Whirlpool ET8WTMXKQ00 User manual
CABINET PARTS
1
For Models: ET8WTMXKQ00, ET8WTMXKT00
(White) (Biscuit)
4−01 Litho In U.S.A. (mdg) Part No. 8197651
REFRIGERATOR
CABINET PARTS
2
For Models: ET8WTMXKQ00, ET8WTMXKT00
(White) (Biscuit)
8197651
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT2213196
Service &
Wiring Sheet
LIT2218150
Energy Label
LIT2205266
Use & Care Guide
LIT628370
Modular Icemaker
Service Sheet
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
LIT677969
Do−It−Yourself
Manual, Ref./Fzr.
2 2189410 Hinge (Top)
3 2166108 Roller−Front (2)
5 489385 Clamp, Tube
(Water Supply Line)
7 3400504 Screw
8 2179826 Rivet
12 549193 Clamp−Cord
15 489497 Screw
16 2183972 Hinge, Center
17 2183854 Shim, Hinge
Center
18 3400881 Screw
20 2189194 Hinge Butt
23 2172743 Shim, Bottom
Hinge
24 Fitting, Water Tube
(NOT SERVICED)
27 Hole Plug (6)
2201012 White
2200924 Biscuit
35 Corner Filler (2)
2201014 White
2200926 Biscuit
36 Grille
2201009 White
2201021 Biscuit
37 489341 Washer
38 487576 Washer
40 Cover−Hinge
2213360 White
2213364 Biscuit
41 Rail, Center
(NOT SERVICED)
43 2189356 Clip−Grille
44 2202883 Cover, Unit
45 Cabinet (Not a
Serviceable Part)
DOOR PARTS
3
For Models: ET8WTMXKQ00, ET8WTMXKT00
(White) (Biscuit)
8197651
DOOR PARTS
4
For Models: ET8WTMXKQ00, ET8WTMXKT00
(White) (Biscuit)
8197651
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(Includes #9 & #11)
2183948 White
2205285 Biscuit
5 Handle, R.C.
2202807W White
2202807T Biscuit
6 489357 Screw
8 8281146 Screw
9 Door Gasket,
Magnetic
2159057 Mist Beige
11 2183003 Thimble
12 Cover, Screw
2202819W White
2202819T Biscuit
13 Nameplate
2157907 White
2205769 Biscuit
16 2180027 Trim, Door Shelf
17 8281206 Screw
18 2201052 Trim, Door
19 Freezer Door
(Includes #11 & #23)
2182487 White
2205279 Biscuit
20 Hole Plug
2189000 White
2200936 Biscuit
21 2195943 Trim, Door Shelf
22 2195915 Plug−Trim
23 Door Gasket,
Magnetic
2159327 Mist Beige
24 2195915 Endcap (2)
25 2201051 Trim, Door Shelf
26 2189202 Bracket, Door
Stop (2)
27 488921 Screw
28 Hole Plug
844478 White
2200934 Biscuit
29 2156007 Plug−Trim (4)
30 2156006 Plug−Trim (4)
31 2188396 Compartment Door
33 Handle, F.C.
2202806W White
2202806T Biscuit
37 2201050 Trim−Door (2)
41 2156003 Endcap (4)
42 2195949 Trim, Door
LINER PARTS
5
For Models: ET8WTMXKQ00, ET8WTMXKT00
(White) (Biscuit)
8197651
LINER PARTS
6
For Models: ET8WTMXKQ00, ET8WTMXKT00
(White) (Biscuit)
8197651
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 531933 Grommet (2)
3 2189268 Gasket, Evaporator
Cover (Side)
4 2213100 Control,
Adaptive Defrost
5 2204640 Thermostat Tube
Barrier
6 98129 Screw
7 2187350 Wire Assy.
Control Box
8 2162085 Socket, Light (2)
10 2183833 Fan Motor
11 2163777 Fan Blade
12 2212980 Control Box
13 2204605 Thermostat
(Includes Item
5)
14 489478 Screw
15 489412 Screw
16 2201170 Cover−Evaporator
17 2160708 Light Bulb
19 1118894 Rocker Arm
Switch
21 2176281 Cover, Air
Diffuser
22 2202885 Knob, Thermostat
23 2182340 Air Tower
24 2189452 Air Diffuser,
Bottom
25 2172565 Freezer Floor
26 2179877 Air Diffuser, Top
29 2200641 Bracket,
Fan Motor
30 2189267 Gasket, Evaporator
Cover (Top)
31 2204639 Shield, Heat
32 2187301 Wire Assembly,
Freezer Compartment
38 941839 Hole Plug
40 2171931 Release Valve
UNIT PARTS
7
For Models: ET8WTMXKQ00, ET8WTMXKT00
(White) (Biscuit)
8197651
UNIT PARTS
8
For Models: ET8WTMXKQ00, ET8WTMXKT00
(White) (Biscuit)
8197651
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 2205341 Plate, Unit
Mounting
3 2212599 Condenser
4 2176300 Heater, Defrost
5 2195391 Evaporator Assy.
6 489494 Screw
7 2172619 Drain Pan
8 2182380 Defrost Bi−Metal
9 2176301 Bracket, Heater
10 2163780 Extension, Air
Baffle
11 489478 Screw
12 4387731 Cover (Service)
13 Overload
4387938 Service
(Includes Relay)
14 Grommet (4)
1100826 Production
4387558 Service
15 2213106 Start−Device,
Combination
(Start Relay and
Overload)for
Production
Compressor Only
16 2201184 Support Block
17 2150304 Roller (2)
18 981126 Rivet
19 2182338 Clip, Heater
20 Capacitor
2169373 Production
21 488687 Screw
22 2166683 Clip
28 2212912 Compressor
(Includes Items 12,
13,14,15,29,31)
(Also Order
482801
Installation Kit
& 876765
Tube Kit)
29 2199167 Drier
30 2155774 Clamp
31 489373 Screw
39 2198921 Air Baffle
40 2188537 Motor, Condenser
42 2187358 Wire Assy. Unit
43 2190685 Fan Blade
44 486692 Nut
45 2212603 Tube, Transition
46 2205294 Tube, Discharge
47 2205293 Tube, Suction
48 2212848 Tube, Process
58 2210451 Evap. Tray
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
4.0 Ozs.
(R134A)
ICEMAKER PARTS
9
For Models: ET8WTMXKQ00, ET8WTMXKT00
(White) (Biscuit)
8197651
ICEMAKER PARTS
10
For Models: ET8WTMXKQ00, ET8WTMXKT00
(White) (Biscuit)
8197651
Illus. Part
No. No. DESCRIPTION
1 488878 Clamp, Tube
4 2181939 Insert, Tube
5 628379 Clip, Fuse
7 2181943 Tube Water
9 489478 Screw
10 2182104 Valve Solenoid
11 627018 Nut Compression
14 489385 Clamp, Tube
18 2210484 Cover
19 3400881 Screw
20 628228 Mold & Heater
Assembly (Also
Order 542638
Silicone Grease)
22 628356 Cup, Water Fill
23 2194711 Ejector
24 2182124 Ice Striper
25 2194712 Support
26 627796 Retainer
Thermostat
27 628397 Thermostat (Also
Order 542369
Cement
Alumilastic)
28 489322 Screw
30 489276 Screw
31 627792 Shut Off Arm
32 628256 Harness, Wiring
33 628320 Bracket
35 628399 Module Assembly
(Includes Item 38)
38 489136 Screw,
3−24 x 23/64
39 488208 Screw
40 488886 Screw, 8−18 x 1/2
100 4317943 Icemaker, Complete
Assembly
