WMF PERFECTION 800L Series User manual
1
EN Operating Instructions 2
PL Instrukcja obsługi 28
HU Használati utasítás 54
CS Návod k obsluze 80
SK Návod na obsluhu 106
RO Instrucţiuni de utilizare 132
BG Указания за употреба 158
WMF PERFECTION
800L-SERIES
EN OPERATING INSTRUCTIONS
1|Technical specifications 4
2|Important safety information 4
2.1|Proper use 5
2.2|For Europe market only 6
2.3|Recommendations for installation 6
2.4|Important product information 8
2.5|Before using the first time 8
3|Components 8
4|Differences between the models 9
5|Overall view 10
5.1|Presentation of the different buttons 10
5.2|Lights settings 11
6|Installing the appliance 11
6.1|Measuring the water hardness 12
6.2|Filter installation 12
7|Important information before preparing drinks 13
7.1|Preparing the appliance 13
7.2|Preparing the grinder 13
7.3|Adjusting the coffee outlet 14
ENOPERATING INSTRUCTIONS
2
8|Preparing drinks 14
8.1|Coffee drinks 14
8.2|Teas / hot water 14
8.3|Milky drinks 14
8.4|Ground coffee recipes 15
8.5|Permanent settings 16
9|Profile menus 18
9.1|Create and delete a profile 18
9.2|Create and delete a fovourite recipe 18
10|Setting menu 18
11|General maintenance 19
11.1|Maintaining coffee grounds collector and drip tray 19
11.2|Maintenance of water tank 20
11.3|Why and how do I maintain the milk system? 20
11.4|Why and how cleaning the coffee beans tank? 20
11.5|Why and how cleaning the coffee hatch? 21
11.6|Overview general maintenance 21
12|Other maintenance 22
13|Troubleshooting 23
LIST OF FIGURES
A First use | B Measuring the water hardness | C Make two cups of a recipe at
once| D Make a milk recipe | E Quick milk rinsing | F Manual deep cleaning
of milk system | G Descaling program | H Complete automatic cleaning of the
machine | IEmpty the coffee ground collector | J Empty the drip tray
3
WMF PERFECTION 800L-SERIES
FULLY AUTOMATIC COFFEE MACHINE
Congratulations! You are now the proud
owner of your WMF Perfection fully auto-
matic coffee machine.
The most frequently consumed drinks are acces-
sible with one simple touch on the main inter-
face. As for the screen, it allows you to follow
the progress of your coffees and provides easy
access to the different menus. Most drinks can
be prepared in batches of two, which saves time
and is more convivial.
We wish you many years of enjoyment with
your WMF Perfection fully automatic coffee
machine.
1| TECHNICAL SPECIFICATIONS
Appliance: WMF Perfection
fully automatic coffee machine
Power supply: 220–240 V~/50 Hz
Pump pressure: 15 bars
Coffee bean container: 250 g
Capacity grounds container: 15 portions
Water tank: 2.0 l
Power consumption: During operation 1,550 W
Use and storage: Indoors, in a dry place (pro-
tected from frost)
Cable length (m): approx. 1.1
Dimensions (mm) H×W×D: 395×285×480
Weight (kg): 12.0
The guarantee period of this appliance is
2years. Please refer to the guarantee document
for details on the other guarantee terms and
conditions in your country.
Manufacturer:
SAS GSM
Rue Saint-Léonard F-53104 Mayenne
France
2| IMPORTANT SAFETY
INFORMATION
Important information is indicated in these
operating instructions using symbols and sig-
nal words:
WARNING indicates a hazardous situation
that can cause serious injuries.
CAUTION indicates a potentially hazard-
ous situation that can cause minor or moder-
ate injuries.
ATTENTION indicates a situation that can lead
to material damage.
NOTE provides additional information regard-
ing the safe handling of the product.
Symbols: observe and follow the
indications.
4
2.1| PROPER USE
•This appliance is not intended for
use by persons (including chil-
dren) with reduced physical, sen-
sory or mental capabilities, or
lack of experience and knowl-
edge, unless they have been
given supervision or instruction
concerning use of the appliance
by a person responsible for their
safety.
•Children should be supervised to
ensure that they do not play with
the appliance.
•Do not use the appliance if the
power cord or plug is damaged.
