Whirlpool RS675PXGB7 User manual

COOKTOP PARTS

For Models:RS675PXGB7, RS675PXGQ7, RS675PXGT7

(Black) (White) (Biscuit)

2−01 Litho in U.S.A. (jac) Part No. 8185715

30" DROP−IN

ELECTRIC OVEN

SELF CLEAN

Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

1 Literaturre Parts

LIT3191799

Installation

Instructiions

LIT3191537

Use & Care Guide

LIT3192845

Tech Sheet

LIT3191638

Safe Cooking Tips

2 3192459 Burner Box

3 3192330 Bracket, Mounting

3177991 Screw

4 Cooktop

8284709 Biscuit

3191168 White

3191167 Black

5 3192575 Clip, Mtg. (4)

3400843 Screw

6 Panel, Control

8284707 Biscuit

3191229 White

3191228 Black

7 Switch, Infinite

3191471 Use W/6" Surface

(Blue Shaft)

3191473 Use W/8" Surface

(Red Shaft)

3400855 Screw, 8−32 x 1/4

8 3191491 Light, Indicator

11 Pan, Surface

3195208 6" Pan

3195209 8" Pan

12 Element, Surface

8053266 6" Burner

8053268 8" Burner

14 Knob, Control

3196232 White

8272506 Biscuit

3196231 Black

15 3183956 Seal, Switch

Shaft (4)

18 Trim, Extension

3192103 White

8300518 Biscuit

3192102 Black

19 3195917 Clip, Element

CONTROL PANEL PARTS

For Models:RS675PXGB7, RS675PXGQ7, RS675PXGT7

(Black) (White) (Biscuit)

8185715

Illus. Part

No. No. DESCRIPTION

1 Control Panel Assy.

4452845 White

8300515 Biscuit

4452844 Black

W/Membrane Switch

3400832 Screw

2 4451034 Gasket,

Control Panel

3 4452892 Microcomputer

4449745 Screw

OVEN PARTS

For Models:RS675PXGB7, RS675PXGQ7, RS675PXGT7

(Black) (White) (Biscuit)

8185715

OVEN PARTS

For Models:RS675PXGB7, RS675PXGQ7, RS675PXGT7

(Black) (White) (Biscuit)

8185715

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

1 Trim, Side

(Right Hand)

4450845 White

4452120 Biscuit

4450844 Black

(Left Hand)

4450848 White

4452121 Biscuit

4450847 Black

Screw

4449041 Bright

4449747 Black

3 Hinge Receiver

4455520 Left Hand

4455521 Right Hand

4 4448520 Bumper, Door

7 4455286 Top Chassis

4449809 Screw

9 4452158 Tube, Vent

4449154 Screw

10 4452165 Lens, Light

11 4452368 Oven Light Assy

12 4452166 Bulb, Light

14 4455612 Frame, Front

4449040 Screw

4450118 Nut

15 4455382 Gasket, Door

19 4451478 Support, Insulation

4449809 Screw

21 Rail, Side

4450579 Right Side

4450580 Left Side

4448444 Grommet

4449154 Screw

22 4451896 Latch Assembly

23 4452224 Solenoid

24 4452312 Micro Switch N.C.

4449154 Screw

25 4455641 Side, Chassis

(R.H. & L.H.)

4449809 Screw

26 4452234 Back, Chassis

4449809 Screw

27 Liner, Oven

(Not serviceable)

28 4451426 Micro Switch

29 4455636 Sensor

4449154 Screw

30 4451537 Spring, Latch

37 4451442 Thermostat (TOD)

(Temp.) SPST

43 4455530 Base, Chassis

49 4448933 Retainer, Gasket

4449154 Screw

50 4451747 Cover, Back

4449809 Screw

53 4449845 Support, Bracket

4449809 Screw

55 Trim, Bottom

4448478 White

4452415 Biscuit

4448477 Black

FOLLOWING PARTS

NOT ILLUSTRATED

INSULATION

4449316 Insulation, Wrap

4450365 Insulation, Back

OVEN DOOR PARTS

For Models:RS675PXGB7, RS675PXGQ7, RS675PXGT7

(Black) (White) (Biscuit)

