the original battery and charger. Do not use other replacement
battery or charger.
2.Prevent the battery and charger from any shock or damage.
3.Keep the battery and charger away from water and any wet environments.
4.Put the battery pack at dry and cool place when charging.
5.Do not put the battery and charger in hot environment over 50 degree. Prevent them
from direct exposure to sunshine. Keep them away from heated surface and cigarettes.
6.Do not repair by yourself when the battery or charger is defective. Please contact the
customer service team for help.
Maintenance
Clean the dust cup
Turn off the vacuum cleaner, press the release button to empty the dust cup.
Starting up
Please check whether the battery is sufficient before use. In order to ensure the normal
operation of the product, please charge the battery for more than 5 hours before the
first use.
IThe On/Off button is , push it to I to use its standard mode, and push it to II to
use the Max mode. Push back to 0 to turn off the machine.
05
06
Clean the filter
After the dust cup is cleaned, detach the tube first, press the release button above
the dust cup to remove it. Remove the sponge filter to clean it thoroughly. Reverse
operation can restore.
Nota:
To protect the machine, make sure the filter is completely dried before assem-
bling back.
Clean the floor brush
Turn off the vacuum cleaner, use a coin or other tool to unlock the the roller brush
lock. Then remove the roller brush for cleaning.
release
button
07
Indicator lights
1.This product is equipped with a 5-stage power display lamp, which can be turned
on after starting up.
2.The power indicator bar displays the current power according to the percentage of
the battery.
3.When the battery power is lower than 3% of the total power, the machine will auto-
matically enter the state of shutdown protection. Meanwhile, the 5-level power indi-
cator will flash one by one to indicate that the battery is insufficient. Please timely
charge.
4.When charging, the progress of electric quantity will be displayed. After being fully
charged, the display light will turn off automatically for about 5 minutes and enter
the sleep state.
5.Do not turn on during charging.
Important safety instructions
08
1. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Cleaning and
user maintenance shall not be made by children without supervision. Children
should not play with the appliance.
2. This product is only suitable for working in dry environment. Keep it away from
Storage cabinets, curtains and other combustible materials. Do not put it in hot
environment.
3. Following objects are strictly banned, otherwise the vacuum cleaner will be
damaged or fire calamity will be caused, which bring such accidents as human
body injuries:
●
Don’t pick up large or sharp broken such as glasses,
●
Don’t pick up harming or erodent liquids (solvent, corrosive, detergent…),
●
Don’t pick up inflammable or explosive substance such as gasoline or alcohol.
4. Keep product airflow and moving parts away from hair, loose clothing, fingers
and other body parts. Do not aim the suction mouth of the suction tube and other
accessories at the eyes and ears, or put it into the mouth.
5. Exclude large pieces of paper, paper balls, plastic cloth, or sharp objects before
use.
6. Stop using the cleaner when the temperature of its motor is getting too high or
it’s having electric leakage.
7. Check the device and connections regularly for visible damage. The device must
not be used if the housing is damaged or other damage is present.
8. Please check the dust cup regularly. If there is too much rubbish in the dust cup,
please deal with it in time to keep the ventilation diameter unimpeded, avoid
clogging and causing suction decline, motor heating, and reduce the service life of
the vacuum cleaner.
9. Please check the smooth condition of the aluminum alloy tube regularly. If there
is any blockage, please remove it in time to avoid the decrease of suction and
affect the performance of the machine.
10.When cleaning this product, do not use lubricant, detergent, polishing agent,
etc.
11.Please contact the customer service center of the seller for help if there is
anything wrong with the product.