The power cord must be replaced
by the manufacturer, its after-
sales service or similarly quali-
fied persons in order to avoid a
hazard.
•Your appliance is intended for
domestic use inside the home only
at an altitude below 2.000 m.
•Do not immerse the appliance,
power cord or plug in water or
any other liquid.
•Your appliance is designed for
domestic use only.
•It is not intended to be used
in the following environments,
which are not covered by the
guarantee:
staff kitchen areas in shops,
offices and other working
environments;
farm houses;
by clients in hotels, motels
and other residential type
environments;
bed and breakfast type
environments.
•Always follow the clean-
ing instruction to clean your
appliance:
unplug the appliance,
do not clean the appliance
while hot,
clean with a damp cloth or
sponge,
never immerse the appliance
in water or put it under run-
ning water.
•When using the nozzle to ensure
that it is properly oriented in
order to avoid the risk of burns.
•Do not insert foreign objects into
the grain mill.
•The appliance shall not be placed
in a cabinet when in use.
5
BG RO SK CS HU PL EN
WARNING
Risks of injuries if you don’t
use this appliance correctly.
After using, do not touch hot sur-
faces (steam nozzle), subjected to
residual heat.
2.2| FOR EUROPE MARKET ONLY
•This appliance can be used by
children of at least 8 years of age,
as long as they are supervised
and have been given instructions
about using the appliance safely
and are fully aware of the haz-
ards involved.
•Cleaning and user maintenance
shall not be made by children
unless they are older than 8 and
they are supervised by an adult.
•Keep the appliance and its cord
out of reach of children under 8
years of age.
•This appliance may be used by
persons with reduced physi-
cal, sensory or mental capabil-
ities, or whose experience or
knowledge is not sufficient, pro-
vided they are supervised or have
received instruction to use the
device safely and understand the
dangers.
•Children should not use the
device as a toy.
•European directive 2012/19/UE
on Waste Electrical and Electronic
Equipment (WEEE), requires that
old household electrical appli-
ances are not thrown into the
normal flow of municipal waste.
Old appliances must be col-
lected separately in order to opti-
mize the recovery and recycling
of materials they contain and
reduce the impact on human
health and the environment.
2.3| RECOMMENDATIONS FOR
INSTALLATION
•Only use an earthed socket to
plug the machine in. Check that
the power voltage indicated
on the nameplate of the appli-
ance corresponds to that of your
mains installation.
•Do not use the appliance if it is
not working properly or if it has
been damaged. If this occurs,
contact an authorised service
centre.
•For your safety, this appliance
conforms to applicable stan-
dards and regulations (Directives
on low voltage, electromagnetic
compatibility, materials in con-
tact with foodstuffs, environ-
ment, etc.)
6
•Any error in the electrical con-
nection will negate your
guarantee.
•Do not use if the drip tray and
the grid are not in place.
•Unplug the appliance when you
clean it manually.
•Remove the plug if a problem
occurs during operation or before
you clean the appliance.
•Do not pull on the cord to unplug
the appliance.
•The power cord must never be
close to or in contact with the
hot parts of your appliance, near
a source of heat or over a sharp
edge.
•Ensure that the cord and your
hands do not touch the hot parts
of the appliance (cup warming
plate, steam nozzle).
•Refer to the instructions for des-
caling your appliance.
•All interventions other than
cleaning and everyday mainte-
nance by the customer must be
performed by an authorised ser-
vice centre.
•The accessories and the remov-
able parts of the appliance are
not dishwasher safe.
•For your safety, only use the
manufacturer’s accessories and
spare parts designed for your
appliance.
•This appliance is not suitable for
making drinks for babies under
the age of 2 years.
•All appliances are subject to strict
quality control procedures. These
include actual usage tests on ran-
domly selected appliances, which
would explain any traces of use.
•To reduce the risk of injury, do
not leave the cord hanging over
the table or counter, where it can
be pulled on by a child or trip
someone.
•Never pour cold water in the tank
immediately after a brew cycle.
Let the appliance cool down
between preparations.
•Do not place on or near a hot gas
or electric burner, or in a heated
oven.
•Do not use appliance for other
than intended use.
•Never operate the appliance with
wet hands.
7
BG RO SK CS HU PL EN
2.4| IMPORTANT PRODUCT
INFORMATION
NOTE
Read these instructions carefully and
keep them for future reference. Please
follow the safety guidelines.
