Windsor Versamatic Plus Assembly instructions

Repair Guide ™

Manufactured by:

Windsor

Model:

Versamatic Plus

Replacing the Power Cord

3. Pull the power

cord plate to

remove it.

7. Using a Phillips

screwdriver remove

the screw holding

the blue main

power cord in

place.

4. Using a # 7 nut

driver remove the

nut holding the

green ground wire.

6. Using needle

nose pliers, pull

the wires from the

back of the white

connector.

Tools needed:

A. Phillips screw-

driver.

B. Flat tip screw-

driver.

C. # 7 nut driver.

D. Needle nose

pliers.

5. Using a small flat

tip screwdriver,

loosen the 4 screws

in the white

connector.

2. Using a Phillips

screwdriver remove

the screw from the

power cord plate

on the back of the

vacuum.

1. Refer to this

picture when

reconnecting the

wires to the new

power cord.

These are general maintenance guidelines. Please consult your

owner’s manual prior to performing any repairs or maintenance on this machine.

*Before you begin: Turn the machine off and unplug it.

10. Pull the power

cord from the

handle to remove it

from the vac.

11. Reverse

process to install a

new power cord.

Refer to step 1 to

reconnect the wires

to the new power

cord.

Repair Guide ™

9. Slide the strain

relief off the power

cord.

Manufactured by:

Windsor

Model:

Versamatic Plus

Replacing the Power Cord

8. Pull up on the

strain relief to

remove the power

cord from the vac

body.

These are general maintenance guidelines. Please consult your

owner’s manual prior to performing any repairs or maintenance on this machine.

*Before you begin: Turn the machine off and unplug it.