8185715

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

1 4451719 Door Liner

2 4455525 Hinge, Door

4449743 Screw

3 4449259 Glass, Inner

4 4451722 Insulation, Door

7 4449263 Glass, Inner (2)

9 4451668 Retainer, Glass

4449809 Screw

13 Door Handle

4448855 White

4452860 Biscuit

4448854 Black

14 4450813 Bracket, Handle

4451040 Screw

15 Door Assembly,

Glass

4452066 White

4452859 Biscuit

4452065 Black

19 4450362 Shield, Heat

4449809 Screw

20 4451671 Retainer, Glass

4449809 Screw

21 4451674 Seal, Door Top

23 Retainer, Clip

4450864 White

4452119 Biscuit

4450863 Black

24 4455257 Glass, Inner

INTERNAL OVEN PARTS

For Models:RS675PXGB7, RS675PXGQ7, RS675PXGT7

(Black) (White) (Biscuit)

8185715

Illus. Part

No. No. DESCRIPTION

2 4452154 Element, Broil

4449154 Screw

3 3147563 Grill, Broiler

4 3147845 Pan, Broiler

6 4448717 Rack, Oven

7 4452153 Element, Bake

4449154 Screw

TOP VENTING PARTS

For Models:RS675PXGB7, RS675PXGQ7, RS675PXGT7

(Black) (White) (Biscuit)

8185715

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

1 4451759 Vent, Exhaust

4449040 Screw, 8−18 x 3/8

2 4455178 Elbow, Vent Top

3 4455334 Blower

4455352 Bracket, Blower

(2)

4 4451758 Block, Foam

5 4455177 Elbow, Vent Bottom

6 4451761 Plate, Service

11 4449868 Block, Terminal

3400080 Screw

13 4448549 Vent,

(Control Panel)

4450038 Screw

14 Side, Control Compt.

3191832 Right

3191833 Left

4449809 Screw

15 4452244 Back, Control

4449809 Screw

20 3191842 Cover, Rear

OPTIONAL PARTS

For Models:RS675PXGB7, RS675PXGQ7, RS675PXGT7

(Black) (White) (Biscuit)

8185715

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

PAINT, TOUCH−UP (1/2oz.)

72017 White

261869 Cord Brown

72032 Black

PAINT, SPRAY

350930 White

261900 Citrine White

830864 Black

ADHESIVE

591014 Adhesive

Loctite (1/3 oz.)

482338 Sealer, Silastic

(3 oz.)

SPLICING WIRES−−25FT.

LENGTH

242828 Wire (12 Ga.

150 c Black)

242820 Wire (14 Ga.

150 c Black)

242821 Wire (14 Ga.

150 c Blue)

242822 Wire (14 Ga.

150 c Brown)

242830 Wire (14 Ga.

200 c Brown)

242823 Wire (14 Ga.

150 c Green)

242824 Wire (14 Ga.

150 c Orange)

242829 Wire (12 Ga.

150 c Red)

242825 Wire (14 Ga.

150 c Red)

242831 Wire (14 Ga.

200 c Red)

242826 Wire (14 Ga.

150 c White)

242827 Wire (14 Ga.

150 c Yellow)

242832 Wire (14 Ga.

200 c Yellow)

WIRING HARNESS PARTS

3191220 Harness, Wire

(Main)

4455733 Harness, Wire

(EDC)

4451163 Conduit

4448664 Clamp

4449809 Screw

112432 Nut

4450800 Screw, Ground

3192236 Harness, Wire

(Infinite Switch)

4455592 Harness, Wire

(Light)

4452222 Spacer, Harness

4454384 Ground, Wire

3400015 Screw, Ground

Miscellaneous

814381 Hinge Pin Kit

4448950 Screw, Install (4)
