Whirlpool GMC305PRS02 User manual
OVEN PARTS
1
For Models:GMC305PRS02
(Stainless)
3−08 Litho in U.S.A. (amd) Part No. W10163659 Rev. A
30" BUILT−IN ELECTRIC
COMBO
SENSOR/SC
(GOLD LINE)
OVEN PARTS
2
For Models:GMC305PRS02
(Stainless)
W10163659
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Literature Parts
Installation
Instructions
8303655 English
8303780 French
Use & Care Guide
(Microwave)
8304078 English
8304082 French
Use & Care Guide
(Oven)
8304077 English
8304081 French
8304173 Tech Sheet (Oven)
Safer Cooking Tips
3191638 English
9759133 French
2 Trim, Side
W10145006
Right
W10145007
Left
3 Hinge, Receiver
4455606 Right
4455605 Left
4
W10105790
Bumper, Door
5 4448444 Grommet, Mounting
Rail
6 4452490 Spacer, Foam
7 8303099 Top, Chassis
8 4449809 Screw
9 4452158 Tube, Vent
10
W10067870
Lens, Light
11
W10009930
Assembly, Oven
Light
12 4452166 Bulb, Light
13 8300791 Bracket, Combo
14
W10130368
Frame, Front
15 4455382 Gasket, Door
16 3400832 Screw
17 3196176 Screw
18 4452152 Bracket, Mounting
19 4451478 Support, Insulation
21 Rail, Side
8303117 Right
8303118 Left
22 4449040 Screw
23 4449743 Screw
24 4449154 Screw
25 4455641 Side, Chassis
26 4452234 Back, Chassis
27 Liner, Oven
(Not Serviceable)
29 4455636 Sensor
30 4449845 Bracket, Support
31 4450038 Screw
33 9760677 Deflector, Vent
34 8302592 Vent, Center
35 4449906 Ext−Filler
37 9759243 Thermostat (TOD)
43 9759713 Base, Chassis
49 4448933 Retainer, Gasket
50 4451747 Cover, Back
51
W10145001
Trim, Vent
Bottom
52 8303502 Vent, Control
53 4451756 Chassis, Back
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449316 Insulation, Wrap
4450365 Insulation, Back
CONTROL PANEL PARTS
3
For Models:GMC305PRS02
(Stainless)
W10163659
Illus. Part
No. No. DESCRIPTION
1
W10105800
Assembly, Control
2 8303948 Assembly, Switch
3
W10153086
Backer, Control
4 8301848 Board, Motorized
Latch
5 8302848 Control Panel
6 4451592 Filter
7 4451632 Bracket, Filter
8 4449745 Screw
9 4449809 Screw
10
W10144998
Trim, Cooktop
OVEN DOOR PARTS
4
For Models:GMC305PRS02
(Stainless)
W10163659
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 9759413 Panel, Door
2 Hinge, Door
9760577 Right
9760578 Left
3 4449259 Glass, Inner
4 4451722 Insulation, Door
And Bottom Door
5 4457132 Retainer, Glass
6 4449809 Screw
7 9759225 Glass, Inner
8 4451040 Screw
9 9759228 Glass, Inner
Door
10
8303389BL
Clip, Door
11 Wings
W10144995
Right
W10144994
Left
12
W10151080
Assembly, Door
Glass
13 8303164 Handle, Door
14
W10136473
Bracket, Handle
15 9759229 Bracket(2nd Glass)
16 9759230 Bracket(3rd Glass)
19 4457103 Shield, Heat
22 4457114 Shield, Heat
Bottom
LATCH PARTS
5
For Models:GMC305PRS02
(Stainless)
W10163659
Illus. Part
No. No. DESCRIPTION
1 4451759 Vent, Exhaust
2 4449040 Screw
3 4451758 Seal, Foam
4 4450408 Baffle, Rear
5 4449154 Screw
6 9760888 Latch, Motorized
8 4455178 Vent, Top
9 4455177 Vent, Bottom
6
INTERNAL OVEN PARTS
For Models:GMC305PRS02
(Stainless)
W10163659
Illus. Part
No. No. DESCRIPTION
1 9760771 Element, Broil
2 4449154 Screw
3 4448717 Rack, Oven
4 9760766 Element,
Convention Bake
CABINET AND STIRRER PARTS
7
For Models:GMC305PRS02
(Stainless)
W10163659
CABINET AND STIRRER PARTS
8
For Models:GMC305PRS02
(Stainless)
W10163659
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 4375299 Bracket, Capacitor
3 4375037 Rubber Ring
4 4375038 Screw
5 4375314 Air Duct,
Magnetron
11 4375315 Damper
12 4375260 Duct, Inlet
13 4375316 Insulation, Switch
14 4375322 Fan Wheel
15 4375317 Duct, Air
16 4375264 Block, Side
17 4375248 Cover Plate, Upper
19 4375318 Lens, Lamp
20 4375319 Spring
21 4375320 Reflector
25 4375020 Capacitor
26 4375072 Magnetron
27 4375321 Fuse
28 4375231 Block, Fuse
29 4375278 Motor, Blower
30 4375279 Thermostat
31 4375079 Thermostat
34 4375286 Transformer
35 Hinge, Door
4375323 Left
4375324 Right
36 4451009 Torison Spring
37 Bracket, Hinge
4375327 Left
4375328 Right
38 4375329 Inlet
39 4375330 Door Strap
40 4375333 Fan Cap
41 4375334 Fan Cap Bottom
42 Switch Holder
4375335 Left
4375336 Right
43 4375337 Isolation Plate
44 4375338 Cover Plate
45 4375339 Door Plate
46 4375340 Inner Frame
47 Side Plate
4375341 Left
4375342 Right
48 4455915 Turntable
49 4375344 Ring Assembly
50 4375345 Shaft
51 4375346 Switch
52 4375347 Motor, Turntable
53 4375348 Lamp
54 4375349 Rectifier
55 4375350 Cable
56 4375351 Lamp Holder
MICROWAVE COMPARTMENT PARTS
9
For Models:GMC305PRS02
(Stainless)
W10163659
Illus. Part
No. No. DESCRIPTION
1 Support Rails
4452551 Right
4452552 Left
2 4449809 Screw
3 4452548 Rear Channel
MICROWAVE DOOR PARTS
10
For Models:GMC305PRS02
(Stainless)
W10163659
Illus. Part
No. No. DESCRIPTION
1 8303810 Nameplate
2 4450834 Glass, Middle
3 8303556 Frame, Door
4 4450038 Screw
5 Bracket, Mounting
4449141 Right
4449142 Left
6 4449809 Screw
7 Filler, Side
4449083 Right
4449086 Left
8 8303164 Handle, Door
9
W10151072
Glass, Outer
10 8303169 Bracket, Handle
11 4451040 Screw