The appliance may be used only for the
intended purpose and in accordance with this
manual. It contains instructions for using,
cleaning and looking after the appliance. We
accept no liability for any damage resulting
from non-observance.
Keep this instruction manual in a safe place and
pass it on to any subsequent user together with
the appliance. Please also note the warranty
information, which is enclosed separately. The
safety precautions must be observed during use.
2.5| BEFORE USING THE FIRST TIME
1| Take the appliance and all accessories out
of the box carefully and make sure that all
components and accessories are complete
and undamaged.
2| Ensure that all packaging material is removed
before use.
3| Clean the appliance, components and acces-
sories before the first use and after any long
storage, as described in section 11.
3| COMPONENTS
1Coffee bean container lid
2Grinding fineness adjustment dial
3Pre ground coffee funnel/funnel
for cleaning tablet
4LED light
5Accessory for cleaning the milk system, 2
in 1: disassembly tool + cleaning needle
6Removable One Touch Cappuccino block
7Ground coffee spoon
8Milk pot + lid (according to model)
9Milk lance
10 Milk tube
11 Coffee grounds collector
12 Milk tube connector
13 Grid and removable drip tray
14 Removable spout cover
15 Height-adjustable coffee outlets
16 Water tank
17 Claris – Aqua Filter System
with fitting accessory
18 Display panel
19 Care kit bag
20 1 descaling sachet
21 2 cleaning tablets
22 2 stick for testing water hardness
23 Pipe cleaner
24 Settings button
25 Cleaning button
26 On/Off button
27 Home button
28 Navigation touchscreen
29 Profile 1
30 Profile 3
31 Profile 2
32 Profile 4
8
4| DIFFERENCES BETWEEN THE MODELS
FEATURES WMF
PERFECTION
890L
WMF
PERFECTION
880L
WMF
PERFECTION
860L
WMF
PERFECTION
840L
Design black silver silver silver
Recipes
Ristretto
Espresso
Lungo
Long Coffee/Café Crème
Doppio/ Double Espresso
Americano
Morning Coffee — —
Cappuccino
Latte macchiato
Caffe Latte
Flat white
Milk Coffee/ Cafe au Lait
Espresso macchiato
Hot milk
Frothy milk
Hot Water — — —
Hot water for black tea —
Hot water for white tea —
Hot water for green tea —
Settings
Profile settings 16 16 10 4
Coffee strength setting options 4 4 4 3
Function
Ground Coffee
Accessory
Glass milk container —
9
BG RO SK CS HU PL EN
5| OVERALL VIEW
5.1| PRESENTATION OF THE DIFFERENT BUTTONS
BUTTON DESCRIPTION/GENERAL FUNCTIONS
Switching the machine on and off. It is necessary to press the button to start the machine.
Home button. Allows you to return to the home menu.
The machine has a range of settings – check them out! They let you create a more personalized
experience.
Go to the various cleaning options for the machine. Carrying out proper maintenance will
optimize the life of your machine and preserve the authentic taste of your coffee.
Allows you to return to the previous screen.
Go to the next. For instance, when preparing a Cappuccino, switch from milk preparation to
espresso preparation after a certain time.
Browse upwards in the menu/ increase the parameter selected. Browse downwards in the
menu/ decrease the parameter selected.
You can prepare one or two cups with your appliance by pushing the + button.
OK Confirmation of selection.
START Start the selection.
STOP Stop the selection.
Profile buttons at the right ofthe screen.
Profile button on the top left of the screen.
Contextual button, function depends on screen (advanced setting for recipes, settings for profiles,
etc.).
A recipe with this symbol is prepared from ground coffee inserted via the pre ground coffee
funnel 3.
10
Other manuals for PERFECTION 800L Series
3
This manual suits for next models
4
Table of contents
Languages:
Other WMF Coffee Maker manuals
WMF
WMF 5000S+ User manual
WMF
WMF 1200 S Configuration guide
WMF
WMF LINEO User manual
WMF
WMF PERFECTION 800L Series User manual
WMF
WMF Basic User manual
WMF
WMF 5000S+ Configuration guide
WMF
WMF PERFECTION 800L Series User manual
WMF
WMF 1300 S Instructions for use
WMF
WMF Bistro! User manual
WMF
WMF KITCHENminis 0412270011 User manual
